Black 1U rackmount NAS chassis with four drive bays and front status LEDs

Synology Inc.

Synology RS1626xs+ Xeon D-1726 4-Bay Rackmount NAS 16GB 80TB

SKU CH-C4AT-5HQAZ

A 4-bay 1U rackmount NAS with Xeon D-1726 processor, 16GB DDR4 ECC memory, dual 10GbE ports, PCIe Gen4 x8 expansion, dual M.2 NVMe slots, and 80TB of enterprise drives pre-installed

  • Port RJ-452 x RJ-45 10GbE LAN Ports 2 x RJ-45 10GbE LAN Ports via Syno
  • Port USB2 x USB 3.2 Gen 1 Ports
  • Form Factor4-Bay
  • ProcessorIntel Xeon
  • Installed Memory16GB
  • Included HDD Capacity80TB (4 x 20TB)
  • 1U rackmount density saves server-room space with 44 mm height
  • Intel Xeon D-1726 6-core CPU powers virtualization and heavy workloads
  • 16 GB DDR4 ECC memory protects data integrity under load
  • Dual 10 GbE RJ-45 ports plus dedicated management LAN enable fast, segregated traffic
  • 80 TB raw capacity from four 20 TB enterprise drives ready for production

Synology RS1626xs+ 4-Bay 80TB Rackmount NAS

The Synology RS1626xs+ is a 1U rackmount network-attached storage server with four drive bays populated by 20TB enterprise hard drives for 80TB total capacity. An Intel Xeon D-1726 processor and 16GB DDR4 ECC memory power the system. Dual 10GbE RJ-45 ports and a dedicated management LAN connection provide high-throughput networking. The unit arrives fully assembled and tested.

Teams needing dense 10GbE storage.

This appliance suits organisations that want a compact 1U chassis with integrated 10GbE and 80TB of validated enterprise drives for virtualisation, backup or file collaboration. Buyers who require more than four internal bays without adding an expansion unit should consider a larger chassis. Environments that need GPU acceleration or fibre-channel connectivity will not find those interfaces here.

80TB usable capacity from four enterprise drives

The defining specification is the factory-installed 80TB raw capacity delivered by four Synology 20TB enterprise NAS drives. This determines how much data the system can store before any RAID overhead and whether the density meets the project's storage target. All other capabilities scale from this base configuration.

Highlights

  • 1U rackmount density saves server-room space with 44 mm height
  • Intel Xeon D-1726 6-core CPU powers virtualization and heavy workloads
  • 16 GB DDR4 ECC memory protects data integrity under load
  • Dual 10 GbE RJ-45 ports plus dedicated management LAN enable fast, segregated traffic
  • 80 TB raw capacity from four 20 TB enterprise drives ready for production

Specifications

BrandSynology
ModelRS1626xs+
Port RJ-452 x RJ-45 10GbE LAN Ports
2 x RJ-45 10GbE LAN Ports via Synology PCIe Card
1 x Out-of-Band Management LAN Port
Port USB2 x USB 3.2 Gen 1 Ports
Form Factor4-Bay
ProcessorIntel Xeon
Installed Memory16GB
Included HDD Capacity80TB (4 x 20TB)
ManagementWeb-Based, DHCP Client
LEDsPower, HDD (Hard Disk Drive), LAN (10/100)
Power100-240 VAC 50/60Hz
Temperature5°C - 35 °C
Humidity8% to 80% RH
Dimensions44 mm × 481.9 mm × 668.5 mm
Weight9.5 kg
Package ContentsMain Unit × 1
Accessory Pack × 1
C13 to C14 power cord × 2
Front Cover × 1
All Configuration Items

Questions about this item

What rack depth and height does the 1U 4-bay chassis with 44 mm height and 668.5 mm depth require?

The unit occupies one rack unit at 44 mm tall and needs a rack at least 668.5 mm deep; allow extra clearance for the two C13-to-C14 power cords and front cover.

How do I install the Synology 2-Port 10GbE Adapter in the PCIe Gen4 x8 slot, and what step is often missed?

Power down, open the chassis, insert the adapter into the PCIe Gen4 x8 slot until it clicks, secure the bracket, then remember to enable the ports in DSM after reboot.

When should the four 20 TB Synology Enterprise NAS drives be replaced, and what memory upgrade is supported later?

Replace drives when DSM reports degraded health or after the rated workload limit; memory can be expanded from 16 GB to 64 GB using DDR4 ECC RDIMM modules.
