Green rectangular server motherboard with large silver CPU socket, eight black memory slots, seven PCIe slots and silver heatsinks

GIGABYTE

GIGABYTE MC62-G40-5955WX01 server motherboard with Threadripper PRO 5955WX 16-core 32-thread

SKU CH-68WE-SFG29 MPN MC62-G40-5955WX01

Server motherboard with integrated 16-core 32-thread Threadripper PRO processor, eight-channel DDR4 up to 2 TB, seven PCIe 4.0 x16 slots, dual 10 GbE LAN and three SlimSAS connectors

  • CPU Socket TypeSocket sWRX8
  • CPU TypeSupports AMD Ryzen Threadripper PRO 5000WX Series Processors
  • Number of Processor Support1
  • CPU FeaturesUp to 64 cores, 128 threads TDP up to 280W
  • North BridgeAMD WRX80
  • Number of DDR4 Slots8 x 288-pin

Model

  • 5955WX
  • 5965WX

Struck-through versions exist but are not stocked here.

  • 16-core 32-thread Threadripper PRO 5955WX delivers workstation performance
  • Eight-channel DDR4 3200 supports 2 TB ECC registered memory
  • Seven PCIe 4.0 x16 slots enable multi-GPU configurations
  • Dual 10 GbE plus 1 GbE LAN with dedicated management port
  • 4 SATA 6.0 Gb/s, 3 SlimSAS and 2 M.2 storage slots

Server motherboard with 16-core Threadripper PRO

The GIGABYTE MC62-G40 bundles a Threadripper PRO 5955WX processor with 16 cores and 32 threads into a single sWRX8 workstation board. It targets professionals running heavily threaded workloads such as rendering, simulation or virtualisation who need a validated CPU-and-board combination. Buyers who want more storage lanes than the board provides or who require dual-socket scaling should look elsewhere.

Sustained load behaviour with 280W TDP ceiling

The integrated 5955WX operates at a 4.0 GHz base clock and can boost to 4.5 GHz within a 280W thermal envelope. Eight-channel DDR4-3200 feeds all cores simultaneously, while the WRX80 chipset distributes PCIe 4.0 bandwidth across seven full-length slots for multi-GPU or accelerator arrays. Builders who need higher core counts than 16 or who rely on liquid-cooling blocks not cleared for this socket will hit limits.

Installation notes for sWRX8 workstation builds

The board uses standard 288-pin DDR4 slots supporting UDIMM, RDIMM, 3DS RDIMM and LRDIMM up to 2 TB total with ECC and registered operation. Two M-key M.2 slots accept 2242 or 2280 drives, and three SlimSAS connectors provide additional PCIe Gen4 or SATA pathways. Installers must verify case clearance for the seven PCIe slots and ensure the power delivery matches the 280W processor rating.

Highlights

  • 16-core 32-thread Threadripper PRO 5955WX delivers workstation performance
  • Eight-channel DDR4 3200 supports 2 TB ECC registered memory
  • Seven PCIe 4.0 x16 slots enable multi-GPU configurations
  • Dual 10 GbE plus 1 GbE LAN with dedicated management port
  • 4 SATA 6.0 Gb/s, 3 SlimSAS and 2 M.2 storage slots

Specifications

BrandGIGABYTE
ModelMC62-G40
CPU Socket TypeSocket sWRX8
CPU TypeSupports AMD Ryzen Threadripper PRO 5000WX Series Processors
Supports AMD Ryzen Threadripper PRO 3000WX Series Processors
Number of Processor Support1
CPU FeaturesUp to 64 cores, 128 threads
TDP up to 280W
North BridgeAMD WRX80
Number of DDR4 Slots8 x 288-pin
DDR4 StandardDDR4 3200
Maximum Memory Supported2TB
Channel SupportedEight Channel
ECC SupportedYes
RegisteredYes
PCI Express 4.0 x16Slot_7: PCIe x16 (Gen4 x16) slot
Slot_6: PCIe x16 (Gen4 x16) slot
Slot_5: PCIe x16 (Gen4 x16) slot
Slot_4: PCIe x16 (Gen4 x16) slot
Slot_3: PCIe x16 (Gen4 x16) slot
Slot_2: PCIe x16 (Gen4 x8) slot
Slot_1: PCIe x16 (Gen4 x16) slot
SATA4 x SATA 6.0Gb/s
Additional SATA RAID0/1/5/10
SAS3 x SlimSAS connector (PCIe Gen4 x4 or SATA)
M.22 x M.2 slots for storage:
- M-key
- PCIe Gen4 x4 or SATA, from CPU
- Support 2242/2280 cards
1 x M.2 slot for Wi-Fi:
- E-key
- Supports 2230 cards
Audio ChipsetRealtek ALC4080
Audio Channels7.1 Channels
Number of LAN2
LAN ChipsetIntel X550-AT2
LAN Speed10/100/1000Mbps
Second LAN ChipsetIntel I210-AT
Second LAN Speed10/100/1000Mbps
Max LAN Speed2 x 10Gbps + 1Gbps
Back I/O Ports1 x USB 3.2 Gen 2x1 (Type-C)(FCH)
4 x USB 3.2 Gen 2x1 (Type-A)(CPU)
1 x USB 3.2 Gen 2x1 (Type-A)(FCH)
1 x VGA
2 x RJ45 (10Gb/s)
1 x RJ45 (1Gb/s)
1 x MLAN
3 x Audio jacks
1 x ID button with LED
Onboard USB2 x USB 3.2 Gen1 x2 headers
Other Connectors1 x 24-pin ATX main power connector
2 x 8-pin ATX 12V power connectors
1 x CPU fan header
1 x FCH fan header
8 x System fan headers
2 x M.2 slots for storage
1 x M.2 slot for Wi-Fi
3 x SlimSAS connectors
4 x SATA connectors
1 x Front panel header
1 x Backplane board header
1 x COM header
1 x PMBus header
1 x IPMB header
1 x TPM header
Form FactorCEB
Dimensions (W x L)12.0" x 10.5"
Package Contents1 x MC62-G40
1 x I/O shield
1 x Quick start guide
1 x SlimSAS to 4 x SATA 6Gb/s cable (600mm)
4 x SATA 6Gb/s cables (500mm)
Contains Embedded BatteryNo
Shipping weight2.00 kg
Package size363 × 330 × 81 mm

Other versions of this model

1 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How much power does the included Threadripper PRO 5955WX draw under sustained load?

The processor has a 280W TDP, so plan cooling and a power supply that can deliver that continuously.

What memory must I supply to use the eight DDR4 slots?

You need DDR4 3200 registered ECC modules — UDIMM, RDIMM, 3DS RDIMM or LRDIMM — up to 2TB total across all eight channels.

Can I keep my PCIe 3.0 add-in cards in the seven PCIe 4.0 x16 slots?

Yes, the slots are backward compatible; PCIe 3.0 cards will run at Gen3 speeds in any of the seven slots.
