A slim 1.8 inch Intel 910 Series SSD, silver metal casing with gold edge connector

Intel

Intel 910 Series SSDPEDPX800G301 800 GB 1.8-Inch internal SSD

SKU CH-7TM8-53MPQ MPN SSDPEDPX800G301

PCIe internal SSD delivering up to 2 GB/s sequential read, 1 GB/s sequential write, 180,000 random read IOPS and 75,000 random write IOPS with 25 nm HET MLC NAND rated for 10 drive writes per day

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Capacity800GB
  • Memory ComponentsMLC
  • InterfacePCI Express
  • Max Sequential ReadUp to 2 GB/s
  • 800 GB capacity stores large workloads in a compact 1.8-inch form factor
  • Sequential read up to 2 GB/s accelerates data-intensive applications
  • Random read up to 180000 IOPS delivers responsive performance for mixed workloads
  • 25nm HET MLC NAND with 10 drive writes per day for 5 years ensures high endurance
  • PCI Express 2.0 interface enables easy deployment without HBA hardware or software configuration

910 Series PCIe SSD for servers

The Intel 910 Series SSDPEDPX800G301 is an 800 GB internal solid-state drive built on a PCIe 2.0 form factor. It targets enterprise servers that need high endurance and low latency without redesigning the chassis. The drive uses 25nm HET MLC NAND rated for 10 drive writes per day over five years. Sequential reads reach up to 2 GB/s and writes up to 1 GB/s.

Driver-only deployment removes HBA complexity

The drive plugs directly into a PCIe slot and operates after a driver load and reboot. No Host Bus Adapter hardware, cabling or software configuration is required. This eliminates the SAS HBA layer that would otherwise add cost, space and power draw. Random performance reaches 180,000 IOPS read and 75,000 IOPS write at 4 KB.

Verify PCIe slot height and driver support

The physical height is 69 mm, so the target server must accept a card of that profile in its PCIe slot. Confirm the operating system or hypervisor includes a compatible driver before ordering. The drive weighs 190 g and measures 168 mm deep by 19 mm wide. Warranty coverage from the manufacturer extends to 2018.

Highlights

  • 800 GB capacity stores large workloads in a compact 1.8-inch form factor
  • Sequential read up to 2 GB/s accelerates data-intensive applications
  • Random read up to 180000 IOPS delivers responsive performance for mixed workloads
  • 25nm HET MLC NAND with 10 drive writes per day for 5 years ensures high endurance
  • PCI Express 2.0 interface enables easy deployment without HBA hardware or software configuration

Specifications

BrandIntel
Series910 Series Ramsdale
ModelSSDPEDPX800G301
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Capacity800GB
Memory ComponentsMLC
InterfacePCI Express
Max Sequential ReadUp to 2 GB/s
Max Sequential WriteUp to 1 GB/s
4KB Random ReadUp to 180,000 IOPS
4KB Random WriteUp to 75,000 IOPS
FeaturesUltimate Performance
- Latency R/W: 65/65us
High Endurance
- 25nm HET MLC NAND
- 10x drive writes / day for 5 years
- 30x endurance over standard MLC
Ease of Deployment
- No HBA HW/SW config
- No chassis adaptation
- No system tuning
Quality & Reliability
- Intel validation, system compatibility, and support
Height69mm
Width19mm
Depth168mm
Weight190g
Shipping weight0.98 kg
Package size152 × 102 × 51 mm

Questions about this item

Will this drive fit in a standard 1.8-inch drive bay?

The drive measures 69 mm by 19 mm by 168 mm and weighs 190 g, matching the 1.8-inch form factor listed in the specifications.

Does the card require a separate host bus adapter or extra cabling?

No. The manufacturer highlights state that no HBA hardware or software configuration, cabling or chassis adaptation is needed; the drive plugs directly into a PCIe slot.

What endurance rating does the 25 nm HET MLC NAND provide?

The drive is rated for 10 full drive writes per day for 5 years, which the manufacturer describes as 30 times the endurance of standard MLC.
