SongryVGA Radeon RX 580 graphics card, dual-slot black metal shroud, single axial fan, six HDMI ports along the rear bracket

SongryVGA

SongryVGA SY586H42 Radeon RX 580 4GB GDDR5 6×HDMI 2.0 graphics card

SKU CH-DM0X-YV9DC

Radeon RX 580 4 GB GDDR5 card with six HDMI 2.0 outputs driving up to six 4K displays from an 80 W TDP and a single-fan cooler

  • InterfacePCI Express 3.0 x16
  • Chipset ManufacturerAMD
  • GPURadeon RX 580
  • Core Clock1244 MHz
  • Stream Processors2048
  • Effective Memory Clock1500 MHz

Memory Size 4 GB

  • Drives six 4K displays from six HDMI 2.0 ports
  • 4 GB GDDR5 on a 256-bit bus feeds 2048 stream processors
  • 1244 MHz core clock with 1500 MHz memory keeps trading desks responsive
  • 80 W TDP draws power from a single 6-pin connector
  • Compact 6.85-inch dual-slot card fits small-form-factor builds

Six-HDMI Multi-Display Card

The SongryVGA SY586H42 Radeon RX 580 delivers six HDMI 2.0 outputs from a single PCIe 3.0 x16 slot. It targets traders, signage operators and office users who need up to six 4K screens without adding extra GPUs. The 4 GB GDDR5 frame buffer and 256-bit bus feed the 2048 stream processors at 1244 MHz core and 1500 MHz memory clocks. DirectX 12 and OpenGL 4.6 cover modern desktop workloads on Windows 7 through 11.

Upgrade From Entry Multi-Monitor GPUs

Moving up from cards limited to four outputs or older HDMI 1.4 ports removes the need for splitters or daisy-chains. The jump is worth it when a single 6-pin connector and 80 W TDP fit the existing 450 W power budget while doubling usable display ports. The dual-slot, 6.85-inch form factor slides into compact chassis that cannot accept longer boards. No external adapters are required for native 4K60 on every port.

4 GB GDDR5 Headroom

Four gigabytes of GDDR5 handles desktop compositing, browser-heavy trading layouts and 4K video playback across six panels without paging. The 256-bit interface sustains 1500 MHz effective bandwidth for smooth window drags and scrolling. Memory pressure appears when driving multiple 4K gaming or 3D rendering contexts simultaneously; compute workloads exceeding the 4 GB limit will spill to system RAM. For pure 2D productivity and signage loops the buffer remains comfortable.

Highlights

  • Drives six 4K displays from six HDMI 2.0 ports
  • 4 GB GDDR5 on a 256-bit bus feeds 2048 stream processors
  • 1244 MHz core clock with 1500 MHz memory keeps trading desks responsive
  • 80 W TDP draws power from a single 6-pin connector
  • Compact 6.85-inch dual-slot card fits small-form-factor builds

Specifications

BrandSongryVGA
ModelSY586H42
InterfacePCI Express 3.0 x16
Chipset ManufacturerAMD
GPURadeon RX 580
Core Clock1244 MHz
Stream Processors2048
Effective Memory Clock1500 MHz
Memory Size4GB
Memory Interface256-Bit
Memory TypeGDDR5
DirectXDirectX 12
OpenGLOpenGL 4.6
Multi-Monitor Support6
HDMI6*HDMI 2.0
Max Resolution3840 x 2160
CoolerSingle Fan
Thermal Design Power80W
Recommended PSU Wattage450W
Power Connector6-Pin
Form FactorATX
Max GPU Length174 mm
Low Profile Bracket IncludedNo
Card Dimensions (L x H)174mm*111mm
Slot Width2 Slots

Other versions of this model

1 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How much clearance does the 6.85-inch dual-slot card need inside the case?

The card measures 6.85 inches long and occupies two expansion slots, so ensure your chassis has at least that length and two adjacent rear brackets free.

Which power connector must be attached before the card will start?

Connect a single 6-pin PCIe power cable from the PSU; the board draws up to 80W and will not initialise without that connector seated fully.

When should the single fan and heatsink be cleaned to maintain the 80W thermal rating?

Use compressed air to clear dust from the fan blades and fin stack every six to twelve months, or sooner if temperatures rise under sustained load.
