Black rectangular network video recorder with sixteen front PoE ports and 4TB drive installed

Reolink

Reolink RLN16-410 16CH PoE NVR 4TB

SKU CH-XGV5-KHEE3

A 16-channel PoE recorder with a pre-installed 4 TB drive that works only with Reolink cameras

  • Channel16 Channel
  • Supported ProtocolsHTTP, TCP/IP, UDP, DHCP, P2P, UPNP, RTSP, SMTP, SSL/TLS, DNS
  • Network Interface• 1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
  • Ports2 x USB 2.0; 2 x SATA interface (1 x Seagate 3TB HDD include
  • Video InputPoE IP Camera x 16
  • Video OutputVGA, HDMI

Channels 16 Channel

Options 4 TB

  • 16-channel PoE recorder with pre-installed 4 TB storage
  • Plug-and-play single-cable power and data up to 330 ft
  • Works exclusively with Reolink IP cameras for full feature integration
  • Local recording and live view without internet connection
  • Free Reolink app and client for remote access on iOS, Android, Windows, Mac

16-channel PoE NVR with 4 TB storage

The Reolink RLN16-410 is a 16-channel network video recorder designed for home or small-business surveillance. It arrives with a pre-installed 4 TB hard drive and supports only Reolink PoE and DC-powered Wi-Fi cameras. The unit provides 16 dedicated PoE ports plus one gigabit uplink for LAN or WAN connectivity.

Capacity and recording headroom

The built-in 4 TB drive stores continuous 24/7 footage from up to 16 cameras. Total internal capacity can reach 12 TB using the two SATA bays, each accepting a maximum 6 TB drive. When all channels record at high bit-rates the 4 TB baseline fills quickly, so additional drives are needed for longer retention.

Reolink-only camera compatibility

This recorder works exclusively with Reolink IP cameras; third-party models are not supported. Buyers who already own other-brand cameras or who need ONVIF flexibility cannot use this NVR.

Highlights

  • 16-channel PoE recorder with pre-installed 4 TB storage
  • Plug-and-play single-cable power and data up to 330 ft
  • Works exclusively with Reolink IP cameras for full feature integration
  • Local recording and live view without internet connection
  • Free Reolink app and client for remote access on iOS, Android, Windows, Mac

Specifications

BrandReolink
SeriesReolink 16Ch 4K PoE NVR
ModelRLN16-410-4T
Channel16 Channel
Supported ProtocolsHTTP, TCP/IP, UDP, DHCP, P2P, UPNP, RTSP, SMTP, SSL/TLS, DNS, DDNS, NTP, FTP
Network Interface• 1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface for LAN/WAN • 16, RJ-45 10/100 Mbps self-adaptive PoE Ethernet interface for IP camera
Ports2 x USB 2.0; 2 x SATA interface (1 x Seagate 3TB HDD included)
Video InputPoE IP Camera x 16
Video OutputVGA, HDMI
Audio InputCameras with built-in mic
Compression FormatH.265, H.264
Recording TypeVideo Recorder
RemoteReolink App/Clents; Edge, Firefox, Chrome, Safari
Storage InstalledBuilt-in 4TB; Up to 12TB (Max. 6TB capacity for each HDD)
Operating SystemPC: Windows, Mac OS; Smartphone: iOS, Android
Power SupplyInput 100~240V, 48V 2.5A
Temperature-10°C~+55°C (14°F~131°F)
Humidity10%~90%
Dimensions330 x 45 x 285mm
Weight2.4kg

Other versions of this model

2 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Will this NVR connect to my existing Reolink PoE cameras that are 4K or 5MP?

The RLN16-410 supports all Reolink PoE cameras at 16MP, 12MP, 4K, 5MP and 4MP resolutions across its 16 PoE ports.

How can I confirm the NVR is recording continuously after I connect the cameras?

The front panel shows HDD status and recording indicators; the Reolink App or Client displays live playback and 24/7 timeline bars for each of the 16 channels.

Does the box include the hard drive and cables, or must I buy them separately?

A 4TB drive is pre-installed; the package also contains the 48V 2.5A power supply, a mouse and a quick-start guide. Extra SATA drives up to 6TB each are optional.
