Green Micro-ATX server board with silver CPU socket, four black DDR5 slots, two long PCIe x16 slots, rear I/O shield with USB-C, HDMI

Supermicro

Supermicro MBD-H13SAE-MF-O server motherboard LGA-1718 192GB DDR5 5200 2 PCIe 5.0 x16

SKU CH-T11Z-TARSK MPN MBD-H13SAE-MF-O

Micro-ATX server board with single LGA-1718 socket supporting up to 16-core AMD CPUs, 192 GB DDR5-5200, two PCIe 5.0 x16 slots, dual Intel 1 GbE LAN and dedicated IPMI

  • CPU Socket TypeSingle Socket LGA-1718 (Socket AM5) supported
  • CPU TypeAMD Ryzen 7000 Series
  • Number of Processor Support1
  • CPU FeaturesCPU TDP supports Up to 170W TDP Up to 16 cores, 32 threads
  • North BridgeAMD B650
  • Memory Slots4 x DDR5 288-pin
  • Supports AMD EPYC 4004 and Ryzen 7000 series CPUs up to 170W TDP
  • 192GB DDR5 5200 MT/s capacity across four 288-pin DIMM slots
  • Two PCIe 5.0 x16 slots configurable as 16/0 or 8/8 for dual GPU
  • Two M.2 PCIe 5.0 x4 slots with RAID 0 and 1 support
  • Dual Intel i210 1GbE LAN plus dedicated IPMI management port

Micro-ATX server board for AMD EPYC and Ryzen

The Supermicro MBD-H13SAE-MF-O is a Micro-ATX server motherboard built around the AMD B650 chipset and single LGA-1718 socket. It supports AMD EPYC 4005 and 4004 series processors as well as Ryzen 9000, 8700G and 7000 series CPUs up to 170W TDP with 16 cores and 32 threads. The board targets builders who need workstation or entry-server density in a compact chassis.

Step up from consumer boards when ECC

This board replaces standard desktop platforms when unbuffered ECC memory, dedicated IPMI LAN and dual Intel i210 Gigabit ports are required. The jump is worth it for 24/7 workloads that need hardware monitoring via ASPEED AST2600 BMC and RAID 0/1/10 across four SATA 6.0Gb/s ports. Buyers who do not need remote management or ECC will find the extra cost harder to justify.

Straightforward install if the cooler clears the VRM

Micro-ATX layout follows standard standoffs and the 24-pin plus 8-pin EPS power connectors sit in familiar positions. Two PCIe 5.0 x16 slots run at 16/0 or 8/8 electrically and accommodate up to two double-width GPUs or one triple-width card. Builders must verify CPU cooler clearance against the VRM heatsinks and confirm that M.2 2280 or 22110 drives fit behind the primary graphics card.

Highlights

  • Supports AMD EPYC 4004 and Ryzen 7000 series CPUs up to 170W TDP
  • 192GB DDR5 5200 MT/s capacity across four 288-pin DIMM slots
  • Two PCIe 5.0 x16 slots configurable as 16/0 or 8/8 for dual GPU
  • Two M.2 PCIe 5.0 x4 slots with RAID 0 and 1 support
  • Dual Intel i210 1GbE LAN plus dedicated IPMI management port

Specifications

BrandSUPERMICRO
ModelMBD-H13SAE-MF-O
CPU Socket TypeSingle Socket LGA-1718 (Socket AM5) supported
CPU TypeAMD Ryzen 7000 Series
Number of Processor Support1
CPU FeaturesCPU TDP supports Up to 170W TDP
Up to 16 cores, 32 threads
North BridgeAMD B650
Memory Slots4 x DDR5 288-pin
Memory StandardMemory Type: 5200/4800/3600 MT/s Up to 192GB of memory with speeds of up to 5200MT/s (1DPC)/ 3600MT/s (2DPC)
DIMM Sizes: 8GB, 16GB, 24GB, 32GB, 48GB
PCI Express 5.0 x162 PCIe 5.0 x16 slots (16/NA or 8/8)
PCI Express x41 PCIe 4.0 x4
SATA4 x SATA 6.0Gb/s
SATA RAID0/1/10
M.2M.2 Interface: 2 PCIe 5.0 x4, RAID 0 & 1
Form Factor: 2280/22110
Key: M-Key
Onboard Video ChipsetAspeed AST2600
Audio ChipsetALC 888S HD Audio
LAN ChipsetDual LAN with Intel i210 Gigabit Ethernet Controller
Single LAN with ASPEED AST2600 BMC, Dedicated LAN for IPMI
LAN Speed10/100/1000Mbps
Max LAN Speed1Gbps
Back I/O PortsUSB
1 USB 3.2 Gen2x2 port(s) (1 rear type C 20Gb)
5 USB 3.2 Gen2 port(s) (3 rear type A 10Gb; 2 rear type C DP 1.4 Alt mode)
Video Output
1 HDMI 2.0 port(s), 1 DP 1.4a port(s), 2 rear type C port(s) DP 1.4 Alt mode
Serial Port
1 COM Port(s) (1 header)
TPM
1 TPM Header
Onboard USB2 USB 3.2 Gen1 port(s) (2 headers 5Gb)
1 USB 2 port(s) (1 via header 2 ports by a header)
Form FactorMicro ATX
Dimensions (W x L)9.6" x 9.6"
Shipping weight1.18 kg
Package size292 × 273 × 53 mm

Questions about this item

What size DDR5 DIMMs and how many slots does the board accept?

The motherboard has four 288-pin DDR5 slots supporting 8, 16, 24, 32 or 48 GB modules for a maximum of 192 GB.

How are the two PCIe 5.0 x16 slots wired when both are populated?

The first slot runs at x16 alone; with two cards installed each slot operates at x8 electrical.

What M.2 drive lengths and RAID modes are supported on the two onboard slots?

Both M-Key slots accept 2280 and 22110 form factors and can be configured in RAID 0 or RAID 1.
