Small green circuit board with black chips labeled 2TB M.2 2230 SSD

Patriot Memory

Patriot Memory VP4000M2TBM23 2TB M.2 2230 internal SSD

SKU CH-NSRY-73XS9 MPN VP4000M2TBM23

A 2 TB M.2 2230 NVMe drive with PCIe 4.0 x4 interface, up to 5000 MB/s read and 3500 MB/s write, DRAM cache, and no heatsink for handheld and ultrabook upgrades

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2230
  • Capacity2TB
  • InterfacePCI-Express 4.0 x4
  • ProtocolNVMe 1.4

Options 2TB Mini 2230

  • 2TB capacity stores more games and media on handhelds and ultrabooks
  • PCIe 4.0 x4 interface delivers up to 5000 MB/s sequential read speed
  • Up to 3500 MB/s sequential write accelerates game installs and file saves
  • 2GB DRAM cache sustains performance during heavy workloads
  • M.2 2230 form factor fits Steam Deck, ROG Ally and compatible laptops

Form factor and target devices

The VP4000M2TBM23 is a 2TB M.2 2230 NVMe SSD built for compact systems such as the Steam Deck, ASUS ROG Ally, MSI Claw and select ultrabooks. It uses a PCIe 4.0 x4 interface and NVMe 1.4 protocol to fit the short 2230 slot found in many handhelds and thin laptops.

Performance and power impact

Sequential reads reach up to 5000 MBps and writes up to 3500 MBps, while the 2GB DRAM cache helps sustain throughput during game loads and multitasking. The power-efficient design keeps draw low to extend battery life on portable devices.

Compatibility checks before ordering

Confirm the host device has an M.2 2230 slot wired for PCIe 4.0 x4 NVMe and that the firmware supports drives without a heatsink. Verify the physical length allowance, as some chassis only accept the shorter 2230 form factor.

Highlights

  • 2TB capacity stores more games and media on handhelds and ultrabooks
  • PCIe 4.0 x4 interface delivers up to 5000 MB/s sequential read speed
  • Up to 3500 MB/s sequential write accelerates game installs and file saves
  • 2GB DRAM cache sustains performance during heavy workloads
  • M.2 2230 form factor fits Steam Deck, ROG Ally and compatible laptops

Specifications

BrandPatriot
SeriesVP4300 Mini
ModelVP4000M2TBM23
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2230
Capacity2TB
InterfacePCI-Express 4.0 x4
ProtocolNVMe 1.4
Cache2GB DRAM
Max Sequential ReadUp to 5000 MBps
Max Sequential WriteUp to 3500 MBps
HeatSinkwithout HeatSink
FeaturesBuilt with the latest PCIe Gen4 x4 controller, fully compliant with NVMe 1.4 and fully compatible with the Steam Deck and Asus ROG Ally, the Viper VP4000 Mini M.2 2230 PCIe Gen4 x4 SSD is the newest SSD from Viper Gaming. Featuring a 2230 form factor miniature design built for handheld gaming, the Viper VP4000 Mini utilizes SmartECC technology, thermal throttling abilities and support for SMART and TRIM command designed to deliver consistent and supreme performance for even the longest gaming marathons.
• Capacity: 1000GB
• Sequential Read (CDM): up to 5,000MB/s
• Sequential Write (C
Shipping weight0.05 kg
Package size133 × 102 × 0 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Does the 2 GB DRAM cache on the VP4300 Mini need any user maintenance or replacement over time?

The 2 GB DRAM cache is integrated into the controller and requires no user maintenance or replacement during the drive's lifespan.

Which limit appears first when the PCIe 4.0 x4 interface runs sustained workloads at up to 5000 MBps read?

Thermal limits appear first; the drive has no heatsink so the controller throttles to protect NAND during prolonged heavy transfers.

How much heat and noise does the M.2 2230 drive produce when running all day in a Steam Deck?

Zero noise because there are no moving parts; heat is moderate but noticeable since the drive ships without a heatsink and relies on the device's own cooling.
