Silver square mini PC with rounded edges and front ports

minisforum

minisforum DeskMini AI X1 Pro-470 Ryzen AI 9 HX 470 32GB DDR5 2TB barebone mini PC

SKU CH-1TSR-ZCRAN

A compact barebone with a 12-core Ryzen AI 9 HX 470, 32 GB DDR5, 2 TB storage, four video outputs, dual 2.5 Gb LAN and Wi-Fi 7

  • ColorSilver
  • AI FeaturesAvailable
  • CPU TypeAMD Ryzen AI 9 HX 470
  • CPU SocketFP8
  • CPU Cores12
  • Memory installed32GB

Option X1 Pro-470 · 32+2T

Show 3 more configurations

Struck-through versions exist but are not stocked here.

  • 12-core Ryzen AI 9 HX 470 up to 5.1 GHz for heavy AI workloads
  • 32 GB DDR5 5600 dual-channel memory expandable to 128 GB
  • 2 TB PCIe 4.0 SSD with two additional M.2 2280 slots for growth
  • Four video outputs via HDMI, DisplayPort and dual USB4
  • Dual 2.5 GbE LAN plus Wi-Fi 7 and Bluetooth 5.4 connectivity

AI Mini PC for Demanding Workloads

The minisforum DeskMini AI X1 Pro-470 is a barebone mini PC built around the AMD Ryzen AI 9 HX 470 processor with 12 cores and 24 threads. It ships with 32GB of DDR5 5600 memory in dual-channel configuration and a 2TB PCIe 4.0 SSD pre-installed. Integrated AMD Radeon 890M graphics drive up to four displays via HDMI, DisplayPort and two USB4 outputs.

Suits AI Developers and Multi-Display Users

This system targets developers running local AI inference, content creators needing multiple monitors and professionals who want high CPU performance in a 7.68-inch square footprint. Dual 2.5GbE ports and WiFi 7 with Bluetooth 5.4 cover wired and wireless networking. Buyers who need discrete GPU power for 3D rendering or gaming should look at larger platforms because the OCuLink port requires sacrificing an M.2 slot and is not hot-swappable.

Deciding Spec: OCuLink Port Trades an M.2 Slot

The single specification that determines fit is the OCuLink interface which enables external PCIe 4.0 x4 connectivity for an eGPU but consumes one of the three M.2 2280 slots. If external graphics expansion is essential, this trade-off is acceptable; if maximum internal storage is the priority, the lost slot reduces total PCIe 4.0 SSD capacity.

Highlights

  • 12-core Ryzen AI 9 HX 470 up to 5.1 GHz for heavy AI workloads
  • 32 GB DDR5 5600 dual-channel memory expandable to 128 GB
  • 2 TB PCIe 4.0 SSD with two additional M.2 2280 slots for growth
  • Four video outputs via HDMI, DisplayPort and dual USB4
  • Dual 2.5 GbE LAN plus Wi-Fi 7 and Bluetooth 5.4 connectivity

Specifications

BrandMINISFORUM
ModelDeskMini
ColorSilver
AI FeaturesAvailable
CPU TypeAMD Ryzen AI 9 HX 470
CPU SocketFP8
CPU Cores12
Memory installed32GB
Memory slot2
Memory Type SupportedDDR5 5600
Max Memory Supported128GB
Dual Channel Memory SupportedYes
Other2x PCIe4.0x4, 1x PCIe4.0x1
Storage Installed2T
Integrated GraphicsAMD Radeon 890M
Max LAN Speed2.5Gbps
Wireless LAN802.11ax
WiFi GenerationWi-Fi 7
BluetoothBluetooth 5.4
Slim ODD2
Front USB3
Front Audio Ports1 jacks
HDMI1
DisplayPort1 x DisplayPort
RJ452
Dimensions7.68x7.68x1.67inch
Weight4.84lb

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Should I pick the 32 GB DDR5 5600 configuration or add more memory later?

The unit ships with 32 GB in dual-channel DDR5 5600 across two SO-DIMM slots; you can expand up to 128 GB total if your workloads need more capacity.

What does the 5.1 GHz boost clock on the 12-core Ryzen AI 9 HX 470 deliver in daily use?

Twelve Zen 5 cores and 24 threads at up to 5.1 GHz give strong single-thread responsiveness and multi-thread throughput for AI-assisted apps, compilation and content creation.

How does the OCuLink port and the two USB4 outputs limit external GPU or display bandwidth?

OCuLink uses one PCIe 4.0 x4 M.2 2280 slot for an external GPU, while each USB4 output carries DisplayPort video and PCIe data for up to four simultaneous displays.
