Eight green DDR4 RDIMM modules with gold contacts, no heat spreaders

NEMIX RAM

NEMIX RAM THINKMATE DDR4 3200 ECC RDIMM 1TB (8×128GB) CL22 1.2V 4Rx4 288-pin

SKU CH-TXTB-3ACA6

Eight 128 GB DDR4-3200 registered ECC modules deliver 1 TB capacity at CL22 and 1.2 V for ThinkMate workstations

  • Capacity1TB (8 x 128GB)
  • SpeedDDR4 3200 (PC4 25600)
  • ECCYes
  • Buffered/RegisteredRegistered
  • ChipsetMajor OEM Samsung, Micron, Hynix
  • Voltage1.20V
  • 1 TB total capacity with eight 128 GB modules
  • DDR4 3200 speed rated at PC4-25600
  • ECC registered design detects and corrects data errors
  • 2 V operating voltage reduces power draw
  • Validated for Thinkmate VSX-R5-760S1 and VSX-R5-540RTP workstations

ThinkMate-validated DDR4 ECC RDIMM kit

This 1 TB kit comprises eight 128 GB DDR4 3200 registered DIMMs built for ThinkMate VSX-R5-760S1 and VSX-R5-540RTP workstations. Each module runs at 1.2 V with CL22 latency and 4Rx4 organisation. ECC and registered buffering protect data integrity in multi-socket server workloads.

288-pin RDIMM form factor with major-brand DRAM

Modules use Samsung, Micron or Hynix chips without heat spreaders, fitting standard DDR4 RDIMM slots. Registered signalling reduces electrical load on the memory controller, allowing all eight slots to be populated. The 1.2 V operating voltage matches DDR4 JEDEC baseline for server platforms.

Replaces smaller or slower DDR4 RDIMM sets

Upgrading from lower-capacity or lower-speed registered ECC kits adds 1 TB in a single validated configuration. The jump is worthwhile when workloads exceed current memory bandwidth or capacity limits on compatible ThinkMate systems. Mixed-rank or unbuffered modules are not supported by these platforms.

Highlights

  • 1 TB total capacity with eight 128 GB modules
  • DDR4 3200 speed rated at PC4-25600
  • ECC registered design detects and corrects data errors
  • 2 V operating voltage reduces power draw
  • Validated for Thinkmate VSX-R5-760S1 and VSX-R5-540RTP workstations

Specifications

BrandNEMIX RAM
SeriesTHINKMATE Server/Workstation Compatible Series Memory
ModelTHINKMATE DDR4 3200MHZ ECC RDIMM Registered Server Memory
Part NumberMR25600-744K8
Capacity1TB (8 x 128GB)
SpeedDDR4 3200 (PC4 25600)
ECCYes
Buffered/RegisteredRegistered
ChipsetMajor OEM Samsung, Micron, Hynix
Voltage1.20V
Compatible SystemTHINKMATE
CAS LatencyCL22
Heat SpreaderNo
Type288-Pin DDR4 RDIMM
Rank4Rx4
FeaturesDDR4 ECC Registered RDIMM Server Motherboard Compatible
Package Content1TB (8X128GB) DDR4 3200MHZ PC4-25600 4Rx4 1.2V CL22 288-PIN ECC RDIMM Registered Server Memory KIT

Questions about this item

Does the DDR4 3200 PC4-25600 interface limit throughput to 25600 MB/s?

The modules run at DDR4 3200 (PC4-25600), so the theoretical peak bandwidth is 25600 MB/s per channel; actual throughput depends on the motherboard and CPU memory controller.

What physical clearance do the 288-pin RDIMM modules need in the ThinkMate VSX-R5-760S1 or VSX-R5-540RTP?

Each module is a standard 288-pin DDR4 RDIMM without a heat spreader, so they fit in the regular DIMM slots of the listed ThinkMate workstations as long as the chassis allows full-height modules.

How are the eight 128 GB sticks installed, and which step is often missed?

Populate all eight slots following the motherboard’s population guide for 4Rx4 registered DIMMs, then enable ECC in the BIOS — the BIOS step is frequently overlooked.
