Four green DDR3 ECC registered DIMMs in anti-static bags

Computer Memory Solutions

Computer Memory Solutions 16GB (4x4GB) DDR3 1333MHz ECC Registered DIMM Kit - B128

SKU CH-F4JA-G7G0J

16 GB kit of four 4 GB DDR3 1333 MHz ECC registered DIMMs validated for Dell PowerEdge C6100 servers

  • Capacity16GB (4 x 4GB)
  • Type240-Pin DDR3 SDRAM
  • SpeedDDR3 1333 (PC3 10600)
  • CAS LatencyCL9
  • Timing9-9-9
  • Voltage1.5V
  • ECC registered design protects data integrity in Dell PowerEdge C6100 servers
  • 16 GB quad-channel kit (4 × 4 GB) fills four slots for balanced throughput
  • DDR3-1333 CL9 timing matches C6100 spec for stable operation
  • Registered 2Rx4 modules support up to 192 GB maximum system capacity
  • 5 V standard voltage keeps power draw predictable in multi-socket Xeon platforms

Dell PowerEdge C6100 Server Memory Kit

This 16 GB kit contains four 4 GB DDR3 1333 MHz ECC registered DIMMs built for the Dell PowerEdge C6100. Each module runs at 1.5 V with CL9 9-9-9 timing and a 2Rx4 organisation. The 240-pin form factor fits the server's 12 available DIMM sockets when using registered memory. It is intended for administrators expanding capacity in compatible Dell rack servers.

Upgrade From Lower Capacity Or Speed

The kit replaces smaller DDR3 ECC registered modules or slower 1066 MHz and 800 MHz sticks that the platform down-clocks to when banks are fully populated. Moving to a full 16 GB quad-channel set is worthwhile when the workload needs the maximum 48 GB registered limit or 192 GB unbuffered limit supported by the C6100. Buyers who need larger single-module densities or non-ECC memory cannot use this product.

Straightforward Installation With Population Rules

Install by powering down, opening the chassis and seating each 240-pin DIMM until the ejectors click. The system requires identical modules within each bank; mixing registered and unbuffered ECC is not supported. Quad-rank modules in the second bank will drop to 800 MHz, so follow the vendor's triple-channel "K3" population guide for best performance.

Pontos fortes

  • ECC registered design protects data integrity in Dell PowerEdge C6100 servers
  • 16 GB quad-channel kit (4 × 4 GB) fills four slots for balanced throughput
  • DDR3-1333 CL9 timing matches C6100 spec for stable operation
  • Registered 2Rx4 modules support up to 192 GB maximum system capacity
  • 5 V standard voltage keeps power draw predictable in multi-socket Xeon platforms

Especificações

BrandComputer Memory Solutions
ModelCM5127210600ECCR2R4H
Capacity16GB (4 x 4GB)
Type240-Pin DDR3 SDRAM
SpeedDDR3 1333 (PC3 10600)
CAS LatencyCL9
Timing9-9-9
Voltage1.5V
ECCYes
Buffered/RegisteredRegistered
Rank2Rx4
ChipsetMajor Brand Chipset
Heat SpreaderBased on Current Inventory (If Required Please Contact)
Compatible SystemDell Poweredge C6100
Package Content4 Memory RAM Sticks

Perguntas sobre este artigo

Will the 240-Pin DDR3 DIMMs fit the six sockets in my Dell PowerEdge C6100?

Yes, each module is a 240-Pin DDR3 Registered ECC DIMM and the C6100 provides six sockets arranged in two banks of three for RDIMMs.

What is the correct order for populating the four modules across the two banks to run in triple-channel mode?

Install three modules first — one in each socket of the first bank — then add the fourth module in the first socket of the second bank; this follows the C6100 triple-channel population rule.

When should I expect to replace these 1.5 V Registered ECC modules in a 24/7 server?

They carry a limited lifetime warranty from Computer Memory Solutions and have no moving parts, so replacement is only needed if a module fails or capacity must be increased beyond 16 GB.
