Rectangular silver desktop NAS with eight front drive bays and Thunderbolt 4 ports

Ugreen Group Limited

Ugreen Group Limited DXP8800 Plus 8-Bay NAS Intel Core i5 1235U 8GB DDR5

SKU CH-V68N-5F19Y MPN DXP8800 Plus

Eight-bay desktop NAS with a 10-core Intel i5-1235U, 8 GB DDR5, dual 10 GbE and two Thunderbolt 4 ports, expandable to 64 GB RAM

  • TypeDesktop NAS
  • Ports2x Thunderbolt 4
  • Port RJ-452 x 10GbE
  • Port USB2 x USB-A 3.2 Gen 2 + 2 x USB-A 2.0
  • HDD Interface8 x SATA (8 x Bay) + 2 x M.2 (2 x Bay)
  • Form Factor8-Bay

Form Factor 8-Bay

Processor Intel Core i5

Memory Slot 2 x SO-DIMM

  • 10-core Intel i5-1235U reaches 4.40 GHz for responsive multi-tasking
  • Dual 10GbE ports aggregate to 20Gb bandwidth for 2500MB/s transfers
  • Eight SATA bays plus two M.2 slots support up to 184TB total capacity
  • 8GB DDR5-4800 memory installed, expandable to 64GB across two SO-DIMM slots
  • UGOS Pro unifies storage, file and photo management in a single app

8-Bay Desktop NAS for Creative Workflows

The Ugreen NASync DXP8800 Plus is an 8-bay desktop NAS built around a 10-core Intel Core i5 1235U processor and 8GB of DDR5 memory. It targets creative professionals and small teams who need high-speed local storage with direct Thunderbolt connectivity for video editing and large file transfers.

Dual 10GbE and Thunderbolt 4 Connectivity

Two 10GbE ports can be aggregated for up to 20Gbps network throughput while two Thunderbolt 4 ports provide direct-attached speeds for workstations. The Intel i5 1235U runs at up to 4.40 GHz within a compact desktop chassis designed for quiet operation in office or studio environments.

Sustained RAID Performance with Expandable Memory

Under continuous workloads the system maintains throughput across JBOD, RAID 0, 1, 5, 6 or 10 arrays using up to eight SATA drives and two M.2 NVMe slots. Installed DDR5 memory can be expanded to 64GB via two SO-DIMM slots to support heavier multitasking and virtualisation tasks.

Highlights

  • 10-core Intel i5-1235U reaches 4.40 GHz for responsive multi-tasking
  • Dual 10GbE ports aggregate to 20Gb bandwidth for 2500MB/s transfers
  • Eight SATA bays plus two M.2 slots support up to 184TB total capacity
  • 8GB DDR5-4800 memory installed, expandable to 64GB across two SO-DIMM slots
  • UGOS Pro unifies storage, file and photo management in a single app

Specifications

BrandUgreen
SeriesNASync
ModelDXP8800 Plus
Part NumberDXP8800 Plus
TypeDesktop NAS
Ports2x Thunderbolt 4
Port RJ-452 x 10GbE
Port USB2 x USB-A 3.2 Gen 2 + 2 x USB-A 2.0
HDD Interface8 x SATA (8 x Bay) + 2 x M.2 (2 x Bay)
Form Factor8-Bay
Operating SystemUGOS Pro
ProcessorIntel® Core i5 1235U (10 cores, 12 threads)
Installed Memory8GB DDR5
Max Memory Capacity64GB DDR5
Memory Slot2 x DDR5 SO-DIMM
Included HDD CapacityDiskless System
Max Capacity8 x 22TB SATA + 2 x 4TB M.2
RAIDJBOD/Basic/RAID0/RAID1/RAID5/RAID6/RAID10
Drive Compatibility3.5" SATA HDD
M.22 x M.2 Slots
Power Consumption70.39W (drive access) / 28.99W (drive hibernation)
UsageBackup & stream media through personal cloud
Dimensions17 x 10 x 7.5
Package ContentsNASync DXP8800 Plus
User Manual
After-sales Card x1
Hard Drive Tray Keys x2
Power Cable
Ethernet Cable (CAT7) x2
SSD Silicone Pads x2
Screws & Screwdriver
Shipping weight9.62 kg
Package size483 × 356 × 279 mm

Other versions of this model

3 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How do I install drives in the 8 SATA bays and the 2 M.2 slots, and what step do people often miss?

Insert 3.5-inch SATA drives into the eight front bays until they click, then secure M.2 modules in the two internal slots with the retaining screws; the step often missed is enabling the new volumes in UGOS Pro Storage Manager before they become usable.

What maintenance or replacement will the DXP8800 Plus need later?

The two DDR5 SO-DIMM slots support expansion up to 64 GB, so adding matched modules is the main upgrade; drive replacement follows normal RAID rebuild procedures when a disk fails.

What limit appears first under sustained heavy workloads on this NAS?

The installed 8 GB DDR5 memory and 10-core Intel i5-1235U processor set the practical ceiling for concurrent VMs, Docker containers and large-file transfers before the 10 GbE or Thunderbolt 4 links saturate.
