Square red 120 mm case fan with thick 27 mm frame and black blades

ARCTIC COOLING

ARCTIC COOLING ACFAN00115A BioniX P120 Red 120 mm 27 mm case fan

SKU CH-S8DF-P9FTE MPN ACFAN00115A

Pressure-optimised 120 mm case fan with fluid-dynamic bearing, 200–2100 RPM, 67.56 CFM and 0.45 Sone, plus PWM sharing for synchronised control

  • Fan Counts1 Fan
  • Fan ControllerNo Controller
  • TypeCase Fan
  • CompatibilityCase
  • Fan Thickness27mm
  • Bearing TypeFluid Dynamic
  • Quiet operation at 0.45 sone for low-noise builds
  • 200 to 2100 RPM range adapts to cooling demand
  • 56 CFM airflow pushes air through dense heatsinks
  • Fluid dynamic bearing reduces friction and extends life
  • PWM sharing technology syncs multiple fans from one header

BioniX P120 Red 120 mm pressure fan

The ARCTIC COOLING BioniX P120 Red is a 120 mm case fan with a 27 mm frame and fluid-dynamic bearing. It runs from 200 to 2100 RPM and delivers 67.56 CFM of airflow at 0.45 Sone. The 4-pin connector plus 4-pin socket enables PWM sharing technology to keep multiple fans in sync.

Builders needing high static pressure on radiators

This fan is optimised for static pressure, making it ideal on heatsinks, radiators and partly covered vents. Its 27 mm thickness requires matching clearance, so builders with slim-fan mounts should look elsewhere. The red frame suits colour-themed builds but offers no neutral option.

27 mm frame thickness decides fit

The single specification that determines compatibility is the 27 mm frame thickness. Verify that your case, radiator or heatsink mounting holes accept this dimension before purchase. The package includes one fan and four screws.

商品特色

  • Quiet operation at 0.45 sone for low-noise builds
  • 200 to 2100 RPM range adapts to cooling demand
  • 56 CFM airflow pushes air through dense heatsinks
  • Fluid dynamic bearing reduces friction and extends life
  • PWM sharing technology syncs multiple fans from one header

商品規格

BrandARCTIC COOLING
SeriesBioniX P120 - Red
ModelACFAN00115A
Fan Counts1 Fan
Fan ControllerNo Controller
TypeCase Fan
CompatibilityCase
Fan Thickness27mm
Bearing TypeFluid Dynamic
RPM200 - 2100 RPM
Air Flow67.56 CFM
Noise Level0.45 Sone
Power Connector4-pin connector + 4-pin socket
ColorRed
FeaturesOptimized for static pressure
Ideal on heatsinks, radiators, and partly covered vents
PWM sharing technology (pst) regulates fans in sync
Dimensions120.00 x 120.00 x 27.00 mm
Package Contents1 x FAN
4 x Screw
出貨重量0.18 kg
包裝尺寸132 × 130 × 36 mm

商品問答

What does the 67.56 CFM airflow figure mean when the fan is installed on a radiator?

The 67.56 CFM rating shows the maximum volume of air the fan can move at 2100 RPM; on a radiator the static-pressure optimised blades keep more of that flow intact through the fins.

What does the 4-pin connector plus 4-pin socket provide for speed control?

The 4-pin PWM connector lets the motherboard vary speed from 200 to 2100 RPM, while the extra 4-pin socket allows a second fan to share the same signal through PWM sharing technology.

Will the 27 mm thickness fit a standard 120 mm mounting point?

The fan uses the standard 120 mm square hole pattern, but the frame is 27 mm thick so verify that your case, radiator or heatsink clearance accepts that depth.
