Thin green circuit board M.2 2280 SSD no heatsink

Patriot Memory

Patriot Memory VP4300L1TBM28H 1TB internal SSD

SKU CH-4ZTR-ZJWNX MPN VP4300L1TBM28H

1 TB M.2 2280 internal SSD with PCIe 4.0 x4 interface, NVMe 2.1 support and up to 7,400 MB/s sequential read speed

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity1TB
  • InterfacePCI-Express 4.0 x4
  • ProtocolNVMe 2.0

Options 1TB

  • Up to 7,400 MB/s sequential read for fast load times
  • Up to 6,400 MB/s sequential write for quick file saves
  • PCIe 4.0 x4 interface enables high-bandwidth data transfer
  • NVMe 2.0 compliant for broad system compatibility
  • PS5 compatible with up to 6,100 MB/s read performance

1TB PCIe 4.0 x4 NVMe Drive

The Patriot Memory VP4300L1TBM28H is a 1TB internal solid-state drive built for consumers who need fast storage in a standard M.2 2280 form factor. It uses a PCIe Gen4 x4 interface with NVMe 2.0 protocol to deliver sequential reads up to 7400 MBps and writes up to 6400 MBps. The drive is validated for both PC and PlayStation 5 platforms.

Installation and Common Issues

The drive fits any M.2 2280 slot keyed for PCIe 4.0 x4 and requires no heatsink bracket because it ships without an integrated heatsink. Most installation problems come from motherboard BIOS versions that do not yet support NVMe 2.1 or from missing the PS5 system software update needed to recognise the drive. Ensure the retaining screw is the correct M2 length to avoid board stress.

PCIe Gen4 x4 Practical Limits

The PCIe 4.0 x4 interface caps theoretical throughput at roughly 8 GBps, so the 7400 MBps read figure sits near the bus ceiling. Real-world speeds drop when the controller manages heavy mixed workloads or when thermal throttling activates on the bare PCB. The PS5 environment further limits reads to about 6100 MBps because the console reserves bandwidth for system operations.

NVMe 2.0 and 2.1 Compliance

The drive complies with NVMe 2.0 and 2.1 specifications, enabling features such as namespace management and improved power-state transitions. Older platforms that only implement NVMe 1.x will still run the drive but cannot use the newer command-set extensions. Firmware updates from Patriot may add future namespace or endurance enhancements.

Highlights

  • Up to 7,400 MB/s sequential read for fast load times
  • Up to 6,400 MB/s sequential write for quick file saves
  • PCIe 4.0 x4 interface enables high-bandwidth data transfer
  • NVMe 2.0 compliant for broad system compatibility
  • PS5 compatible with up to 6,100 MB/s read performance

Specifications

BrandPatriot
SeriesVP4300 Lite
ModelVP4300L1TBM28H
Part NumberVP4300L1TBM28H
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity1TB
InterfacePCI-Express 4.0 x4
ProtocolNVMe 2.0
ConnectorPCIe
Cache1 unknown_modifier
Max Sequential ReadUp to 7400 MBps
Max Sequential WriteUp to 6400 MBps
HeatSinkwithout HeatSink
FeaturesBuilt with the latest PCIe Gen x controller, fully compliant with NVMe . and fully compatible with both PCs and the Playstation , the VP Lite is the latest in Viper Gamings high-performance solid state drive line. Featuring Viper Gamings newest DRAMLESS design, gamers can anticipate sharp performance with the VP Lites host memory buffer support and Toggle and ONFi mode Flash support for double data rates up to , MTs. Alongside its Seq. Read speeds up to , MBs, Seq. Write speeds up to , MBs, PS sequential read speeds up to , MBs and , TBW, the VP Lite will blow away the competition ev
Height500.0 in x 500.0 in x 280.0 in
Width500.0 in x 500.0 in x 280.0 in
Depth500.0 in x 500.0 in x 280.0 in
Weight9 grams
Package Content1 x VP4300 Lite SSD
Shipping weight0.23 kg
Package size140 × 108 × 38 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Does this drive fit a standard M.2 2280 slot in a laptop or desktop motherboard?

Yes, the drive uses the M.2 2280 form factor, which is the common size for most modern laptop and desktop M.2 slots.

Will it work in a PlayStation 5 without an additional heatsink?

The drive is listed as PS5 compatible and includes an ultra-thin graphene cooling heat spreader, so no separate heatsink is required for the console's expansion slot.

What sequential read and write speeds can I expect on a PC with a PCIe 4.0 x4 slot?

Up to 7,400 MB/s read and 6,400 MB/s write as measured by CrystalDiskMark on a PCIe 4.0 x4 interface.
