Silver 1U rack server with front LED panel and ventilation slots

Supermicro

Supermicro SYS-E300-13AD-02-G1 1U rack server Intel Core i5-13500E 12-core 32GB DDR4 960GB NVMe

SKU CH-SF77-6EYXR MPN SYS-E300-13AD-02-G1

A 1U rack edge server with a 12-core Intel Core i5-13500E, 32GB DDR4-3200, and a 960GB NVMe drive, plus 2.5GbE and 1GbE ports

  • WorkloadEdge Server
  • TypeRack
  • Rack Height1U
  • LEDsHDD Status LAN1 activity LAN2 activity Power status WIFI act
  • Hot-swap Fans2x 4-PIN PWM 40x40x28mm Fan(s) 1 CPU heatsink with F80x15mm
  • CPU TypeIntel Core i5
  • 12-core Intel Core i5-13500E handles edge workloads
  • 32 GB DDR4-3200 memory supports up to 2 TB capacity
  • 960 GB M.2 NVMe PCIe 4.0 drive delivers fast storage
  • 5 GbE and 1 GbE ports provide flexible networking
  • Dual 800 W platinum power supplies ensure reliable operation

1U rack server for edge workloads

The Supermicro SYS-E300-13AD-02-G1 is a 1U rack system built for edge deployments. It ships with a single Intel Core i5-13500E 12-core processor running at 2.40 GHz and 24 MB cache. Installed memory is 32 GB DDR4-3200 across eight slots, with support for up to 2 TB ECC DDR4 RDIMM or LRDIMM. A 960 GB M.2 7450 PRO NVMe PCIe 4.0 drive provides primary storage. Networking includes one 2.5 GbE RJ45 and one 1 GbE RJ45 port. Two 800 W Platinum power supplies power the unit.

Who this suits and who should look elsewhere

This server fits teams deploying inferencing, IoT aggregation or light virtualisation at the network edge where a single-socket box with dual-speed Ethernet and hot-swap cooling is required. Buyers who need dual-processor capacity, 10 GbE or faster networking, or multiple NVMe drives should consider other platforms. Sites without 0.7 m/s airflow or operating outside 0 °C to 40 °C also need a different chassis.

Deciding specification: single-socket 12-core

The Intel Core i5-13500E is fixed at one processor with 12 cores and a 2.40 GHz base frequency. Maximum processor count is one, so the system cannot scale beyond this CPU. If the workload demands more cores, higher base clocks or a second socket, this model will not meet the requirement. The 32 GB DDR4-3200 and 960 GB NVMe are field-upgradable, but the compute ceiling is set by the installed 12-core processor.

Highlights

  • 12-core Intel Core i5-13500E handles edge workloads
  • 32 GB DDR4-3200 memory supports up to 2 TB capacity
  • 960 GB M.2 NVMe PCIe 4.0 drive delivers fast storage
  • 5 GbE and 1 GbE ports provide flexible networking
  • Dual 800 W platinum power supplies ensure reliable operation

Specifications

BrandSUPERMICRO
SeriesGold Series
ModelSYS-E300-13AD-02-G1
WorkloadEdge Server
TypeRack
Rack Height1U
LEDsHDD Status
LAN1 activity
LAN2 activity
Power status
WIFI activity
Hot-swap Fans2x 4-PIN PWM 40x40x28mm Fan(s)
1 CPU heatsink with F80x15mm Fan(s)
CPU TypeIntel Core i5
CPU Speed13500E (2.40 GHz)
Number of CPU Cores12-Core Processor
Cache Memory24 MB
# of Processors Installed1
MAX Processors1
Installed Memory Size32GB
Memory TypeDDR4 3200
Memory FeaturesMax Memory (2DPC): Up to 2TB 3200MT/s ECC DDR4 RDIMM/LRDIMM
Number of Memory Slots8
SSD (Installed)1 x 960GB M.2 7450 PRO NVMe (80mm) PCIe 4.0 Solid State Drive
Ethernet Controller1 x 1 2.5GbE RJ45 Port + 1 1GbE RJ45 Port
Expansion Bays1 internal fixed 2.5" SATA* drive bay
1 M.2 PCIe 4.0 x4 NVMe slot (M-key 2280)
Power Characteristics2 x 800W Platinum Level
TemperatureOperating Temperature: 0°C to 40°C (32°F to 104°F) with 0.7 m/s airflow
Non-operating Temperature: -40°C to 70°C (-40°F to 158°F)
HumidityOperating Relative Humidity: 8% to 90% (Non-Condensing)
Non-operating Relative Humidity: 5% to 95% (Non-Condensing)
Dimensions1.69" x 10.43" x 8.89"
Weight3.7 lbs.
Shipping weight3.40 kg
Package size381 × 276 × 142 mm

Questions about this item

What network speeds do the onboard RJ45 ports support?

The server provides one 2.5GbE RJ45 port and one 1GbE RJ45 port for wired connectivity.

What rack space and internal drive bays does this 1U server require?

It fits a single 1U rack position and includes one internal fixed 2.5-inch SATA drive bay plus one M.2 PCIe 4.0 x4 NVMe slot (M-key 2280).

How is the memory installed and what limit applies?

The system ships with 32GB DDR4-3200 across eight slots and supports up to 2TB of ECC DDR4 RDIMM or LRDIMM at 3200MT/s in a 2DPC configuration.
