Small square barebone mini PC in white finish

Intel

Intel NUC13VYKi7 Core i7-1360P barebone mini PC

SKU CH-61SM-V8776 MPN NUC13VYKi7

Barebone mini PC with a 13th Gen Core i7-1360P, Iris Xe graphics, dual DDR4-3200 slots for 64 GB, two M.2 bays, 2.5 Gb Ethernet, Wi-Fi 6E and dual Thunderbolt 4 ports

  • CPU TypeIntel Core i7 13th Gen
  • Memory installedNo Memory
  • Memory slot2 x 262Pin SO-DIMM
  • Memory Type SupportedDDR4 3200
  • Max Memory Supported64GB
  • Dual Channel Memory SupportedYes

CPU Type Intel Core i7-1360P

Group No Memory / No Hard Drive

Options NUC 13 Pro NUC13VYKi7

  • 12-core i7-1360P reaches 5.0 GHz turbo for responsive multitasking
  • Dual-channel DDR4-3200 supports up to 64 GB for large workloads
  • Two M.2 slots accept PCIe Gen 4 NVMe and SATA storage
  • Dual Thunderbolt 4 ports carry DP 1.4a video and USB4 data
  • 5 GbE LAN plus Wi-Fi 6E AX211 and Bluetooth 5 for fast connectivity

Intel NUC 13 Pro Vivid Canyon barebone

The Intel NUC13VYKi7 is a barebone mini PC built around a 13th Generation Core i7-1360P processor with 12 cores and 16 threads. It ships without memory or storage so you choose DDR4-3200 SO-DIMMs up to 64 GB and two M.2 drives. Integrated Iris Xe graphics with 96 execution units handles 4K output over dual HDMI 2.1 ports.

Upgrading from older NUCs or larger desktops

The jump is worth it when you need Thunderbolt 4, 2.5 GbE and Wi-Fi 6E in a chassis qualified for 24/7 operation. Dual-channel DDR4-3200 and a PCIe Gen 4 x4 M.2 slot remove the storage and memory bottlenecks common in earlier small-form-factor systems. The 35 W TDP keeps cooling simple while delivering 5.0 GHz turbo performance.

Suits builders who want a compact.

It fits signage, kiosk or home-lab roles that demand dual 4K displays, discrete TPM 2.0 and plenty of USB 3.2 Gen 2 ports. Buyers who need discrete graphics, more than two M.2 slots or memory types other than DDR4 should look at something else.

Highlights

  • 12-core i7-1360P reaches 5.0 GHz turbo for responsive multitasking
  • Dual-channel DDR4-3200 supports up to 64 GB for large workloads
  • Two M.2 slots accept PCIe Gen 4 NVMe and SATA storage
  • Dual Thunderbolt 4 ports carry DP 1.4a video and USB4 data
  • 5 GbE LAN plus Wi-Fi 6E AX211 and Bluetooth 5 for fast connectivity

Specifications

BrandIntel
SeriesVivid Canyon
ModelNUC13VYKi7
CPU TypeIntel Core i7 13th Gen
Memory installedNo Memory
Memory slot2 x 262Pin SO-DIMM
Memory Type SupportedDDR4 3200
Max Memory Supported64GB
Dual Channel Memory SupportedYes
Storage InstalledNo Hard Drive
M.2 Slot2 x M.2
Discrete Graphic CardIntel Iris Xe Graphics 96EU
Onboard AudioIntegrated
Channel7.1 Channel
LANIntel® Ethernet Controller i226-V
Max LAN Speed2.5Gbps
Wireless LANIntel® Wi-Fi 6E AX211 (Gig+)
Bluetooth5.3
Front USB2x USB 3.2
Front Audio Ports3.5mm headphone/mic jack
Thunderbolt 32x Thunderbolt™ 4
Rear USB2x USB 4 (type C)
RJ451
Input20V
Power Supply120W
Dimensions117 x 111 x 37 [mm] (LxWxH)
Weight1.5kg
PackagingOriginal packaging

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What size SO-DIMM modules fit the 262-pin slots?

The board has two 262-pin SO-DIMM slots that accept DDR4-3200 modules up to 64 GB total in dual-channel mode.

Which screw do I use for the 22x80 M.2 SSD?

The M.2 22x80 key-M slot uses a single mounting screw at the 80 mm position; the 22x42 key-B slot uses the 42 mm position.

When should I replace the CMOS battery?

Replace the coin cell when the system loses date and time settings after being unplugged, typically after several years of 24/7 operation.
