Rectangular green circuit board 115 by 65 mm with soldered components and mounting holes

myVolts

myVolts 24V 6-9A AC-DC Power Supply 150W 115x65mm

SKU CH-K36X-S3QJ0

Delivers 24 V DC at 6–9 A with 150 W continuous power in a compact 115 × 65 mm board

  • TypeAT
  • Universal AC input 100-240V works worldwide
  • 24V DC output delivers up to 150W continuous power
  • Compact 115x65mm board fits tight enclosures
  • Built-in overcurrent overload and short-circuit protection safeguards equipment
  • Low noise ripple under 150mV ensures clean power

24V 150W AC-DC Module

This 24V DC power supply accepts a universal AC 100-240V 50/60Hz input and delivers a continuous 6-9A output with a 150W rating and 220W peak. The open-frame board measures 115x65mm with mounting pores at 105.8x55.7mm and includes overcurrent, overload and short-circuit protection. Ripple is specified below 150mV.

Integration-Focused Builders

Suits engineers and technicians embedding a 24V source inside custom enclosures, test rigs or industrial equipment where an AT-type board can be secured to the mounting pattern. Not for buyers needing a housed desktop unit with IEC inlet and cable strain relief, or anyone requiring a silent fanless chassis.

220W Peak Headroom

The 220W maximum output power is the single figure that decides whether the board can absorb transient loads such as motor starts or capacitor inrush without tripping protection.

Highlights

  • Universal AC input 100-240V works worldwide
  • 24V DC output delivers up to 150W continuous power
  • Compact 115x65mm board fits tight enclosures
  • Built-in overcurrent overload and short-circuit protection safeguards equipment
  • Low noise ripple under 150mV ensures clean power

Specifications

TypeAT

Questions about this item

What AC mains input does the 24V 150W supply accept?

It accepts AC 100-240V at 50/60Hz, so it works on standard household mains worldwide.

Will the 115x65mm board fit the 105.8x55.7mm mounting holes in my existing chassis?

Yes, the mounting-hole pattern is 105.8x55.7mm and the board outline is 115x65mm, matching that footprint.

How can I verify the output is within spec after wiring it up?

Measure the DC output with a multimeter; it should read 24V with ripple below 150mV under load.
