Black mid-tower case with dark tinted tempered glass side panel and mesh front, three 120mm fans visible inside

NZXT

NZXT H7 Flow CM-H72FB-01 PC Case

SKU CH-FF7T-N897X MPN CM-H72FB-01

Mid-tower ATX case with vertical PSU layout, three pre-installed 120 mm front fans and bottom mounts for three more 120 mm fans

  • Motherboard CompatibilityE-ATX (Up to 27.7mm), ATX, Micro-ATX, Mini-ITX
  • ColorBlack
  • Case MaterialSGCC Steel, Dark Tinted Tempered Glass
  • TypeATX Mid Tower
  • Side Panel1 x Side Tempered Glass Panel
  • Dust FiltersHigh Performance Mesh

Options H7 Flow Black (2024)

Struck-through versions exist but are not stocked here.

  • Supports E-ATX boards up to 27.7 mm wide
  • Three 120 mm front fans pre-installed for immediate airflow
  • Front radiator capacity up to 420 mm for liquid cooling
  • GPU clearance of 410 mm fits long graphics cards
  • USB 3.2 Gen 2 Type-C front port for fast peripherals

Mid-tower airflow case

The NZXT H7 Flow is an ATX mid-tower built around a high-performance mesh front panel and three pre-installed 120 mm F120Q fans. It accepts E-ATX boards up to 27.7 mm thick plus ATX, Micro-ATX and Mini-ITX layouts. A vertical PSU layout creates room for three bottom intake fans without widening the 244 mm chassis. Front USB 3.2 Gen 1 Type-A, USB 3.2 Gen 2 Type-C and a headset jack handle everyday I/O.

Thermals and acoustics at idle

The mesh front and top panels feed cool air to components while trapping dust on removable filters. Three front 120 mm fans spin at 1 350 ± 150 RPM, delivering 60.2 CFM each at low noise levels. A single rear 120 mm or 140 mm slot and top mounts for three 120 mm or two 140 mm fans give flexible exhaust paths. The dark-tinted tempered glass side panel keeps the interior visible without adding vibration.

Sustained-load behaviour

Under prolonged load the case can mount a 420 mm radiator up front and a 360 mm unit on top for liquid-cooled CPUs and GPUs. GPU clearance reaches 410 mm and CPU cooler height tops out at 185 mm, leaving headroom for large air towers. The PSU cavity fits units up to 200 mm deep while still allowing bottom fan airflow. Seven expansion slots and four 2.5-inch plus four 3.5-inch drive bays support dense storage arrays without choking airflow.

Highlights

  • Supports E-ATX boards up to 27.7 mm wide
  • Three 120 mm front fans pre-installed for immediate airflow
  • Front radiator capacity up to 420 mm for liquid cooling
  • GPU clearance of 410 mm fits long graphics cards
  • USB 3.2 Gen 2 Type-C front port for fast peripherals

Specifications

Motherboard CompatibilityE-ATX (Up to 27.7mm), ATX, Micro-ATX, Mini-ITX
ColorBlack
Case MaterialSGCC Steel, Dark Tinted Tempered Glass
TypeATX Mid Tower
Side Panel1 x Side Tempered Glass Panel
Dust FiltersHigh Performance Mesh
Front Ports2 x USB 3.2 Gen 1 Type-A, 1 x USB 3.2 Gen 2 Type-C, 1 x Audio,
BrandNZXT
ModelCM-H72FB-01
Part NumberCM-H72FB-01
Internal 3.5" Drive Bays2 + 2
Internal 2.5" Drive Bays4
Expansion Slots7
Fan OptionsFront: 3 x 120 mm / 3 x 140 mm (3 x F120Q included)
Top: 3 x 120 mm / 2 x 140 mm
Bottom: 3 x 120 mm
Rear: 1 x 120 mm / 1 x 140 mm
Fan Specs
Model: F120Q Airflow Fan (Case Version)
Speed: 1,350 ± 150 RPM
Airflow: 60.2 CFM
Static Pressure: 1.05 mm-H2O
Noise: 24.1 dBA
Fan Connector: 3-pin
Pre-installed FansFront - 3 x 120mm
Radiator OptionsFront: Up to 420 mm
Top: Up to 360 mm
Rear: Up to 140 mm
Max GPU Length410 mm
Max CPU Cooler Height185 mm
Max PSU Length200 mm
DimensionsW: 244mm H: 544mm D: 468mm (with feet)
FeaturesThe H7 Flow maintains a classic mid-tower look while enabling direct GPU cooling with bottom fan support. Ultra-fine perforation on the panels maximizes airflow. Includes 3 x 120mm fans.
Accommodates up to 420mm radiators in the front, 360mm radiators up top, plus a 10-fan capacity to meet the cooling needs of any build.
Crafted from durable steel and tempered glass panels. Rigorously tested to ensure long-lasting performance and appearance over the years.
Experience simplified building with an intuitive cable management system and tool-less panel access. Supports both ATX and EATX m
Shipping weight11.34 kg
Package size635 × 559 × 330 mm

Other versions of this model

3 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How do I install the three pre-installed 120mm front fans, and what step do people get wrong?

The three 120mm fans come pre-installed at the front. The common mistake is forgetting to plug each fan into the motherboard or fan hub so they actually spin.

What maintenance will the high-performance mesh dust filters need later?

Remove the magnetic mesh panels and rinse or vacuum the dust off every few months to keep airflow at 60.2 CFM per fan.

What is the first limit I will hit when running a 420mm front radiator under sustained load?

The 185mm CPU cooler height clearance becomes the limiting factor once a thick 420mm radiator and fans occupy the front chamber.
