Silver 3.5-inch internal hard drive with silver label and exposed circuit board

Seagate

Seagate ST24000NT002 IronWolf Pro 24TB 7200 RPM 512MB SATA 3.5" internal hard drive

SKU CH-CCNG-3VTVF MPN ST24000NT002

24 TB CMR drive built for 24/7 NAS RAID workloads with 550 TB/year rating and 512 MB cache

  • InterfaceSATA 6.0Gb/s
  • Capacity24TB
  • Recording TechnologyCMR
  • RPM7200 RPM
  • Cache512MB
  • FeaturesOptimized for NAS with AgileArray AgileArray uses dual-plane

Options 24TB

  • 24 TB capacity for massive NAS storage
  • 7200 RPM and 512 MB cache deliver fast 24x7 performance
  • CMR recording technology ensures consistent write speeds
  • AgileArray with RV sensors optimises RAID reliability in multi-bay systems
  • 550 TB yearly workload rating and 2.5 M hours MTBF for enterprise endurance

24 TB CMR NAS drive

This 24 TB hard drive uses conventional magnetic recording and a 7200 RPM spindle to serve multi-bay NAS enclosures. A 512 MB cache and AgileArray firmware with dual-plane balancing and TLER keep RAID arrays responsive. The SATA 6.0 Gb/s interface fits standard 3.5 inch drive bays in commercial and enterprise storage servers.

Sustained 24x7 workload rating

Rated for 550 TB per year, the drive is built for continuous operation rather than burst transfers. Rotational vibration sensors and time-limited error recovery maintain consistent throughput across all bays during heavy multi-user loads. The 2.5 million hour MTBF figure reflects design targets for always-on environments.

Check bay count and controller

Verify that your NAS chassis has enough 3.5 inch bays and that the RAID controller or HBA supports SATA 6.0 Gb/s links. Confirm the system can supply adequate cooling for a 26.11 mm high drive running at 7200 RPM. Ensure your backup strategy accounts for the 24 TB capacity before deploying in a production array.

Highlights

  • 24 TB capacity for massive NAS storage
  • 7200 RPM and 512 MB cache deliver fast 24x7 performance
  • CMR recording technology ensures consistent write speeds
  • AgileArray with RV sensors optimises RAID reliability in multi-bay systems
  • 550 TB yearly workload rating and 2.5 M hours MTBF for enterprise endurance

Specifications

BrandSeagate
SeriesIronWolf Pro
ModelST24000NT002
Part NumberST24000NT002
InterfaceSATA 6.0Gb/s
Capacity24TB
Recording TechnologyCMR
RPM7200 RPM
Cache512MB
FeaturesOptimized for NAS with AgileArray AgileArray uses dual-plane balancing and time-limited error recovery (TLER) to deliver best-in-class RAID performance in multi-bay systems.
Always On, Always Accessible IronWolf Pro drives are designed for 24x7 performance, allowing users to access their data anytime, anywhere.
All-CMR Portfolio All IronWolf Pro drives utilize conventional magnetic recording (CMR) technology for consistent, best-in-class NAS performance.
Up to 32TB Broad range of high-performance capacity options to deliver scalable and costefficient storage solutions.
Built Tough Ir
UsageEnterprise NAS Hard Drives
Form Factor3.5"
Height (maximum)26.11mm
Width (maximum)101.85mm
Length (maximum)146.99mm
Shipping weight0.69 kg
Package size147 × 102 × 26 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How much noise and heat does the 7200 RPM mechanism generate during 24x7 operation?

The 7200 RPM CMR design is built for continuous 24x7 use with a 550 TB per year workload rating and 2.5 million hours MTBF, while AgileArray dual-plane balancing and RV sensors limit vibration and heat in multi-bay NAS.

What host interface and physical bay does the 3.5 inch SATA 6.0 Gb/s drive require?

It needs a standard 3.5 inch drive bay with a SATA 6.0 Gb/s data port and a SATA power connector; the drive measures 146.99 mm long, 101.85 mm wide and 26.11 mm high.

Will the AgileArray firmware and TLER work with an older RAID controller that expects enterprise drives?

Yes, AgileArray includes time-limited error recovery and rotational vibration sensors tuned for multi-bay RAID, so the drive responds correctly to legacy controllers expecting enterprise-class behaviour.
