Gray 12.1 inch all-in-one panel PC with resistive touch screen and aluminum alloy chassis

partaker

Partaker A26 AI edge system 12.1" resistive touch i5-7200U 8GB 256GB

SKU CH-BZEW-1QJ96

A fanless aluminium 12.1" resistive touch panel PC with an i5-7200U, 8 GB DDR4, 256 GB mSATA, dual Gigabit LAN, two COM ports and IP65 front protection

  • TypeAll-in-One PC
  • Form FactorAll-in-One
  • ColorGray
  • Operating SystemWindows 10 Pro
  • CPU TypeIntel Core i5 7th Gen
  • CPU NameIntel Core i5-7200U

A26 12.1" Resistive I5 7200U 8GB RAM / 256GB SSD

  • 1-inch resistive touch screen rated IP65 for dust and water resistance
  • Fanless aluminum alloy chassis enables silent operation in harsh industrial environments
  • Dual Gigabit Ethernet ports plus four USB and two configurable COM ports for extensive connectivity
  • Intel Core i5-7200U processor with up to 32 GB DDR4 memory for reliable automation performance
  • Optional 9–36 V DC wide-range power input adapts to varied industrial power supplies

Industrial all-in-one with resistive touch

The Partaker A26 is a fanless industrial panel PC built around a 12.1-inch resistive TFT-LCD with XGA 1024x768 resolution. Its aluminum alloy chassis carries an IP65-rated front panel for dust and water resistance in harsh environments. The system ships with Windows 10 Pro and an Intel Core i5-7200U dual-core processor running up to 3.10 GHz. It targets automation, visualization and control tasks that demand silent, maintenance-free operation.

8 GB DDR4 with 32 GB ceiling

The unit arrives with 8 GB of DDR4 memory installed across two slots and supports a maximum of 32 GB for heavier workloads. Storage is provided by a single mSATA SSD slot populated with a 256 GB drive. Expansion includes two Mini PCIe slots, one wired for wireless modules with a SIM holder. This memory ceiling is the key figure when sizing the system for concurrent HMI and gateway duties.

Fanless thermal design for continuous duty

Passive cooling through the aluminum alloy shell keeps the i5-7200U at its rated speeds without fans or moving parts. The platform is specified for an operating range that includes sub-zero temperatures and includes a hardware watchdog with 0-255 level control. Dual Realtek Gigabit Ethernet ports support wake-on-LAN and PXE for remote management. The 12 V DC input, with an optional 9-36 V wide-range variant, ensures stable power in industrial cabinets.

商品特色

  • 1-inch resistive touch screen rated IP65 for dust and water resistance
  • Fanless aluminum alloy chassis enables silent operation in harsh industrial environments
  • Dual Gigabit Ethernet ports plus four USB and two configurable COM ports for extensive connectivity
  • Intel Core i5-7200U processor with up to 32 GB DDR4 memory for reliable automation performance
  • Optional 9–36 V DC wide-range power input adapts to varied industrial power supplies

商品規格

TypeAll-in-One PC
Form FactorAll-in-One
ColorGray
Operating SystemWindows 10 Pro
CPU TypeIntel Core i5 7th Gen
CPU NameIntel Core i5-7200U
Screen Size12.1"
Screen TypeMulti-Touch Screen

其他版本

同系列還有 5 款

同系列產品，記憶體、散熱器或時脈不同 — 下單前請先比較。

商品問答

What does the i5-7200U's 3.10 GHz boost mean for daily industrial workloads?

The dual-core processor reaches 3.10 GHz on burst tasks such as HMI updates or data logging, while the fanless aluminium chassis keeps sustained clocks steady without acoustic noise.

How do the dual Gigabit Ethernet ports and RS232/485 COM ports limit real-world throughput?

Each RJ45 port caps at 1 Gbps and each COM port at RS485 electrical levels, so aggregate bandwidth depends on the connected switch and fieldbus master rather than the panel PC itself.

What cut-out and VESA pattern are needed to mount the 12.1-inch unit in a cabinet?

The embedded mount requires a 298.5 mm by 237 mm rectangular cut-out, and the rear provides standard VESA holes for arm or wall brackets.
