Green PCIe card with two USB-C and five USB-A ports on a metal bracket

Vszerda

Vszerda PCI-E USB 3.2 7-Port (2C/5A) Expansion Card

SKU CH-NPET-8Y4EG

Adds seven USB 3.2 ports — two Type-C and five Type-A — over a single PCIe slot with up to 20 Gbps total bandwidth

  • Connect up to seven devices with two USB-C and five USB-A ports
  • Transfer files at up to 10 Gbps per port on USB 3.2 Gen 2
  • Total 20 Gbps bandwidth split across two independent controllers
  • Works with Windows 7 through 11 and Mac OS 10.8.2 or later
  • Fits any PCIe x1, x4, x8 or x16 slot on PCIe 2.0 or 3.0 motherboards

Seven-Port PCIe USB 3.2 Expansion

This Vszerda add-on card adds seven USB 3.2 ports to a desktop PC through a single PCI Express slot. It provides two USB Type-C and five USB Type-A connectors for attaching drives, input devices, cameras and other peripherals. The card fits x1, x4, x8 or x16 slots and works with Windows 7 through 11 and Mac OS 10.8.2 or newer. No driver is required for Windows 10 or 11 or for Mac OS and Linux.

Bandwidth Limits and Protocol Constraints

The seven ports share two 10 Gbps channels for a total of 20 Gbps bandwidth. Each port can reach 10 Gbps when used alone, but simultaneous transfers divide the available throughput. The card does not support Power Delivery fast charging, video output or Thunderbolt protocol, so it cannot drive displays or fast-charge laptops. Windows XP, Vista, 7 and Server editions need a driver install before the ports become active.

PCIe Slot Requirement

Installation requires a free PCI Express slot of any width from x1 to x16 on a motherboard compatible with PCIe 2.0 or 3.0. Systems without an open slot cannot use this card, and the bandwidth ceiling is set by the host slot generation.

商品特色

  • Connect up to seven devices with two USB-C and five USB-A ports
  • Transfer files at up to 10 Gbps per port on USB 3.2 Gen 2
  • Total 20 Gbps bandwidth split across two independent controllers
  • Works with Windows 7 through 11 and Mac OS 10.8.2 or later
  • Fits any PCIe x1, x4, x8 or x16 slot on PCIe 2.0 or 3.0 motherboards

商品規格

本商品目前尚未公佈規格。

商品問答

Should I pick the version with five Type-A and two Type-C ports or the one with four Type-A and three Type-C?

The card described here has five USB Type-A ports and two USB Type-C ports.

What does the 10 Gbps per-port rate mean when I plug in several drives at once?

Ports are grouped so one Type-C and three Type-A share 10 Gbps, while the remaining three ports share a second 10 Gbps pool, giving 20 Gbps total bandwidth.

Does the PCIe 3.0 x1 slot cap the 20 Gbps total throughput?

A PCIe 3.0 x1 link provides roughly 8 Gbps usable bandwidth, so the slot will limit the card's combined 20 Gbps potential.
