Green circuit board M.2 2280 SSD with black heatsink attached

Seagate

Seagate FireCuda 530 2TB internal SSD ZP2000GM3A023

SKU CH-BWTG-HDJ1Q MPN ZP2000GM3A023

M.2 2280 2TB internal SSD with included heatsink delivers up to 7300 MBps sequential read and 6900 MBps write for high-end gaming and content creation

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity2TB
  • Memory Components3D TLC
  • InterfacePCIe Gen4 x4 NVMe 1.4

Options 2TB w/ Heatsink

  • Faster game loads with up to 7300 MBps sequential read
  • Sustained write performance up to 6900 MBps for content creation
  • Responsive multitasking from 1,000,000 IOPS random read and write
  • Long-term reliability backed by 1,800,000 hours MTBF
  • Cooler operation under load with included heatsink

Capacity and interface

The Seagate FireCuda 530 ZP2000GM3A023 is a 2TB internal SSD built on the M.2 2280 form factor with a PCIe Gen4 x4 NVMe 1.4 interface. It uses 3D TLC memory and has no separate cache. The drive targets consumers who need sustained high throughput for gaming and content creation workloads.

Compatibility check

Verify that your motherboard provides an M.2 slot wired for PCIe Gen4 x4 and that the BIOS supports NVMe 1.4 boot devices. The module includes a heatsink, so confirm adequate clearance around the slot and that the board mounting standoff matches the 2280 length. Ensure your operating system includes an NVMe driver for full performance.

Build and daily use

The integrated heatsink helps maintain lower temperatures during extended transfers, supporting consistent sequential reads up to 7300 MBps and writes up to 6900 MBps. Random 4KB performance reaches 1000000 IOPS for both read and write. An MTBF of 1800000 hours and the 3D TLC design indicate high endurance for heavy daily workloads.

Highlights

  • Faster game loads with up to 7300 MBps sequential read
  • Sustained write performance up to 6900 MBps for content creation
  • Responsive multitasking from 1,000,000 IOPS random read and write
  • Long-term reliability backed by 1,800,000 hours MTBF
  • Cooler operation under load with included heatsink

Specifications

BrandSeagate
SeriesFireCuda 530
ModelZP2000GM3A023
Part NumberZP2000GM3A023
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity2TB
Memory Components3D TLC
InterfacePCIe Gen4 x4 NVMe 1.4
ProtocolNVMe 1.4
Cache0MB
Max Sequential ReadUp to 7300 MBps
Max Sequential WriteUp to 6900 MBps
4KB Random ReadUp to 1,000,000 IOPS
4KB Random WriteUp to 1,000,000 IOPS
MTBF1,800,000 hours
HeatSinkwith HeatSink
FeaturesSpeed Reigns. FireCuda 530 dominates the SSD lineup - delivering pure performance, absolute power, the most advanced components, and unrivaled endurance.
Absolute Performance. At up to 7,300MB/s you can harness the full power of PCIe Gen4 speeds to dominate next-generation games and applications.
Cool Speed Ahead Heatsink technology keeps things cooler to maintain performance longer.
Fastest. FireCuda. Ever. Built for sustained, pro-level gaming and accelerated content creation with transfer speeds up to 2x faster than PCIe Gen3 NVMe SSDs and up to 12x faster than SATA SSDs.
Latest T
Power Consumption (Idle)24 mW
Power Consumption (Active)8.0W
Operating Temperature0°C ~ +70°C
Storage Temperature-40°C ~ +85°C
Max Shock Resistance1500G
Height10.39mm
Width24.20mm
Depth80.15mm
Weight47.00g
Shipping weight0.09 kg
Package size157 × 109 × 28 mm

Other versions of this model

4 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Does the FireCuda 530 2TB ZP2000GM3A023 include the heatsink in the box or must it be purchased separately?

The drive ships with the heatsink already attached, so no separate purchase is needed.

Which capacity of the FireCuda 530 line should I choose if I want the 7300 MBps sequential read speed shown in the specifications?

The 2TB model ZP2000GM3A023 delivers up to 7300 MBps sequential read and 6900 MBps sequential write.

What does the 7300 MBps headline figure mean for real-world game loading on a PCIe Gen4 motherboard?

On a PCIe Gen4 x4 slot the drive can reach 7300 MBps sequential read, cutting large game load times versus Gen3 drives.
