White PTZ network camera, compact rectangular body with front lens, side tally light and rear connection panel

BZBGEAR

BZBGEAR BG-UPTZ-12XHSU-W 12x PTZ network camera White

SKU CH-K2HZ-E6SF8

PTZ network camera with 12x optical zoom, simultaneous HDMI, 3G-SDI, USB 3.0 and IP streaming outputs, PoE power and ONVIF support

  • Bundled Camera Number1 Camera
  • Camera Type2 Megapixel
  • Network CameraYes
  • TypePTZ HDMI/SDI/USB 3.0 RS232/485 Live Streaming Camera
  • Connection TypeUSB 3.0, HDMI, 3G-SDI, LAN(POE), RS232/485, LINE IN
  • ColorWhite

Option 12X

  • 12x optical zoom captures distant detail clearly
  • Simultaneous HDMI, 3G-SDI, USB 3.0 and IP outputs fit any workflow
  • PoE delivers power and data over one cable
  • Pan 340° and tilt -30° to +90° covers wide areas
  • ONVIF, RTSP, RTMP support works with common platforms

12x optical zoom PTZ camera

The BG-UPTZ-12XHSU-W is a 2 megapixel network camera with 12x optical zoom and simultaneous HDMI, 3G-SDI, USB 3.0 and IP streaming outputs. It targets houses of worship, universities, hospitals and performing arts centres that need a single camera for live production and direct streaming to platforms. Control options include IR remote, IP VISCA, ONVIF and cascadable RS-232/485 with 255 preset positions.

Sustained streaming and multi-output operation

The camera encodes H.264 or H.265 at up to 1080p60 while driving HDMI, 3G-SDI and USB 3.0 concurrently, so the processor handles continuous compression and multiple signal paths without dropping frames. Pan and tilt speeds reach 80° per second horizontally and 60° per second vertically across the 340° pan and -30° to +90° tilt range, maintaining smooth motion during long events. Power over Ethernet delivers 12 V DC over the LAN cable, removing the need for a local power supply during extended sessions.

IP streaming protocol and bandwidth limits

ONVIF, RTSP, RTMP and GB/T28181 are the supported network protocols, so the stream fits standard NVR and software ecosystems but cannot use proprietary or newer transport methods. The single 3.5 mm line input embeds external audio into the IP feed, yet there is no built-in microphone or additional audio interface. Maximum resolution stays at 1080p, so 4K workflows and higher-bitrate codecs beyond H.265 are not supported.

Najważniejsze cechy

  • 12x optical zoom captures distant detail clearly
  • Simultaneous HDMI, 3G-SDI, USB 3.0 and IP outputs fit any workflow
  • PoE delivers power and data over one cable
  • Pan 340° and tilt -30° to +90° covers wide areas
  • ONVIF, RTSP, RTMP support works with common platforms

Specyfikacja

BrandBZBGEAR
ModelBG-UPTZ-12XHSU-W
Bundled Camera Number1 Camera
Camera Type2 Megapixel
Network CameraYes
TypePTZ HDMI/SDI/USB 3.0 RS232/485 Live Streaming Camera
Connection TypeUSB 3.0, HDMI, 3G-SDI, LAN(POE), RS232/485, LINE IN
ColorWhite
Networking ProtocolRTSP, RTMP, ONVIF, GB/T28181
ONVIFYes
Pan/Tilt340°(max. speed: 80°/s) / -30° to +90° (max. speed: 60°/s)
Sensor & Detector1/2.8" Progressive CMOS
Pixels2 MP
HD Resolution1080p60/50, 1080i60/50, 1080p30/25,720p60/50
Frame Rateup to 60fps
Optical Zoom12x Optical Zoom
AudioYes
Power over EthernetYes
Power12V DC
Dimension(L)178× (W)115.5 ×(H)150.9mm
Weight1.38KG

Inne wersje tego modelu

Jeszcze 5 w tej samej serii

Ta sama rodzina, inna pamięć, inne chłodzenie lub taktowanie — proszę porównać przed decyzją.

Pytania dotyczące tego produktu

How loud or warm does the BG-UPTZ-12XHSU-W get when streaming 1080p60 over PoE all day?

The camera draws power through its PoE port and has no fan listed in the specifications, so it runs silently and stays cool during continuous operation.

Which cables and controllers must I already have to use the HDMI, 3G-SDI, USB 3.0 and RS-232/485 outputs together?

You need an HDMI cable, a 3G-SDI cable, a USB 3.0 cable, and a VISCA or Pelco-D/P controller for the RS-232/485 chain; PoE or the 12 V DC adapter powers the unit.

Will the 12× optical zoom and 340° pan work with my existing ONVIF NVR and VISCA joystick?

Yes — the camera supports ONVIF Profile S and VISCA over IP, so an ONVIF NVR can record the stream while a VISCA joystick controls pan, tilt, zoom and the 255 presets.
