Black 1U rackmount NAS front panel with four drive bays and status LEDs

Synology Inc.

Synology RS1626xs+ Xeon D-1726 16GB 3.2TB Cache 16TB rackmount NAS

SKU CH-3YGE-TGXYQ

A 1U 4-bay rackmount NAS with a Xeon D-1726 processor, 16GB DDR4 ECC memory, dual 10GbE ports, 3.2TB NVMe cache, and 16TB of enterprise drives pre-installed

  • Port RJ-452 x RJ-45 10GbE LAN Port 1 x Out-of-Band Management LAN Port
  • Port USB2 x USB 3.2 Gen 1 Ports
  • Form Factor4-Bay
  • ProcessorIntel Xeon
  • Installed Memory16GB
  • Included HDD Capacity16TB (4 x 4TB)
  • Pre-installed 3.2 TB NVMe cache accelerates workloads
  • Intel Xeon D-1726 6-core processor handles virtualization
  • 16 GB DDR4 ECC memory supports mission-critical tasks
  • Dual 10GbE RJ-45 ports enable high-speed networking
  • Four 4 TB enterprise drives provide 16 TB capacity

Enterprise 4-bay NAS for virtualization workloads

The Synology RS1626xs+ is a 1U rackmount server built around an Intel Xeon D-1726 processor with 16GB of DDR4 ECC memory. It targets businesses that run virtual machines, host collaborative file services or need a consolidated backup target for mission-critical data.

Dual 10GbE ports and PCIe Gen4 expansion

Two RJ-45 10GbE LAN ports and a dedicated out-of-band management port handle high-throughput traffic and remote administration simultaneously. A PCIe Gen4 x8 slot and dual M.2 NVMe slots allow the platform to grow with additional networking, storage cache or specialised accelerator cards as requirements evolve.

Pre-populated with enterprise drives and cache

The unit ships fully assembled with four 4TB Synology enterprise drives providing 16TB of raw capacity and two 1.6TB NVMe cache modules totalling 3.2TB for read-write acceleration. This configuration eliminates initial drive sourcing and RAID setup time so the system can enter production immediately.

Highlights

  • Pre-installed 3.2 TB NVMe cache accelerates workloads
  • Intel Xeon D-1726 6-core processor handles virtualization
  • 16 GB DDR4 ECC memory supports mission-critical tasks
  • Dual 10GbE RJ-45 ports enable high-speed networking
  • Four 4 TB enterprise drives provide 16 TB capacity

Specifications

BrandSynology
ModelRS1626xs+
Port RJ-452 x RJ-45 10GbE LAN Port
1 x Out-of-Band Management LAN Port
Port USB2 x USB 3.2 Gen 1 Ports
Form Factor4-Bay
ProcessorIntel Xeon
Installed Memory16GB
Included HDD Capacity16TB (4 x 4TB)
ManagementWeb-Based, DHCP Client
LEDsPower, HDD (Hard Disk Drive), LAN (10/100)
Power100-240 VAC 50/60Hz
Temperature5°C - 35 °C
Humidity8% to 80% RH
Dimensions44 mm × 481.9 mm × 668.5 mm
Weight9.5 kg
Package ContentsMain Unit × 1
Accessory Pack × 1
C13 to C14 power cord × 2
Front Cover × 1
All Configuration Items

Questions about this item

What bandwidth do the dual 10GbE RJ-45 ports provide for network transfers?

Two 10GbE RJ-45 LAN ports deliver up to 10 Gbps each, with a dedicated 1GbE out-of-band management port for remote administration.

What rack space and clearance does the 1U chassis require?

The unit measures 44 mm high, 481.9 mm wide and 668.5 mm deep, fitting a standard 1U rack slot and weighing 9.5 kg.

How are the M.2 NVMe cache modules installed in the RS1626xs+?

Insert each NVMe module into the internal M.2 slots, secure with the retention screw, then create the read-write cache volume in DSM.
