M.2 2280 internal SSD, bare green circuit board, black label, no heatsink

Western Digital

Western Digital WD BLACK SN750 WDS250G3X0C 250GB internal SSD

SKU CH-PNEH-YERY1 MPN WDS250G3X0C

A 250GB M.2 2280 internal SSD using 64-layer 3D NAND and a PCI-Express 3.0 x4 interface, delivering sequential reads up to 3100 MB/s and writes up to 1600 MB/s with 200 TBW endurance

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity250GB
  • Memory Components64-layer 3D NAND
  • InterfacePCI-Express 3.0 x4

Options 250GB

  • Read speeds up to 3100 MB/s cut game load times
  • Write speeds up to 1600 MB/s accelerate file transfers
  • 220,000 random read IOPS boost system responsiveness
  • 64-layer 3D NAND with 200 TBW endurance rating
  • M.2 2280 form factor fits compact builds

WD BLACK SN750 250GB NVMe SSD

This internal solid-state drive uses a PCI-Express 3.0 x4 interface and 64-layer 3D NAND to deliver sequential reads up to 3100 MBps and writes up to 1600 MBps. It is built for consumer PCs that need fast boot and load times in a compact M.2 2280 form factor.

Suits builds with an M.2 slot wired for PCIe 3.0 x4

Systems that only support PCIe 2.0 or earlier will not reach the rated speeds. Users who need sustained write performance for heavy workloads should consider drives with higher endurance ratings.

PCI-Express 3.0 x4 interface decides compatibility

The drive requires an M.2 2280 slot that runs four lanes of PCIe 3.0 to achieve 3100 MBps reads and 1600 MBps writes. Without that link the SSD will fall back to lower throughput.

Highlights

  • Read speeds up to 3100 MB/s cut game load times
  • Write speeds up to 1600 MB/s accelerate file transfers
  • 220,000 random read IOPS boost system responsiveness
  • 64-layer 3D NAND with 200 TBW endurance rating
  • M.2 2280 form factor fits compact builds

Specifications

BrandWestern Digital
SeriesBLACK SN750 NVMe
ModelWDS250G3X0C
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity250GB
Memory Components64-layer 3D NAND
InterfacePCI-Express 3.0 x4
Max Sequential ReadUp to 3100 MBps
Max Sequential WriteUp to 1600 MBps
4KB Random ReadUp to 220,000 IOPS
4KB Random WriteUp to 180,000 IOPS
MTTF1,750,000 hours (Telcordia SR-332, GB, 40 celsius degree)
HeatSinkwithout HeatSink
FeaturesEndurance (TBW): 200
Read speeds up to 3,100 MB/s for improved load times.
Available in capacities ranging from 250GB to 2TB.
Sleek heatsink design to customize and intensify your gaming rig while helping to maintain peak performance.
An exclusive WD BLACK SSD dashboard with gaming mode improves game performance.
Operating Temperature0°C ~ +70°C
Storage Temperature-55°C ~ +85°C
Height2.38mm
Width22.00mm
Depth80.00mm
Weight7.50g
Shipping weight0.05 kg
Package size127 × 102 × 25 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What M.2 slot length does the WDS250G3X0C require?

The drive uses the M.2 2280 form factor, so the motherboard must provide an M-keyed slot that accepts 80 mm modules.

Which step is often missed when installing this PCI-Express 3.0 x4 NVMe drive?

After seating the module at an angle and securing it with the motherboard standoff screw, many builders forget to enable the NVMe option in the BIOS boot-order menu.

When will the 250 GB model reach its rated endurance limit?

The drive is rated for 200 TBW; once that amount of data has been written the NAND may enter read-only mode.
