Rectangular black 2.5 inch SATA SSD with silver label and gold connectors

Patriot Memory

Patriot Memory PBE480GS25SSDR 480GB 2.5" SATA III internal SSD

SKU CH-XVXE-W29EB MPN PBE480GS25SSDR

A 2.5-inch SATA III solid-state drive with 480 GB of TLC storage, sequential reads up to 450 MB/s and writes up to 320 MB/s, DRAM-less HMB caching, and a 2-million-hour MTBF

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form Factor2.5"
  • Capacity480GB
  • Memory ComponentsTLC
  • InterfaceSATA III

Options 480GB TLC

  • Up to 450 MB/s sequential read speeds accelerate boot and load times
  • 400 TBW endurance rating supports heavy daily write workloads
  • 2,000,000 hour MTBF indicates long-term reliability for consumer use
  • TRIM support and wear leveling maintain consistent performance over the drive life
  • Low power management extends laptop battery runtime during mobile use

Patriot Burst Elite 480GB SATA SSD

The Patriot Burst Elite is a 2.5 inch internal solid state drive with 480GB of capacity. It uses a SATA III interface and TLC memory components for consumer workloads. The drive fits standard laptop and desktop bays that accept a 7.00mm z-height. No DRAM cache is present; the controller relies on Host Memory Buffer.

DRAM-less design with HMB and 7mm height

The DRAM-less architecture uses Host Memory Buffer to maintain responsive performance while keeping power draw low. A 7.00mm profile allows installation in thin ultrabooks as well as conventional 2.5 inch drive cages. SATA III connectors are the same ones used by mechanical drives, so no adapter or bracket is required. TRIM support and wear leveling help sustain write endurance over time.

400TB written endurance rating

The drive is rated for up to 400TB of total bytes written, a figure that reflects the TLC NAND and controller wear management. Sequential reads reach up to 450 MBps and writes up to 320 MBps. Random 4KB performance reaches 40,000 IOPS for both read and write. MTBF is quoted at greater than 2,000,000 hours.

Highlights

  • Up to 450 MB/s sequential read speeds accelerate boot and load times
  • 400 TBW endurance rating supports heavy daily write workloads
  • 2,000,000 hour MTBF indicates long-term reliability for consumer use
  • TRIM support and wear leveling maintain consistent performance over the drive life
  • Low power management extends laptop battery runtime during mobile use

Specifications

BrandPatriot
SeriesBurst Elite
ModelPBE480GS25SSDR
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form Factor2.5"
Capacity480GB
Memory ComponentsTLC
InterfaceSATA III
CacheNo DRAM (HMB)
Max Sequential ReadUp to 450 MBps
Max Sequential WriteUp to 320 MBps
4KB Random ReadUp to 40,000 IOPS
4KB Random WriteUp to 40,000 IOPS
MTBF>2,000,000 Hours
FeaturesTBW: up to 400TB
Latest SATA 3 controller
Static and Dynamic Wear Leveling
Bad Block Management
Low Power Management
TRIM Support
Smart ZIP
Operating Temperature0°C ~ +70°C
Height7.00mm
Width69.00mm
Depth100.00mm
Weight46.00g
Shipping weight0.05 kg
Package size178 × 133 × 13 mm

Other versions of this model

1 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What practical throughput does the SATA III interface cap this drive at?

The SATA III link limits real-world transfer to the drive's rated 450 MBps sequential read and 320 MBps sequential write.

What physical space and mounting points does the 2.5 inch form factor need?

It fits a standard 2.5 inch bay measuring 100.00 mm deep, 69.00 mm wide and 7.00 mm high, weighing 46.00 g.

How is the drive installed in a laptop or desktop, and which step is often missed?

Connect the SATA data and power cables, secure the drive with four screws, then enable TRIM in the OS so the controller can maintain write performance.
