Green M.2 2280 circuit board with gold edge connector and black controller chip

SanDisk

SanDisk WDS500G1R0C-68BDK0 500GB NVMe internal SSD

SKU CH-JAAE-DG9WC MPN WDS500G1R0C-68BDK0

An M.2 2280 NVMe SSD with 500GB capacity, 3430 MBps read and 2600 MBps write speeds for NAS workloads

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity500GB
  • InterfacePCI-Express 3.0 x4
  • Max Sequential ReadUp to 3430 MBps

Options 500GB

  • Accelerate NAS caching with PCIe 3.0 x4 NVMe speed
  • Sequential reads up to 3430 MBps for fast data access
  • Sequential writes up to 2600 MBps to handle heavy workloads
  • 420,000 random read IOPS for responsive multi-user performance
  • 1000 TBW endurance rating for long-term reliability

500GB NVMe SSD for NAS caching

The SanDisk WD Red SN700 is a 500GB internal solid-state drive built for network-attached storage. It uses an M.2 2280 form factor and connects through a PCI-Express 3.0 x4 interface. The drive targets small-business and enthusiast NAS appliances that need fast caching tiers.

Suits multi-user NAS workloads.

This SSD suits environments running virtualization, collaborative editing or heavy multi-user file access where high random I/O matters. It is less appropriate for a single-user desktop boot drive where sustained write endurance and NAS-specific firmware validation are not required.

M.2 2280 slot with PCIe 3.0 x4; frees 2.5-inch bays

Installation requires an M.2 2280 slot wired for PCIe 3.0 x4 and operates between 0°C and 70°C. Idle power draw is 70 mW. The compact stick layout frees traditional 2.5-inch drive bays for additional mechanical storage capacity.

Highlights

  • Accelerate NAS caching with PCIe 3.0 x4 NVMe speed
  • Sequential reads up to 3430 MBps for fast data access
  • Sequential writes up to 2600 MBps to handle heavy workloads
  • 420,000 random read IOPS for responsive multi-user performance
  • 1000 TBW endurance rating for long-term reliability

Specifications

BrandWestern Digital
SeriesRed SN700 NVMe
ModelWDS500G1R0C
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity500GB
InterfacePCI-Express 3.0 x4
Max Sequential ReadUp to 3430 MBps
Max Sequential WriteUp to 2600 MBps
4KB Random ReadUp to 420,000 IOPS
4KB Random WriteUp to 380,000 IOPS
Terabytes Written (TBW)1000TB
MTTF1,750,000 hours
FeaturesAccelerate Your NAS
The fast-caching power of the WD Red SN700 NVMe SSD delivers robust system responsiveness and exceptional I/O performance compared to our SATA SSDs.
Step Up to NVMe
Tame your SMB's toughest projects - from virtualization to collaborative editing to intensive database storage with efficient caching - with storage designed to outperform while helping to lower your TCO.
Perfect for SMBs
Even in smaller operations, multiple people working at the same time can tax a NAS device. NVMe caching easily handles random workloads in multi-user, multitasking applications to let
Power Consumption (Idle)70 mW
Operating Temperature0°C ~ +70°C
Storage Temperature-55°C ~ +85°C
Width22.00mm
Depth80.00mm
Weight7.50g
Shipping weight0.05 kg
Package size127 × 102 × 20 mm

Other versions of this model

4 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What M.2 slot key and PCIe generation does my motherboard need for this WDS500G1R0C-68BDK0 drive?

The drive uses an M.2 2280 form factor with a PCI-Express 3.0 x4 interface, so the slot must support that key and generation.

Will this 500GB NVMe SSD work in a NAS that currently runs SATA SSDs?

Yes, it is purpose-built and tested for popular NAS systems and delivers higher I/O performance than SATA SSDs.

How can I confirm the drive is delivering its rated sequential speeds after installation?

Run a sequential read/write benchmark such as CrystalDiskMark and check that results approach 3430 MBps read and 2600 MBps write.
