Black ATX motherboard with silver heatsinks and no RGB lighting

MSI

MSI MEG Z690 UNIFY-X Intel motherboard

SKU CH-DJ4C-WEJRM

ATX Intel Z690 board for 12th Gen Core CPUs on LGA 1700 with dual-channel DDR5 up to 6800 MHz and 64 GB capacity

  • CPU Socket TypeLGA 1700
  • CPU TypeSupports 12th Gen Intel Core™ Processors, Pentium Gold and C
  • ChipsetIntel Z690
  • Memory StandardSupports dual-channel DDR5 6800 (OC) MHz memory
  • Maximum Memory Supported64GB
  • PCI Slots2x PCIe x16 slots (From CPU) Support PCIe 5.0 Support x16/ x
  • Supports 12th Gen Intel Core processors on LGA 1700 socket
  • Dual-channel DDR5 6800 MHz memory up to 64GB capacity
  • PCIe 5.0 x16 slot for next-generation graphics bandwidth
  • 5 Gbps dual LAN controllers for fast wired networking
  • 1-channel Realtek ALC4080 audio with S/PDIF output

Intel Z690 ATX platform

The MSI MEG Z690 UNIFY-X is an Intel Z690 motherboard built for LGA 1700 processors. It supports 12th Gen Intel Core, Pentium Gold and Celeron CPUs in a standard ATX layout. The board provides dual-channel DDR5 memory support up to 64 GB and PCIe 5.0 graphics slots.

Enthusiast DDR5 focus

This board suits builders who want high-frequency DDR5 on a Z690 chipset with 2.5 Gbps dual LAN and 7.1-channel audio. Users requiring larger memory capacity or a smaller Mini-ITX form factor should look at other models.

Dual-channel DDR5 6800 OC limit

The decisive specification is the validated memory ceiling of DDR5 6800 MHz in dual-channel mode with a 64 GB maximum. This defines the performance envelope for memory-sensitive workloads.

Highlights

  • Supports 12th Gen Intel Core processors on LGA 1700 socket
  • Dual-channel DDR5 6800 MHz memory up to 64GB capacity
  • PCIe 5.0 x16 slot for next-generation graphics bandwidth
  • 5 Gbps dual LAN controllers for fast wired networking
  • 1-channel Realtek ALC4080 audio with S/PDIF output

Specifications

BrandMSI
SeriesMSI MEG Z690 UNIFY-X
ModelMSI MEG Z690 UNIFY-X
CPU Socket TypeLGA 1700
CPU TypeSupports 12th Gen Intel Core™ Processors, Pentium Gold and Celeron Processors
Processor socket LGA1700
ChipsetIntel Z690
Memory StandardSupports dual-channel DDR5 6800 (OC) MHz memory
Maximum Memory Supported64GB
PCI Slots2x PCIe x16 slots (From CPU)
Support PCIe 5.0
Support x16/ x0, x8/ x8
1x PCIe x4 slot (From Z690 Chipset)
Supports PCIe 3.0 x4
SATA RAID5XM.2 interface, 6xSATA III interface
Audio ChipsetRealtek ALC4080 Codec
7.1-Channel High Definition Audio
Supports S/PDIF output
LAN Chipset2x Intel I225-V 2.5Gbps LAN controllers
Onboard USBIntel Z690 Chipset
2x USB 3.2 Gen2x2 20Gbps ports ( 1 Type-C port on the back panel, 1 Type-C internal connector)
3x USB 3.2 Gen2 10Gbps Type-A ports on the back panel
2x USB 2.0 Type-A port on the back panel
Hub GL3590
4x USB 3.2 Gen2 10Gbps ports on the back panel
Hub ASM1074
4x USB 3.2 Gen1 5Gbps ports available through internal USB connectors
Hub GL850G
4x USB 2.0 ports available through internal USB connectors

Questions about this item

What ATX case and power connectors does the MSI MEG Z690 UNIFY-X require to fit and mount?

It fits a standard ATX chassis and uses the LGA 1700 socket, 24-pin ATX power and CPU EPS power connectors for installation.

How do I install the CPU into the LGA 1700 socket without bending pins?

Lift the retention lever, align the processor notches with the socket keys, place it gently without force, then lower the lever to lock it.

Which replaceable part on the board keeps BIOS settings when the system is off?

The included CMOS battery maintains the real-time clock and firmware settings while the PC is unplugged.
