Black ATX motherboard with silver heatsinks and four DDR4 slots

MSI

MSI MPG Z590 GAMING PLUS Intel motherboard

SKU CH-Y9Q6-JR4JK

ATX board for 10th and 11th Gen Intel Core CPUs with LGA 1200 socket, four DDR4 slots up to 128 GB, one PCIe 4.0 x16, two PCIe 3.0 x16, two PCIe 3.0 x1, six SATA 6 Gb/s, three M.2 slots.

  • CPU Socket TypeLGA 1200
  • CPU TypeSupports 11th / 10th Gen Intel Core processors Supports Inte
  • ChipsetIntel Z590
  • Onboard Video ChipsetSupported only by CPU with integrated graphic
  • Number of Memory Slots4x288pin (DDR4)
  • Memory StandardDDR4 1R 3200 / 2933 / 2666 / 2133 for 11th Gen Intel CPU (by
  • Supports 11th and 10th Gen Intel Core processors via LGA 1200 socket
  • DDR4 memory up to 5333 MHz overclocked across four 288-pin slots
  • PCIe 4.0 x16 slot and M.2 slot from CPU for 11th Gen processors
  • Intel I225-V LAN plus Realtek ALC4080 7.1 channel audio
  • Six SATA 6Gb/s ports with RAID 0/1/5/10 and three M.2 slots

Socket LGA 1200 Z590 motherboard

The MSI MPG Z590 GAMING PLUS is an ATX motherboard built around the Intel Z590 chipset. It accepts 10th and 11th Gen Intel Core processors as well as Pentium Gold and Celeron CPUs in an LGA 1200 socket. Four DDR4 slots support up to 128 GB of memory in dual-channel mode.

Ideal for 10th or 11th Gen Intel builds

This board suits builders pairing a 10th or 11th Gen Intel CPU with DDR4 memory and multiple SATA drives. It is not suitable for newer 12th Gen or later Intel processors, which require a different socket and chipset.

PCIe 4.0 x16 slot requires an 11th Gen CPU

The single PCI Express 4.0 x16 slot and the primary M.2 slot are wired from the CPU and only operate at 4.0 speeds when an 11th Gen processor is installed. With a 10th Gen CPU those connections fall back to PCIe 3.0.

Highlights

  • Supports 11th and 10th Gen Intel Core processors via LGA 1200 socket
  • DDR4 memory up to 5333 MHz overclocked across four 288-pin slots
  • PCIe 4.0 x16 slot and M.2 slot from CPU for 11th Gen processors
  • Intel I225-V LAN plus Realtek ALC4080 7.1 channel audio
  • Six SATA 6Gb/s ports with RAID 0/1/5/10 and three M.2 slots

Specifications

BrandMSI
ModelMPG Z590 GAMING PLUS
CPU Socket TypeLGA 1200
CPU TypeSupports 11th / 10th Gen Intel Core processors
Supports Intel Pentium Gold / Celeron processors
ChipsetIntel Z590
Onboard Video ChipsetSupported only by CPU with integrated graphic
Number of Memory Slots4x288pin (DDR4)
Memory StandardDDR4 1R 3200 / 2933 / 2666 / 2133 for 11th Gen Intel CPU (by JEDEC & POR)
DDR4 1R 2933 / 2666 / 2133 for 10th Gen Intel CPU (by JEDEC & POR)
Max overclocking frequency:
1DPC 1R Max speed up to 5333
1DPC 2R Max speed up to 4700+
2DPC 1R Max speed up to 4400+
2DPC 2R Max speed up to 4000+
Maximum Memory Supported128GB
Channel SupportedDual Channel
PCI Express 4.0 x161 x PCI Express 4.0 x16*
* Actual support may vary by CPU.
PCI Express 3.0 x162 x PCI Express 3.0 x16*
* PCI_E3 will be unavailable when installing M.2 SSD in the M2_2 slot.
PCI Express x12 x PCIe 3.0 x1
Serial ATA (SATA)6 x SATA 6Gb/s
M.23 x M.2 slots (Key M):
M2_1 slot (From CPU):
Available only on 11th Gen Intel CPU
Supports up to PCIe 4.0 x4
Supports 2242/2260/2280/22110 storage devices
M2_2* & M2_3** slots (From Z590 Chipset):
Support up to PCIe 3.0 x4 and SATA 6Gb/s
Supports 2242/2260/2280 storage devices
Intel Optane Memory Ready***
* PCI_E3 will be unavailable when installing M.2 SSD in the M2_2 slot. SATA2 will be unavailable when installing M.2 SATA SSD in the M2_2 slot.
** SATA5 & SATA6 will be unavailable when installing M.2 SSD in the M2_3 slot.
*** Before using Intel Optane memory modules, please ensure
Intel Optane ReadyYes
SATA RAID0/1/5/10
Audio ChipsetRealtek ALC4080
Audio Channels7.1 Channels
LAN ChipsetIntel I225-V
Max LAN Speed2.5Gbps
Back I/O Ports1 x DisplayPort
1 x HDMI
1 x LAN (RJ45)
1 x Optical S/PDIF Out
1 x USB 3.2 Gen 2x2 Type-C
2 x USB 2.0/1.1
2 x USB 3.2 Gen 1 Type-A
3 x USB 3.2 Gen 2 Type-A
5 x Audio Jacks
1 x Flash BIOS Button
Onboard USB1 x USB 3.2 Gen 2 10Gbps Type-C port
1 x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports)
2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
Other Connectors1 x 4-pin CPU fan connector
1 x 4-pin water-pump fan connector
6 x 4-pin system fan connectors
1 x Front panel audio connector
2 x System panel connectors
1 x Chassis Intrusion connector
1 x TPM module connector
1 x Clear CMOS jumper
1 x TBT connector (supports RTD3)
Windows 11Supported
Form FactorATX
LED LightingRGB
Dimensions (W x L)12.0" x 9.6"
Power Pin1 x 24-pin ATX main power connector
2 x 8-pin ATX 12V power connectors
1 x 6-pin ATX PCIE power connector
FeaturesSupports 11th and 10th Gen Intel Core / Pentium Celeron processors for LGA 1200 socket
Supports DDR4 Memory, up to 5333(OC) MHz
Lightning Fast Game experience: PCIe 4.0, Lightning Gen 4 x4 M.2, USB 3.2 Gen 2x2
Enhanced Power Design: 14+1+1 Duet Rail Power System, dual 8-pin CPU power connectors, Core Boost, DDR4 Boost
Premium Thermal Solution: Enlarged heatsink with heat-pipe, MOSFET thermal pads rated for 7W/mK, additional choke thermal pads and 3 x M.2 Shield Frozr are built for high performance system and non-stop gaming experience
MYSTIC LIGHT: 16.8 million colors / 29 effects co

Questions about this item

Will this board work with my 11th Gen Intel Core i7 processor?

Yes, the LGA 1200 socket and Z590 chipset support both 11th and 10th Gen Intel Core, Pentium Gold and Celeron CPUs.

Can I install four 32 GB DDR4 modules to reach 128 GB?

The board has four 288-pin DDR4 slots and a maximum capacity of 128 GB, so four 32 GB sticks will work.

If I use an 11th Gen CPU, can I run a PCIe 4.0 M.2 drive in the top slot?

The M2_1 slot connects to the CPU and supports PCIe 4.0 x4 with 11th Gen processors; it is unavailable with 10th Gen chips.
