Small green M.2 2280 circuit board with black controller and silver label

SanDisk

SanDisk WDS250G1R0C Red SN700 NVMe 250GB internal SSD

SKU CH-HXTM-SAS0R MPN WDS250G1R0C

An M.2 2280 internal SSD delivering up to 3100 MBps read and 1600 MBps write with 500 TBW endurance for NAS caching

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity250GB
  • InterfacePCI-Express 3.0 x4
  • Max Sequential ReadUp to 3100 MBps

Options 250GB

  • NVMe caching accelerates NAS responsiveness with up to 3100 MBps sequential read
  • High endurance sustains heavy workloads through 500 TBW and 1,750,000 hours MTTF
  • PCIe 3.0 x4 interface delivers up to 220,000 IOPS random read for multi-user tasks
  • Low 70 mW idle power reduces heat in always-on NAS enclosures
  • M.2 2280 form factor fits standard NAS slots for easy capacity scaling

250GB NVMe cache drive for NAS

The SanDisk WDS250G1R0C is a 250GB internal SSD built for network-attached storage. It uses the M.2 2280 form factor and a PCI-Express 3.0 x4 interface. The drive targets small-to-medium business workloads such as virtualization, collaborative editing and multi-user databases.

Upgrade from SATA SSD caching

This NVMe SSD replaces a SATA cache device to deliver higher I/O performance and lower latency. Sequential reads reach up to 3100 MBps and writes up to 1600 MBps. Random reads hit 220000 IOPS and writes 180000 IOPS. The jump is worth it when your NAS serves many simultaneous users or runs latency-sensitive applications.

Fits M.2 2280 slots with PCIe 3.0 x4

The drive slots directly into a compatible M.2 2280 connector wired for PCI-Express 3.0 x4. Endurance is rated at 500TB written and MTTF at 1750000 hours. Idle power draw is 70 mW. Operating temperatures range from 0°C to 70°C, while storage temperatures span -55°C to 85°C.

Highlights

  • NVMe caching accelerates NAS responsiveness with up to 3100 MBps sequential read
  • High endurance sustains heavy workloads through 500 TBW and 1,750,000 hours MTTF
  • PCIe 3.0 x4 interface delivers up to 220,000 IOPS random read for multi-user tasks
  • Low 70 mW idle power reduces heat in always-on NAS enclosures
  • M.2 2280 form factor fits standard NAS slots for easy capacity scaling

Specifications

BrandWestern Digital
SeriesRed SN700 NVMe
ModelWDS250G1R0C
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity250GB
InterfacePCI-Express 3.0 x4
Max Sequential ReadUp to 3100 MBps
Max Sequential WriteUp to 1600 MBps
4KB Random ReadUp to 220,000 IOPS
4KB Random WriteUp to 180,000 IOPS
Terabytes Written (TBW)500TB
MTTF1,750,000 hours
FeaturesAccelerate Your NAS
The fast-caching power of the WD Red SN700 NVMe SSD delivers robust system responsiveness and exceptional I/O performance compared to our SATA SSDs.
Step Up to NVMe
Tame your SMB's toughest projects - from virtualization to collaborative editing to intensive database storage with efficient caching - with storage designed to outperform while helping to lower your TCO.
Perfect for SMBs
Even in smaller operations, multiple people working at the same time can tax a NAS device. NVMe caching easily handles random workloads in multi-user, multitasking applications to let
Power Consumption (Idle)70 mW
Operating Temperature0°C ~ +70°C
Storage Temperature-55°C ~ +85°C
Width22.00mm
Depth80.00mm
Weight7.50g
Shipping weight0.05 kg
Package size127 × 102 × 20 mm

Other versions of this model

4 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Does the M.2 2280 form factor fit my NAS slot?

The drive is an M.2 2280 module measuring 22.00 mm wide and 80.00 mm long, matching the standard slot found in compatible NAS devices.

How do I install the PCI-Express 3.0 x4 drive, and what step is often missed?

Align the notched edge with the M.2 key, insert the drive, then secure it with the retention screw; the missed step is forgetting that screw, which leaves the drive unseated.

When will the 500 TBW endurance rating require replacement?

The drive is rated for 500 terabytes written; replacement depends on your actual write volume, which the NAS SMART tools can track over time.
