Green micro-ATX board with black LGA 1151 socket, four DDR4 slots, silver PCIe x16 and two x1 slots, blue SATA ports

MSI

MSI H310M PRO-V PLUS Intel motherboard LGA 1151 DDR4 32GB Micro ATX

SKU CH-DAKB-2M6X2

Micro ATX board for LGA 1151 CPUs with H310 chipset, dual-channel DDR4 up to 32 GB, one PCIe 3.0 x16 slot, two PCIe 2.0 x1 slots, four SATA III ports, Realtek ALC887 7.1 audio, Gigabit LAN.

  • CPU Socket TypeLGA 1151
  • CPU Type8th Gen Intel Core ™ processors with LGA1151 support, as wel
  • ChipsetIntel H310
  • Memory StandardSupports dual-channel DDR4 2666/2400/2133MHz memory
  • Maximum Memory Supported32GB
  • PCI Slots1 PCIe 3.0 x16 slot 2 PCIe 2.0 x1 slots
  • Supports 8th Gen Intel Core processors via LGA 1151 socket
  • Dual-channel DDR4 memory up to 32 GB at 2666 MHz
  • One PCIe 3.0 x16 and two PCIe 2.0 x1 expansion slots
  • Four SATA III ports for storage drives
  • Realtek ALC887 7.1 channel audio with RTL8111H Gigabit LAN

Core compatibility

The MSI H310M PRO-V PLUS is a Micro ATX motherboard built on the Intel H310 chipset. It accepts 8th Gen Intel Core processors and compatible Pentium Gold or Celeron CPUs using the LGA 1151 socket. The board supports dual-channel DDR4 memory at 2666, 2400 or 2133 MHz up to a maximum of 32 GB.

Bundled essentials

The package includes the motherboard, a CMOS battery, one SATA cable and a chassis I/O back panel. These items let you install the board, retain BIOS settings and connect a SATA drive immediately. No Wi-Fi antenna is supplied because the board has no built-in Wi-Fi module.

Build and connectivity

The board provides one PCIe 3.0 x16 slot and two PCIe 2.0 x1 slots for expansion. Storage uses four SATA III ports while audio runs through a Realtek ALC887 codec with 7.1 channel output. Networking is handled by a single RTL8111H Gigabit LAN port. Rear USB includes two USB 3.1 Gen1 Type-A and four USB 2.0 ports, with two more USB 3.1 Gen1 and two USB 2.0 headers onboard.

Highlights

  • Supports 8th Gen Intel Core processors via LGA 1151 socket
  • Dual-channel DDR4 memory up to 32 GB at 2666 MHz
  • One PCIe 3.0 x16 and two PCIe 2.0 x1 expansion slots
  • Four SATA III ports for storage drives
  • Realtek ALC887 7.1 channel audio with RTL8111H Gigabit LAN

Specifications

BrandMSI
SeriesMSI H310M PRO-V PLUS
ModelMSI H310M PRO-V PLUS
CPU Socket TypeLGA 1151
CPU Type8th Gen Intel Core ™ processors with LGA1151 support, as well as Intel Pentium Gold and Celeron processors
ChipsetIntel H310
Memory StandardSupports dual-channel DDR4 2666/2400/2133MHz memory
Maximum Memory Supported32GB
PCI Slots1 PCIe 3.0 x16 slot
2 PCIe 2.0 x1 slots
SATA RAID4XSATA III interface
Audio ChipsetRealtek ALC887 decoding chip
7.1 channel high-quality sound effects
LAN Chipset1 RTL8111H Gigabit network interface card
Onboard USB4 USB 3.1 Gen1 (SuperSpeed USB) ports (2 Type-A ports on the backplane, 2 via onboard USB ports)
6 USB 2.0 (High-speed USB) ports (4 ports on the backplane, 2 via onboard USB ports)

Questions about this item

Will this board take my 8th-generation Intel Core i5 and how much DDR4 can I install?

The LGA 1151 socket accepts 8th Gen Intel Core, Pentium Gold and Celeron processors, and the two slots support up to 32 GB of dual-channel DDR4 at 2666, 2400 or 2133 MHz.

How many SATA drives and front-panel USB ports can I connect?

Four SATA III connectors are onboard, plus two internal USB 2.0 headers and two internal USB 3.1 Gen1 headers for front-panel Type-A ports.

Does the rear I/O include gigabit Ethernet and 7.1-channel audio?

Yes, a single RTL8111H controller provides gigabit LAN and the Realtek ALC887 codec delivers 7.1-channel output through the back-panel audio jacks.
