Blue M.2 2280 NVMe SSD with black circuit board and silver label

SanDisk

SanDisk WDS400T4B0E-00BKY0 4TB internal SSD

SKU CH-NTKR-PQ0F9 MPN WDS400T4B0E-00BKY0

M.2 2280 NVMe drive stores 4 TB with sequential reads up to 5500 MB/s and 1200 TBW endurance

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity4TB
  • InterfacePCIe Gen4 16GT/s, up to 4 Lanes
  • CacheNo DRAM (HMB)

Style Faster

Options 4TB

  • Holds large projects with 4TB capacity
  • Reads files fast at up to 5500 MBps
  • Writes data quickly at up to 5000 MBps
  • High endurance rating of 1200 TBW
  • Runs efficiently with 75mW average active power

4TB M.2 NVMe SSD for creators

The SanDisk WDS400T4B0E-00BKY0 is a 4TB internal solid-state drive built for consumer workloads. It fits the M.2 2280 slot and connects through a PCIe Gen4 x4 interface. The drive targets users who need large capacity for creative projects and everyday multitasking.

PCIe Gen4 x4 interface with HMB

The single specification that decides compatibility is the PCIe Gen4 16GT/s interface operating across four lanes. The controller uses host memory buffer technology instead of on-board DRAM. This design works with any motherboard that provides an M.2 key-M slot wired for PCIe 4.0 or 3.0 operation.

4TB capacity with 1200 TBW endurance

The 4TB volume holds extensive media libraries, project files and applications. Rated endurance of 1200 TBW supports heavy write workloads such as video editing and large dataset processing. Sequential reads reach 5500 MBps and writes reach 5000 MBps, while random performance hits 690000 read IOPS and 900000 write IOPS.

Highlights

  • Holds large projects with 4TB capacity
  • Reads files fast at up to 5500 MBps
  • Writes data quickly at up to 5000 MBps
  • High endurance rating of 1200 TBW
  • Runs efficiently with 75mW average active power

Specifications

BrandWestern Digital
SeriesBlue SN5000 NVMe
ModelWDS400T4B0E
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity4TB
InterfacePCIe Gen4 16GT/s, up to 4 Lanes
CacheNo DRAM (HMB)
Max Sequential ReadUp to 5500 MBps
Max Sequential WriteUp to 5000 MBps
4KB Random ReadUp to 690,000 IOPS
4KB Random WriteUp to 900,000 IOPS
Terabytes Written (TBW)1200TB
MTBF1,750,000 hours
FeaturesCreate and store more - Hold more masterpieces and enjoy endless inspiration with up to 4TB capacity.
Boost your creative workflow - Harness AI and streamline your creative workflow with the combined power of PCIe Gen 4, up to 5,500MB/s read speeds (4TB model), and Western Digital nCache 4.0 Technology.
Multitask like a pro - Switch smoothly between applications and projects with high-end NVMe storage technology.
Endurance for intense workloads - Create confidently with up to 1,200TBW (4TB model) endurance for ideating, drafting, and finalizing your creative work.
Free Acronis True I
Power Consumption (Idle)(Sleep) PS5: 5mW
Power Consumption (Active)Average Active Powe: 75mW
Operating Temperature32°F to 185°F (0°C to 85°C)
Storage Temperature-40°F to 185°F (-40°C to 85°C)
Max Shock Resistance1,500G @0.5 ms half sine
Max Vibration ResistanceOperating Vibration: 5 gRMS, 10-2000 Hz, 3 axes
Non-operating Vibration: 4.9 gRMS, 7-800 Hz, 3 axes
Height2.38mm
Width22 +/- 0.15mm
Depth80 +/- 0.15mm
Weight5.7g +/- 0.5g
Shipping weight0.05 kg
Package size127 × 102 × 25 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How does the 5500 MBps sequential read figure translate to everyday use?

The 5500 MBps sequential read speed means large files such as video projects or game assets load quickly when the drive is installed in a PCIe Gen4 M.2 slot.

What does the PCIe Gen4 x4 interface cap at in practice?

The PCIe Gen4 x4 interface supports up to 5500 MBps read and 5000 MBps write, with 690000 IOPS random read and 900000 IOPS random write.

What physical slot and form factor does the 4TB model need to fit?

The drive uses the M.2 2280 form factor and requires an M.2 slot keyed for PCIe NVMe.
