Black mid-tower ATX case with tempered glass side panel and front RGB fan

NZXT

NZXT CC-H52FB-R1 H5 Flow RGB ATX Mid Tower PC case

SKU CH-3VVK-5AT8Z MPN CC-H52FB-R1

Mid-tower ATX chassis with perforated PSU shroud, mesh panels and pre-installed RGB fans for high-airflow builds

  • Motherboard CompatibilityATX / E-ATX / Micro ATX / Mini ITX
  • Power Supply MountedBottom
  • ColorBlack
  • Case MaterialSGCC Steel / Dark Tinted Tempered Glass
  • TypeATX Mid Tower
  • With Power SupplyNo

Options H5 Flow RGB (Black)

  • Perforated PSU shroud and mesh panels direct airflow straight to the GPU for stronger cooling
  • Front supports up to 360 mm radiator and top up to 240 mm or 280 mm with low-profile RAM for powerful liquid cooling
  • Ultra-fine mesh panels act as both high-flow intake and dust filters to keep components clean
  • Pre-installed front F360 RGB Core fan and rear F120Q fan deliver immediate cooling and lighting out of the box
  • Wide cable channels and hooks simplify routing for a tidy interior and better airflow

Compact airflow mid-tower

The NZXT H5 Flow RGB is an ATX mid-tower chassis built for builders who prioritise GPU thermals in a compact footprint. Its perforated PSU shroud and ultra-fine mesh panels pull cool air directly toward the graphics card while filtering dust. A front-mounted F360 RGB Core fan and a rear F120Q fan ship pre-installed for immediate airflow and lighting.

Upgrade from restricted airflow cases

This chassis replaces enclosures with solid front panels or closed PSU shrouds that starve the GPU of fresh air. The jump is worth it when your current build runs hot under load and you need front intake that feeds bottom-mounted fans straight to the graphics card. Support for a 360 mm front radiator and a 240 mm top radiator also opens the door to custom-loop or AIO upgrades that smaller cases cannot fit.

Radiator and fan limits

The front mount accepts up to a 360 mm radiator or three 120 mm fans, while the top mount takes up to 240 mm, extending to 280 mm only with low-profile memory installed. Bottom mounts support two 120 mm fans but no radiator, and the rear fits a single 120 mm fan. These constraints define the maximum cooling capacity you can install without modification.

Highlights

  • Perforated PSU shroud and mesh panels direct airflow straight to the GPU for stronger cooling
  • Front supports up to 360 mm radiator and top up to 240 mm or 280 mm with low-profile RAM for powerful liquid cooling
  • Ultra-fine mesh panels act as both high-flow intake and dust filters to keep components clean
  • Pre-installed front F360 RGB Core fan and rear F120Q fan deliver immediate cooling and lighting out of the box
  • Wide cable channels and hooks simplify routing for a tidy interior and better airflow

Specifications

Motherboard CompatibilityATX / E-ATX / Micro ATX / Mini ITX
Power Supply MountedBottom
ColorBlack
Case MaterialSGCC Steel / Dark Tinted Tempered Glass
TypeATX Mid Tower
With Power SupplyNo
Side Panel1 x Side Tempered Glass Panel
LEDRGB
Dust FiltersBottom / Front / Top
Front Ports1 x USB 3.2 Type-A, 1 x USB 3.2 Type-C, 1 x Audio
BrandNZXT
SeriesH5 Flow RGB
ModelCC-H52FB-R1
Part NumberCC-H52FB-R1
Internal 3.5" Drive Bays1
Internal 2.5" Drive Bays2
Expansion Slots7
Fan OptionsFront: 3 x 120 mm / 2 x 140 mm (1 x F360 RGB Core Case Version included)
Top: 2 x 120 mm / 2 x 140 mm
Bottom: 2 x 120 mm
Rear: 1 x 120 mm (2 x F120Q Case Version included)
Pre-installed FansFront - 3 x 120mm / Rear - 1 x 120mm
Radiator OptionsFront: Up to 360 mm
Top: Up to 240 mm (280mm with low-profile memory only)
Max GPU Length410 mm
Max CPU Cooler Height170 mm
Max PSU Length200 mm
Dimensions465 x 225 x 430 mm / 18.31" x 8.86" x 16.93"
Weight7.28 kg / 16.04 lbs.
FeaturesThe H5 Flow boosts airflow and GPU cooling with its fully-perforated PSU shroud, mesh panels, and robust radiator support—all in a compact mid-tower form factor.
Package Content1 x H5 Flow RGB
1 x F360 RGB Core (CV)
2 x F120Q (CV)
1 x Installation accessories
1 x User guide
Shipping weight9.87 kg
Package size556 × 526 × 310 mm

Other versions of this model

3 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Will the NZXT H5 Flow RGB fit an E-ATX motherboard and a 360 mm front radiator at the same time?

Yes, the case supports E-ATX boards and a front radiator up to 360 mm, so both can be installed together.

How do I install the bottom fans that feed the perforated PSU shroud, and what step is often missed?

Mount two 120 mm fans on the bottom bracket, then re-attach the bracket; the missed step is forgetting to plug the fan cables into the motherboard or controller before closing the panel.

Which dust filters need regular cleaning on this chassis?

The bottom, front and top ultra-fine mesh panels act as dust filters and should be removed and cleaned periodically to maintain airflow.
