Silver 3.5-inch bare hard drive with exposed circuit board and SATA connectors

Western Digital

Western Digital WD6002FRYZ 6TB 7200 RPM SATA 128MB internal hard drive

SKU CH-80CJ-CSWX3 MPN WD6002FRYZ

A 6TB 3.5-inch enterprise hard drive with 7200 RPM, 128MB cache, SATA 6.0Gb/s interface and a 550TB yearly workload rating

  • PackagingBare Drive
  • InterfaceSATA 6.0Gb/s
  • Capacity6TB
  • RPM7200 RPM
  • Cache128MB
  • FeaturesHigh workload rating Delivering dependable performance to an

Options 6TB

  • Enterprise-class reliability with 2.5 million hours MTBF
  • Handles heavy workloads up to 550TB per year
  • 7200 RPM and 128MB cache for fast data access
  • 6TB capacity in a standard 3.5-inch form factor
  • HelioSeal technology for proven high-capacity operation

Enterprise 6 TB SATA drive

The Western Digital WD6002FRYZ is a 3.5-inch internal hard drive built for enterprise servers and storage systems. It delivers 6 TB of capacity on a SATA 6.0Gb/s interface with a 7200 RPM spindle and 128 MB cache. The drive is rated for 24x7x365 operation and a 550 TB yearly workload. Its 2.5 million hour MTBF targets high-reliability environments.

Upgrade from lower-workload drives

This model replaces consumer or entry-level drives that lack the 550 TB per year workload rating and the enhanced vibration protection. The jump is worth it when your array writes heavily every day and you need the sustained throughput of a 7200 RPM platform with HelioSeal technology. It also supersedes older enterprise drives that do not reach the 2.5 million hour MTBF figure.

Check bay height and controller compatibility

Verify that your chassis accepts a 26.10 mm drive height and that your backplane or HBA supports SATA 6.0Gb/s. The bare-drive packaging means no mounting screws or cables are included. Confirm your power supply provides the standard 3.5-inch SATA power connector before ordering.

Highlights

  • Enterprise-class reliability with 2.5 million hours MTBF
  • Handles heavy workloads up to 550TB per year
  • 7200 RPM and 128MB cache for fast data access
  • 6TB capacity in a standard 3.5-inch form factor
  • HelioSeal technology for proven high-capacity operation

Specifications

BrandWD
SeriesGold
ModelWD6002FRYZ
PackagingBare Drive
InterfaceSATA 6.0Gb/s
Capacity6TB
RPM7200 RPM
Cache128MB
FeaturesHigh workload rating
Delivering dependable performance to any storage environment, WD Gold hard drives are designed with a workload rating up to 550TB per year, among the highest of any 3.5-inch hard drive.
Enterprise-class storage to rely on
With up to 2.5 million hours MTBF, WD Gold hard drives deliver reliability and durability, are built for yearly operation (24x7x365) within the most demanding storage environments.
HelioSeal Technology
Featured in over 15 million Western Digital hard drives shipped, HelioSeal technology allows for higher capacities and less turbulence on large s
UsageFor Enterprise Storage
Form Factor3.5"
Height (maximum)26.10mm
Width (maximum)101.60mm
Length (maximum)147.00mm
Shipping weight0.85 kg
Package size208 × 163 × 112 mm

Other versions of this model

1 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What are the exact dimensions of this 3.5-inch WD Gold drive so I can confirm it fits my server bay?

The drive measures 147.00 mm long, 101.60 mm wide and 26.10 mm high, matching the standard 3.5-inch form factor used in enterprise bays.

Which cables and jumpers are required to install the WD6002FRYZ in a RAID enclosure?

Connect a standard SATA data cable to the 6.0Gb/s port and a SATA power cable from the supply; no jumpers are needed for normal operation.

When should I plan to replace this enterprise drive based on its rated workload limit?

The drive is rated for up to 550TB written per year; track cumulative writes in your monitoring software and schedule replacement before you consistently exceed that annual figure.
