Tower chassis with front bezel and eight 3.5-inch drive trays

DELL

DELL E5-2683 PowerEdge T430 5U rack server 2× 2.1 GHz 16-core Xeon 256 GB DDR4 H730 8× 3.5" trays

SKU CH-XYC7-YZXEQ MPN E5-2683

5U rack server with dual 16-core Xeon CPUs at 2.1 GHz, 256 GB DDR4, H730 RAID controller, and eight 3.5-inch drive trays

  • Type0
  • Rack Height5U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.10 GHz
  • CPU SocketLGA 2011-3

Installed Memory Size 256GB

HDD None

CPU Model E5-2683 V4

  • Dual 16-core Xeon CPUs deliver 32 total cores for heavy multi-threaded workloads
  • 256 GB DDR4 registered ECC memory supports large datasets and virtualisation
  • PERC H730 controller enables RAID 0, 1, 5, 6, 10, 50, 60 with battery-backed cache
  • Eight 3.5-inch SAS/SATA drive trays provide high-capacity internal storage expansion
  • Dual 750 W platinum power supplies and iDRAC8 Express ensure uptime and remote management

Dual Xeon 5U server for office workloads

The Dell PowerEdge T430 is a 5U rack server equipped with two Intel Xeon E5-2683 v4 processors, each running at 2.1 GHz with 16 cores. It includes 256 GB of DDR4 registered ECC memory across 12 slots, expandable to 384 GB. The PERC H730 storage controller supports RAID 0, 1, 5, 6, 10, 50, 60 and pass-through modes. Dual 750 W redundant power supplies and iDRAC8 Express remote management are built in.

Suits small-office and branch-office deployments

This system suits buyers who need a rack-mount platform for file, print, mail, web or collaboration workloads with room for eight 3.5-inch SATA or SAS drives. It is not suited to buyers who need drives included, a tower chassis without rack rails, or memory types other than DDR4. The integrated dual-port 1 GbE adapter meets basic network needs but offers no higher-speed onboard interfaces.

Eight 3.5-inch drive bays with H730 RAID

The single specification that decides fit is the eight 3.5-inch hot-swap trays paired with the PERC H730 1 GB controller. This combination determines how many spinning disks or SSDs you can install and which RAID levels are available. If your storage plan exceeds eight drives or requires a different controller feature set, this server will not match the requirement.

Highlights

  • Dual 16-core Xeon CPUs deliver 32 total cores for heavy multi-threaded workloads
  • 256 GB DDR4 registered ECC memory supports large datasets and virtualisation
  • PERC H730 controller enables RAID 0, 1, 5, 6, 10, 50, 60 with battery-backed cache
  • Eight 3.5-inch SAS/SATA drive trays provide high-capacity internal storage expansion
  • Dual 750 W platinum power supplies and iDRAC8 Express ensure uptime and remote management

Specifications

BrandDELL
SeriesPowerEdge T430
ModelT430
Type0
Rack Height5U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.10 GHz
CPU SocketLGA 2011-3
Number of CPU Cores16-Core Processor
# of Processors Installed0
MAX Processors2
ChipsetIntel C610
Installed Memory Size256GB
Memory TypeDDR4
Max Memory Capacity384GB
Number of Memory Slots12
Hard Drive (Installed)None
Storage ControllerDell Perc H730 1GB Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Media Drives0
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerIntegrated Dell Broadcom 5720 Dual Port 1GbE LOM
LAN Ports4 x Ports
Expansion Slots1 x PCIe 3.0 x16 Slot, Single Riser Included (Riser 3)
Management PortRJ 45
Operating SystemNo
Features8 x 3.5" SATA/SAS Hot-Plug Drive Bays

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What does the 2× 16-core 2.1 GHz Xeon setup deliver in this server?

Two E5-2683 v4 processors give 32 cores at 2.1 GHz base with 3.0 GHz turbo, suited for multi-threaded workloads such as virtualization, databases or file serving.

What does the PERC H730 12Gb/s controller cap in practice?

The H730 supports RAID 0/1/5/6/10/50/60 and pass-through at 12Gb/s SAS/SATA; actual throughput depends on the drives installed in the eight 3.5-inch bays.

What clearance and mounting does the 5U T430 chassis require?

The 5U rack-mount chassis fits a standard 5U bay; plastic feet are not included for tower placement.
