Qnap
Qnap TVS-h674-i3-16G-US 6-bay NAS i3-12100 16GB DDR4
Six-bay desktop NAS with Intel Core i3-12100 processor, 16GB DDR4 memory, dual 2.5GbE ports and two M.2 PCIe Gen4 slots
- TypeDesktop NAS
- Port RJ-452 x 2.5 GbE
- Port USB1 x Type-C USB 3.2 Gen 2 10Gbps 2 x Type-A USB 3.2 Gen 2 10G
- HDD Interface6 x SATA (6 x Bay)
- Form Factor6-Bay
- ProcessorIntel® Core™ i3-12100 4-core/8-thread Processor, burst up to
- Quad-core i3-12100 up to 4.3 GHz for responsive multi-tasking
- 16 GB DDR4 pre-installed, expandable to 64 GB for larger workloads
- Six drive bays support up to 132 TB of SATA storage
- Two M.2 PCIe Gen4 slots accelerate caching with NVMe SSDs
- Dual 2.5 GbE ports plus USB 3.2 Gen 2 Type-C and Type-A for fast connectivity
Purpose and audience
The Qnap TVS-h674-i3-16G-US is a six-bay desktop NAS built around an Intel Core i3-12100 processor with four cores and eight threads. It ships with 16 GB of DDR4 memory installed and supports up to 64 GB across two SODIMM slots. The platform targets small businesses and creative teams that need ZFS-based data integrity, inline deduplication and near-limitless snapshots for file serving, virtualization or collaborative video editing.
Build, connectors and daily use
The chassis accepts six 3.5-inch or 2.5-inch SATA drives and provides two M.2 PCIe Gen 4 slots for NVMe caching. Front-panel LEDs show status for each drive bay, LAN, USB and M.2 devices. Networking consists of two 2.5 GbE RJ-45 ports, while external expansion uses one USB 3.2 Gen 2 Type-C and two Type-A ports, all at 10 Gbps. An HDMI 1.4b output and PCIe Gen 4 slots allow display or add-in card flexibility.
Thermals, noise and power
Operating temperature range is 0 to 40 °C with 5 to 95 % non-condensing humidity. Typical power draw with a full set of drives is 79.363 W, dropping to 39.911 W when the disks are in sleep mode. The 250 W internal supply handles 100 to 240 V input. Buyers who need more than six drive bays or 10 GbE networking built in will need a different platform.
Highlights
- Quad-core i3-12100 up to 4.3 GHz for responsive multi-tasking
- 16 GB DDR4 pre-installed, expandable to 64 GB for larger workloads
- Six drive bays support up to 132 TB of SATA storage
- Two M.2 PCIe Gen4 slots accelerate caching with NVMe SSDs
- Dual 2.5 GbE ports plus USB 3.2 Gen 2 Type-C and Type-A for fast connectivity
Specifications
| Brand | QNAP |
|---|---|
| Series | Ultra-High Speed 6 Bay NAS |
| Model | Ultra-High Speed 6 Bay NAS |
| Part Number | TVS-h674-i3-16G-US |
| Type | Desktop NAS |
| Port RJ-45 | 2 x 2.5 GbE |
| Port USB | 1 x Type-C USB 3.2 Gen 2 10Gbps 2 x Type-A USB 3.2 Gen 2 10Gbps |
| HDD Interface | 6 x SATA (6 x Bay) |
| Form Factor | 6-Bay |
| Processor | Intel® Core™ i3-12100 4-core/8-thread Processor, burst up to 4.3 GHz |
| Installed Memory | 16GB |
| Max Memory Capacity | 64GB |
| Memory Slot | 2 x DDR4 SODIMM |
| Included HDD Capacity | Diskless System |
| Max Capacity | 132TB |
| Drive Compatibility | 3.5" SATA HDD 2.5" SATA SSD |
| LEDs | HDD 1-6, Status, LAN, USB port, M.2 port |
| Power | 250W, 100-240V |
| Power Consumption | Power Consumption: HDD Sleep Mode 39.911 W Power Consumption: Operating Mode, Typical 79.363 W Tested fully populated with WD10EFRX hard drives. |
| Temperature | Operating Temperature: 0 - 40 °C (32°F - 104°F) Storage Temperature: -20 - 70°C (-4°F - 158°F) |
| Humidity | 5-95% RH non-condensing, wet bulb: 27°C (80.6°F) |
| Usage | Backup & stream media through personal cloud |
| Dimensions | 7.41 × 10.41 × 11.06 inch |
| Weight | Weight (Net): 13.93 lbs Weight (Gross): 17.39 lbs |
| Shipping weight | 8.62 kg |
| Package size | 330 × 305 × 229 mm |
Questions about this item
What speed does the 2.5GbE port actually cap at for file transfers?
Each RJ-45 port runs at 2.5 GbE, so sustained throughput tops out around 2.5 Gbps per connection.
Which drive sizes and tray count does the chassis accept?
Six hot-swap bays take 3.5" SATA HDDs or 2.5" SATA SSDs, no caddies needed.
How do I add RAM and what slot mistake should I avoid?
Open the case, insert DDR4 SODIMM modules into the two slots; populate both channels for dual-channel performance.
