Silver 12.1 inch all-in-one panel PC with resistive touch screen and fanless aluminium housing

partaker

partaker A2-PA-121TPC-CE5B(I34) 12.1" all-in-one PC i3 1.90GHz 4GB DDR3 64GB SSD

SKU CH-4204-RTC26

12.1" industrial panel PC with IP65 front protection, fanless aluminium chassis, Intel Core i3 1.90GHz, 4GB DDR3L and 64GB SSD

  • Form FactorAll-in-One
  • ColorSilver
  • Operating SystemWindows 10 Pro
  • CPU TypeIntel Core i3 4th Gen
  • CPU Name1.90GHz
  • GPU/VGA TypeIntel HD Graphics 4400

GPU Intel HD Graphics 4400

Memory 4GB DDR3

  • 4GB DDR3
  • 8GB DDR3

SSD 64GB

  • 64GB
  • 256GB
  • 512GB

HDD None

  • None
  • 1TB

Struck-through versions exist but are not stocked here.

  • IP65 front panel resists dust and water jets
  • High-temperature 5-wire resistive touch rated for 200 million touches
  • Fanless aluminium chassis operates silently from 0 to 50 °C
  • Intel Core i3 4th Gen with 4 GB DDR3 and 64 GB SSD runs Windows 10 Pro out of the box
  • VESA 75 mount plus HDMI, VGA, dual LAN, four USB and two COM ports for flexible integration

Compact industrial panel PC

The 12.1 inch all-in-one system combines an Intel Core i3 fourth-generation processor at 1.90 GHz with 4 GB of DDR3L memory and a 64 GB mSATA SSD. Its fanless aluminium chassis carries an IP65-rated front panel and a high-temperature five-wire resistive touchscreen. The unit ships with Windows 10 Pro installed and supports embedded, wall, desktop or cantilever mounting.

Interface and expansion limits

Video output is provided through one HDMI and one VGA port. Networking uses a single LAN connection. Two USB 3.0 and two USB 2.0 ports handle peripherals, while two COM ports serve legacy serial devices. Internal expansion is limited to one full-size Mini PCIe slot with a SIM socket; storage can be expanded with one 2.5 inch SATA drive alongside the mSATA SSD. The DDR3L SODIMM slot accepts up to 8 GB total memory.

Deciding specification

The resistive touchscreen is rated for 200 million touches and operates across a 0 to 50 °C range with the fitted SSD. This durability and temperature envelope determines whether the panel PC suits continuous industrial use or requires a different touch technology.

Highlights

  • IP65 front panel resists dust and water jets
  • High-temperature 5-wire resistive touch rated for 200 million touches
  • Fanless aluminium chassis operates silently from 0 to 50 °C
  • Intel Core i3 4th Gen with 4 GB DDR3 and 64 GB SSD runs Windows 10 Pro out of the box
  • VESA 75 mount plus HDMI, VGA, dual LAN, four USB and two COM ports for flexible integration

Specifications

ModelA2-PA-121TPC-CE5B(I34)-4G64G
Form FactorAll-in-One
ColorSilver
Operating SystemWindows 10 Pro
CPU TypeIntel Core i3 4th Gen
CPU Name1.90GHz
GPU/VGA TypeIntel HD Graphics 4400
Memory Capacity4GB DDR3
SSD64GB
HDDNo
Screen Size12.1"
TouchscreenYes

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Should I pick the 4 GB DDR3L model or upgrade to the 8 GB maximum?

The unit ships with 4 GB DDR3L 1333/1600 in a single SODIMM slot and supports up to 8 GB total; adding a second 4 GB module gives headroom for multi-tasking without changing the existing stick.

How does the 1.90 GHz Core i3 4th Gen with HD Graphics 4400 perform in a fanless industrial chassis?

The 1.90 GHz dual-core i3 and integrated HD 4400 run passively cooled in the aluminium housing, delivering steady performance for HMI, SCADA and light edge workloads within the 0 – 50 °C operating range.

What does the 12 V DC input with 100 – 240 V AC adapter mean for installation?

The panel PC accepts 12 V DC directly and includes a 100 – 240 V AC adapter, so it can be wired into a 12 V vehicle or cabinet supply or plugged into mains power without extra converters.
