Black aluminium-top enclosure with USB-C port and 2-in-1 cable

Orico

Orico M2PV NVMe drive enclosure USB 3.1 Gen 2 10 Gbps 2230 2242 2260 2280

SKU CH-DWC6-JYH9V

USB 3.1 Gen 2 Type-C enclosure turns a PCIe NVMe M.2 SSD (2230, 2242, 2260, 2280) into a 10 Gbps portable drive with aluminium top for heat dissipation

  • SizeSupports All Size
  • ColorBlack
  • External InterfaceUSB 3.1 Type-C
  • AC AdapterNo
  • MaterialAluminum / Plastic
  • FanNo

Material Aluminum / Plastic

Interface USB 3.1 Type-C

  • USB 3.1 Type-C
  • USB Type C

Bay 1

  • 1
  • 1 Bay

Size M.2 NVME SSD

  • M.2 NVME SSD
  • M.2 NVMe / NGFF SSD
  • M.2 NGFF SSD

Model 1 Bay

  • 1 Bay
  • M.2 NVME SSD (20Gbps)

Struck-through versions exist but are not stocked here.

  • USB 3.1 Gen 2 delivers up to 10 Gbps transfer speed
  • Realtek RTL9210 controller enables plug-and-play on Windows, Mac and Linux
  • Aluminium top with thermal pad keeps the SSD cool during use
  • 2-in-1 USB-C to C and USB-C to A cable works with laptops, desktops and OTG phones
  • Fits 2230, 2242, 2260 and 2280 PCIe NVMe M.2 drives up to 8 TB

Portable NVMe enclosure for 2230–2280 drives

The Orico M2PV is a compact USB 3.1 Gen 2 Type-C enclosure that accepts single-sided M.2 PCIe NVMe SSDs in 2230, 2242, 2260 and 2280 lengths. It uses the Realtek RTL 9210 controller to deliver up to 10 Gbps bandwidth and supports Windows, macOS and Linux without drivers. The aluminium top and plastic base provide passive cooling and an auto-sleep function powers the drive down after ten minutes of inactivity. A 2-in-1 USB-C to C and USB-C to A cable is included for broad host compatibility.

Suits mobile workflows; not for SATA or Mac SSDs

This enclosure is built for users who need fast external NVMe storage on laptops, desktops or OTG-capable phones and tablets. It does not support M.2 SATA SSDs, M.2 PCIe AHCI SSDs or any SSD originally fitted to a Mac, so buyers with those drive types must choose a different adapter. The single-bay design also means it cannot accommodate two drives simultaneously or provide RAID functionality.

Sustained performance with passive cooling

Under continuous read or write loads the aluminium lid acts as a heatsink, while the RTL 9210 controller manages thermal throttling to maintain stable throughput. The auto-sleep feature reduces wear and power draw during idle periods, and the plug-and-play operation means no software overhead affects long transfers. Peak speeds will still depend on the installed SSD and the host USB port capabilities.

Highlights

  • USB 3.1 Gen 2 delivers up to 10 Gbps transfer speed
  • Realtek RTL9210 controller enables plug-and-play on Windows, Mac and Linux
  • Aluminium top with thermal pad keeps the SSD cool during use
  • 2-in-1 USB-C to C and USB-C to A cable works with laptops, desktops and OTG phones
  • Fits 2230, 2242, 2260 and 2280 PCIe NVMe M.2 drives up to 8 TB

Specifications

BrandORICO
SeriesORICO M2PV
ModelORICO M2PV
Part Number6954301166405
SizeSupports All Size
ColorBlack
External InterfaceUSB 3.1 Type-C
AC AdapterNo
MaterialAluminum / Plastic
FanNo
Specifications10 Gbps HIGH SPEED
ONLY SUITABLE FOR PCIe NVMe M.2 SSD
Plug and Play, No Driver required.
Supports Window / Mac / Linux.
TypeEnclosure
HDD Count SupportedSingle SSD
Number of Bay1
Maximum Capacity (per Bay)Up to 4TB
PowerNo
Dimensions5.91 x 3.19 x 1.42 inches
Package Contents1x ORICO M.2 NVMe Enclosure
1x2-in-1 data cable
2x Silicone Plug
1x User manual
1x Silicone Thermal Pad
1x Screwdriver

Other versions of this model

3 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What type of M.2 SSD must I already own for the Orico M2PV enclosure to work?

You need a PCIe NVMe M-key M.2 SSD in 2230, 2242, 2260 or 2280 form factor; SATA-based or AHCI M.2 drives are not supported.

Will my USB 3.1 Gen 1 (5 Gbps) port limit the 10 Gbps Realtek RTL 9210 controller in this enclosure?

The enclosure is backward compatible with USB 3.1 Gen 1 ports, but the 10 Gbps ceiling will drop to the port's 5 Gbps maximum.

How can I confirm the auto-sleep feature is active after I connect the M2PV?

Leave the drive idle for ten minutes; the enclosure should enter sleep mode automatically, which you can verify by the LED turning off or the drive spinning down.
