Silver 1U rack server chassis with four front drive bays and redundant power supplies

HP

HP ProLiant DL360 Gen9 rack server 2× E5-2640 v3 2.6 GHz 64 GB 2× 1 TB SAS

SKU CH-T4S0-7K2S7

A 1U rack server with dual eight-core Xeon processors at 2.6 GHz, 64 GB DDR4 memory, two 1 TB SAS drives and redundant 500 W power supplies

  • TypeRack
  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon E5 v3
  • MAX Processors2
  • ChipsetIntel C610

Installed Memory Size 64GB

Struck-through versions exist but are not stocked here.

HDD 2 x 1TB SAS

Struck-through versions exist but are not stocked here.

  • Dual Xeon E5-2640 v3 CPUs provide 16 cores at 2.6 GHz for heavy workloads
  • 64 GB DDR4 ECC memory fills all 24 DIMM slots for maximum capacity
  • Two 1 TB 7.2K SAS drives on H240ar controller support RAID 0/1/5/6/10/50/60
  • Redundant hot-swap 500 W power supplies keep the 1U server running during failures
  • 4 LFF drive bays in 1U rack height allow future storage expansion

Dense 1U compute platform

The HP ProLiant DL360 Gen9 packs two Intel Xeon E5-2640 v3 eight-core processors at 2.6 GHz and 64 GB of DDR4 ECC memory into a single rack unit. Dual 500 W hot-swap power supplies provide redundancy for continuous operation. This configuration targets virtualization hosts, database nodes and high-density web tiers that need maximum thread count in minimal space.

Upgrade from single-socket or Gen8

Moving from a single-processor server or an earlier Gen8 chassis adds a second socket, doubling core count to 16 physical and 32 logical cores while keeping the same 1U footprint. The jump is worth it when workloads scale across threads — container clusters, multi-tenant databases or heavy Java middleware — and when the existing power and cooling budget already supports 500 W redundant supplies.

SAS 12 Gb/s controller with 6 Gb/s drives

The Smart HBA H240ar controller supports 12 Gb/s SAS and 6 Gb/s SATA, but the two installed 3.5-inch 1 TB drives run at 7.2K RPM on a 6 Gb/s link. That link speed caps sequential throughput well below the controller ceiling, so random I/O and mixed workloads will hit the drive limit first. Four LFF bays total leave two empty slots; adding faster SAS SSDs or more spindles is the only way to raise the storage ceiling.

Highlights

  • Dual Xeon E5-2640 v3 CPUs provide 16 cores at 2.6 GHz for heavy workloads
  • 64 GB DDR4 ECC memory fills all 24 DIMM slots for maximum capacity
  • Two 1 TB 7.2K SAS drives on H240ar controller support RAID 0/1/5/6/10/50/60
  • Redundant hot-swap 500 W power supplies keep the 1U server running during failures
  • 4 LFF drive bays in 1U rack height allow future storage expansion

Specifications

BrandHP
SeriesProLiant
ModelProliant DL360 G9
TypeRack
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon E5 v3
MAX Processors2
ChipsetIntel C610
Installed Memory Size64GB
Memory TypeDDR4
Max Memory Capacity64GB
Memory Features24 DIMM slots, 12 per processor. (4GB/8GB/16GB/32GB/64GB DDR4 up to 2400MT/s ECC Registered, actual memory speed dependent on the processor capability).
Number of Memory Slots24
Storage ControllerHP Smart HBA H240ar Controller
HDD InterfaceSAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Media DrivesNone
GPU TypeMatrox G200
Video Memory16MB
Remote ManagementiLO Management (standard).
LAN Ports4 x Ports
Expansion SlotsPrimary Riser: 2 PCIe 3.0 Slots (1 & 2) available: 1x Full-Height Half Length, 1x Half-Lenth Half Height. Optional PCIe 3.0 slot 3 - Full-Height Half Height (Secondary PCIe Riser and dual CPU required).
Operating SystemNo
Compatible/Certified OSMicrosoft Windows Small Business Server 2011/2008, Microsoft Windows Server 2008 R2 SP1/SP2, Microsoft Windows HPC Server 2008 R2, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Oracle Solaris
Weight63.0000LBS

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What rack depth is needed for this 1U DL360 Gen9 server?

The unit occupies 1U of rack height. Ensure the cabinet depth accommodates the full chassis length and cable clearance at the rear.

How are the two 3.5-inch SAS drives installed in the four LFF bays?

Slide each drive into its carrier until the latch clicks, then insert the carrier into any of the four front bays until it locks; the H240ar controller detects them automatically.

When should the 64 GB DDR4 ECC registered memory be upgraded?

Add modules in matched pairs per processor up to the 24-slot limit when workloads exceed the installed capacity; all DIMMs must be DDR4 ECC registered.
