Green printed circuit board M.2 2280 SSD with black controller and silver label

Mushkin Enhanced

Mushkin Enhanced Tempest MKNSSDTS2TB-D8 2TB PCIe Gen3 x4 NVMe 1.4 M.2 2280 internal SSD

SKU CH-WZP2-7SFYD MPN MKNSSDTS2TB-D8

A 2TB M.2 2280 NVMe SSD delivering up to 3250 MBps read and 2900 MBps write with 1000 TBW endurance

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity2TB
  • Memory Components3D NAND
  • InterfacePCIe Gen3 x4 NVMe 1.4

Options 2TB

  • Up to 3250 MBps sequential read speeds data loads fast
  • Up to 2900 MBps sequential write speeds large files save quickly
  • 344,000 IOPS random read responsiveness stays sharp under multitasking
  • 343,000 IOPS random write mixed workloads finish without lag
  • 1000 TBW endurance rating drive handles heavy daily writes

M.2 2280 2TB NVMe SSD

The Mushkin Enhanced Tempest MKNSSDTS2TB-D8 is a 2TB internal solid state drive built for consumer workloads. It uses 3D NAND flash and an InnoGrit IG5216 controller in an M.2 2280 form factor. The drive targets users who need fast sequential and random access for intensive computing tasks.

PCIe Gen3 x4 NVMe 1.4 interface limits

The drive connects through a PCIe Gen3 x4 lane configuration using the NVMe 1.4 protocol. This interface caps theoretical bandwidth below newer Gen4 or Gen5 standards, so maximum throughput is bounded by the Gen3 electrical specification. Performance scales with the host platform's PCIe generation support.

Verify M.2 slot wiring and BIOS support

Confirm the motherboard provides an M.2 2280 slot wired for PCIe NVMe operation and that the BIOS recognises NVMe 1.4 drives as boot devices. The controller requires no external DRAM cache, so the slot must supply sufficient power for sustained 3250 MBps reads and 2900 MBps writes. Check firmware update availability for the IG5216 controller.

Highlights

  • Up to 3250 MBps sequential read speeds data loads fast
  • Up to 2900 MBps sequential write speeds large files save quickly
  • 344,000 IOPS random read responsiveness stays sharp under multitasking
  • 343,000 IOPS random write mixed workloads finish without lag
  • 1000 TBW endurance rating drive handles heavy daily writes

Specifications

BrandMushkin Enhanced
SeriesTempest
ModelMKNSSDTS2TB-D8
Part NumberMKNSSDTS2TB-D8
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity2TB
Memory Components3D NAND
InterfacePCIe Gen3 x4 NVMe 1.4
ProtocolNVMe 1.4
ControllerInnoGrit IG5216
Cache0MB
Max Sequential ReadUp to 3250 MBps
Max Sequential WriteUp to 2900 MBps
4KB Random ReadUp to 344,000 IOPS
4KB Random WriteUp to 343,000 IOPS
Seek Time< 0.1 ms
Terabytes Written (TBW)1000TB
MTBF1,500,000 hours
FeaturesMEDS (Mushkin Enhanced Data-protection Suite) ensures valuable data is protected
- Built-in 4th Generation LDPC ECC provides the most-powerful data correction level in use today
- End-to-end data path protection
- SLC Caching
- Data shaping increases endurance
- StaticDataRefresh ensures data integrity
- Global wear-leveling evens program/erase counts across data blocks to extend lifespan
Enhanced Power Management
NVMe Security Erase support
NVMe Deallocate function support (NVMe equivalent of TRIM command)
High-reliability 3D NAND flash
S.M.A.R.T. support
Temperature sensor
RoHS, FC
Power Consumption (Idle)0.3W
Power Consumption (Active)3W
Operating Temperature0°C ~ +70°C
Storage Temperature-40°C ~ +85°C
Max Shock Resistance1500G
Height3.80mm
Width22.00mm
Depth80.00mm
Weight7.00g
Shipping weight0.02 kg
Package size127 × 51 × 18 mm

Other versions of this model

3 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Will this M.2 2280 drive fit my laptop or motherboard slot?

The drive uses the M.2 2280 form factor, which is the standard 80 mm length for most modern laptops and desktops. Verify your device has an M-keyed M.2 slot that supports PCIe NVMe before purchasing.

Does this SSD require a separate heatsink for heavy workloads?

The drive is a single-sided M.2 2280 module with no bundled heatsink. Many motherboards include integrated M.2 shields that provide adequate cooling; if yours does not, an aftermarket heatsink can be added.

What endurance rating does the 2 TB model offer for long-term writes?

The drive is rated for 1000 TBW (terabytes written) and an MTBF of 1,500,000 hours, indicating it can sustain heavy daily write workloads for several years in typical consumer use.
