Rectangular silver 2.5 inch SSD with label showing Samsung 870 EVO 500GB

SAMSUNG

SAMSUNG 870 EVO 500GB 2.5" SATA III internal SSD MZ-77E500B/AM

SKU CH-REM3-29D93 MPN MZ-77E500B/AM

A 500 GB 2.5-inch SATA III internal SSD with V-NAND, 512 MB DDR4 cache, AES 256 encryption and sequential speeds up to 560 MB/s read and 530 MB/s write

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form Factor2.5"
  • Capacity500GB
  • Memory ComponentsV-NAND
  • InterfaceSATA III

Options 500GB

  • Professional speeds up to 560 MB/s read
  • Sustained writes to 530 MB/s with larger buffer
  • Hardware AES 256 encryption protects data
  • 5 million hours MTBF for long life
  • 512 MB DDR4 cache boosts responsiveness

Samsung 870 EVO 500GB SATA SSD

The Samsung 870 EVO is a 500GB internal solid state drive built for consumer desktops and laptops. It uses V-NAND memory and a 512MB low-power DDR4 cache to deliver reliable everyday performance. The 2.5-inch form factor fits standard SATA drive bays. AES 256-bit hardware encryption with TCG Opal 2.0 and IEEE 1667 support protects stored data.

SATA III interface at 560 MBps read

The drive connects through the SATA III interface, reaching up to 560 MBps sequential read and 530 MBps sequential write. These speeds saturate the SATA bus, making the interface the limiting factor for throughput. The 512MB cache helps sustain write performance during large file transfers. Compatibility testing covers major chipsets, motherboards, NAS units and video recorders.

Sustained workloads with 2,400 TBW endurance

Under continuous use the 870 EVO is rated for 2,400 TBW, reflecting its ability to handle heavy write workloads such as 8K video processing. Average active power draw is 2.2W with a 3.5W maximum, while idle consumption drops to 30 mW. MTBF of 1,500,000 hours and 1500G shock resistance support long-term reliability in demanding environments.

Highlights

  • Professional speeds up to 560 MB/s read
  • Sustained writes to 530 MB/s with larger buffer
  • Hardware AES 256 encryption protects data
  • 5 million hours MTBF for long life
  • 512 MB DDR4 cache boosts responsiveness

Specifications

BrandSAMSUNG
Series870 EVO Series
ModelMZ-77E500B/AM
Part NumberMZ-77E500B/AM
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form Factor2.5"
Capacity500GB
Memory ComponentsV-NAND
InterfaceSATA III
ProtocolSATA
CacheSamsung 512MB Low Power DDR4 SDRAM
EncryptionClass 0 (AES 256) TCG/Opal v2.0, MS eDrive (IEEE1667)
Max Sequential ReadUp to 560 MBps
Max Sequential WriteUp to 530 MBps
MTBF1,500,000 hours
FeaturesTHE SSD ALL-STAR - The latest 870 EVO has indisputable performance, reliability and compatibility built upon Samsung's pioneering technology.
EXCELLENCE IN PERFORMANCE - Enjoy professional-level SSD performance with 870 EVO, which maximizes the SATA interface limit to 560/530 MB/s sequential speeds, accelerates write speeds and maintains long-term high performance with a larger variable buffer.
INDUSTRY-DEFINING RELIABILITY - Meet the demands of every task - from everyday computing to 8K video processing, with up to 300 TBW.
MORE COMPATIBLE THAN EVER - 870 EVO has been compatibility
Power Consumption (Idle)Max. 30 mW
Power Consumption (Active)Average: 2.2W
Maximum: 3.5W
Max Shock Resistance1500G
Height7.00mm
Width69.85mm
Depth100.00mm
Weight86.18g
Shipping weight0.09 kg
Package size146 × 98 × 24 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What does the 560 MBps sequential read speed mean once the drive is installed in my laptop?

It means the drive can sustain read transfers at the SATA III interface ceiling, so large files and boot sequences load at the maximum pace the 6 Gbps link allows.

How does the SATA III interface cap real-world performance?

SATA III tops out at 6 Gbps, so the 560/530 MBps sequential figures are the practical limit; the drive reaches that ceiling and cannot exceed it.

What physical space and connectors does the 2.5-inch 500GB model need to fit?

It fits a standard 2.5-inch drive bay with a SATA data and power connector, using 7 mm z-height and the same mounting holes as a notebook hard drive.
