M.2 2280 SSD with black heatsink, 22 by 80 mm

Team Group

Team Group NV5000 2TB M.2 2280 internal SSD TM8FGM002T0C101

SKU CH-XBEB-V8M04 MPN TM8FGM002T0C101

A 2TB PCIe 4.0 x4 internal SSD with NVMe, 5000 MBps read, 3000 MBps write, 640TB TBW and an integrated heatsink

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity2TB
  • InterfacePCIe 4.0 x4 with NVMe
  • ProtocolNVMe

Capacity 2TB

  • 2TB capacity stores large game libraries and media projects
  • PCIe 4.0 x4 interface delivers up to 5000 MBps sequential read speeds
  • Integrated heatsink maintains performance under sustained workloads
  • 640TB written endurance rating supports heavy daily write cycles
  • 2,000,000-hour MTBF indicates long-term reliability for consumer use

Team Group NV5000 2TB PCIe 4.0 NVMe SSD

This internal solid state drive uses the M.2 2280 form factor and a PCIe 4.0 x4 interface with NVMe protocol. It targets consumer workloads such as gaming, content creation and everyday computing. The drive ships with an integrated heatsink for thermal management.

Sustained write behaviour without DRAM cache

The controller relies on host memory buffer (HMB) instead of onboard DRAM. Sequential write speeds reach up to 3000 MBps while random write performance hits 545000 IOPS. The 640TB endurance rating and 2000000 hour MTBF indicate consistent operation across heavy workloads.

Straightforward M.2 installation

The 3.70mm module height fits standard M.2 slots but may need extra clearance in tight laptop bays. Motherboard standoffs at 22mm and 80mm depth align with the 2280 footprint. Operating range of 0°C to 70°C requires adequate case airflow to avoid throttling.

Highlights

  • 2TB capacity stores large game libraries and media projects
  • PCIe 4.0 x4 interface delivers up to 5000 MBps sequential read speeds
  • Integrated heatsink maintains performance under sustained workloads
  • 640TB written endurance rating supports heavy daily write cycles
  • 2,000,000-hour MTBF indicates long-term reliability for consumer use

Specifications

BrandTeam Group
SeriesNV5000
ModelTM8FGM002T0C101
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity2TB
InterfacePCIe 4.0 x4 with NVMe
ProtocolNVMe
CacheNo DRAM (HMB)
Max Sequential ReadUp to 5000 MBps
Max Sequential WriteUp to 3000 MBps
4KB Random WriteUp to 545,000 IOPS
Terabytes Written (TBW)640TB
MTBF2,000,000 hours
HeatSinkwith HeatSink
Operating Temperature0°C ~ +70°C
Storage Temperature-40°C ~ +85°C
Max Shock Resistance1,500G/0.5ms
Max Vibration Resistance80Hz~2,000Hz/20G
Height3.70mm
Width22mm
Depth80mm
Weight7g
Shipping weight0.05 kg
Package size124 × 94 × 1 mm

Other versions of this model

1 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Does the included heatsink increase the drive height enough to block a laptop M.2 slot?

The drive with heatsink measures 3.70 mm tall, a standard single-sided M.2 2280 height that fits most laptop slots.

What does the 640 TBW rating mean for daily write workloads?

640 TBW allows several hundred gigabytes of writes per day over the typical warranty period.

Is a motherboard PCIe 4.0 slot required to use this SSD?

The drive works in PCIe 3.0 slots at reduced speed; full 5000 MBps reads need a PCIe 4.0 x4 M.2 socket.
