Rectangular silver 2.5 inch SATA SSD with label showing Intel DC S3500 800GB

Intel

Intel DC S3500 SSDSC2BB800G4 800GB 2.5" SATA enterprise SSD

SKU CH-7AHM-AKW5S

A 2.5" SATA enterprise SSD with 800GB of MLC storage delivering up to 500 MBps read and 450 MBps write speeds for server workloads

  • Form Factor2.5"
  • Capacity800GB
  • Memory ComponentsMLC
  • InterfaceSATA 6Gb/s
  • Max Sequential ReadUp to 500 MBps
  • Max Sequential WriteUp to 450 MBps
  • Up to 500 MB/s sequential read for fast data access
  • Up to 450 MB/s sequential write for quick data storage
  • 75,000 IOPS random read for responsive mixed workloads
  • 11,500 IOPS random write for steady transaction performance
  • 2,000,000 hours MTBF for long-term reliability

Intel DC S3500 800GB SATA enterprise SSD

This 2.5 inch drive delivers 800GB of MLC NAND over a SATA 6Gb/s link for read-intensive server workloads. Sequential speeds reach 500 MBps read and 450 MBps write, with random performance of 75,000 IOPS read and 11,500 IOPS write. Latency sits at 50 µs read and 65 µs write. The 2 million hour MTBF and 7 mm height suit standard hot-swap bays.

Installation notes for 2.5 inch SATA SSD

The drive slides into any 2.5 inch SATA bay and connects with standard data and power cables. No special drivers are required beyond the operating system SATA stack. A common issue is forgetting to enable AHCI mode in the system BIOS, which limits queue depth and random IOPS. Ensure the backplane or cabling supports 6Gb/s signalling to realise the rated throughput.

Sustained load behaviour of DC S3500

Under continuous operation the drive draws 5W active power and is rated for 0°C to 70°C ambient temperature. The 1,000G shock rating and 2.17 GRMS operating vibration tolerance protect data integrity in dense rack environments. Steady-state write latency remains consistent because the MLC media and controller avoid the sharp throttle seen in consumer TLC drives during long sequential writes.

Highlights

  • Up to 500 MB/s sequential read for fast data access
  • Up to 450 MB/s sequential write for quick data storage
  • 75,000 IOPS random read for responsive mixed workloads
  • 11,500 IOPS random write for steady transaction performance
  • 2,000,000 hours MTBF for long-term reliability

Specifications

BrandIntel
SeriesDC S3500
ModelSSDSC2BB800G4
Form Factor2.5"
Capacity800GB
Memory ComponentsMLC
InterfaceSATA 6Gb/s
Max Sequential ReadUp to 500 MBps
Max Sequential WriteUp to 450 MBps
4KB Random ReadUp to 75,000 IOPS
4KB Random WriteUp to 11,500 IOPS
Read Latency50 µs
Write Latency65 µs
MTBF2,000,000 hours
Power Consumption (Idle)0.9W
Power Consumption (Active)5W
Operating Temperature0°C ~ +70°C
Max Shock Resistance1,000G at 0.5 msec
Max Vibration ResistanceOperating: 2.17 GRMS (5-700 Hz)
Non-Operating: 3.13 GRMS (5-800 Hz)
Height7.00mm
Weight72g +/- 2g

Questions about this item

How can I confirm the SSDSC2BB800G4 is delivering its rated 75,000 random read IOPS after installation?

Run a 4 KB random read benchmark such as fio or CrystalDiskMark; sustained results near 75,000 IOPS with latency around 50 µs indicate the drive is performing to specification.

What ships with the Intel DC S3500 800 GB drive and what must I source separately?

The package contains only the 2.5" 7.00 mm SATA SSD; you must supply a 2.5" drive bay or caddy, SATA data and power cables, and any mounting screws required by your chassis.

Which DC S3500 capacity should I choose for a write-heavy database workload?

The 800 GB model provides up to 11,500 random write IOPS and 450 MB/s sequential write; select a larger capacity only if you need more space, as write performance scales with capacity in this series.
