KingSpec NX-256 M.2 2280 NVMe SSD, bare green circuit board with gold edge connector, no heatsink

KingSpec

KingSpec NX-256 2280 256GB PCIe 3.0 x4 NVMe internal SSD

SKU CH-8WDJ-YYYTG

M.2 2280 NVMe drive with 256GB capacity, PCIe 3.0 x4 interface and up to 3200MB/s sequential read

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity256GB
  • Memory Components3D NAND
  • InterfacePCI-Express 3.0 x4

Options NX-256-2280

  • Up to 3200 MB/s read speeds with PCIe 3.0 x4 NVMe 1.3
  • 1600 MB/s sequential write for fast file saves using 3D NAND
  • 380,000 random read IOPS and 320,000 write IOPS for responsive multitasking
  • 120 TBW endurance and 1,000,000-hour MTBF for long-term reliability
  • Low 0.71 W idle and 4.66 W active power draw extends laptop battery life

KingSpec NX-256 2280 PCIe 3.0 x4 NVMe SSD

The KingSpec NX-256 2280 is a 256GB internal solid-state drive built for consumer desktops and laptops. It uses the M.2 2280 form factor with a PCI-Express 3.0 x4 interface and NVMe 1.3 protocol. The drive employs 3D NAND flash for storage density and endurance.

No bundled accessories

The product ships as a bare drive without a heatsink, extra cables, cloning utilities or mounting hardware. Installation relies on the host system's M.2 slot and native NVMe driver support. Performance figures reflect the drive alone.

256GB capacity with 120TB written endurance

The drive offers 256GB of usable capacity and a terabytes-written rating of 120TB. Sequential speeds reach up to 3200 MBps read and 1600 MBps write. Random performance hits 380000 IOPS read and 320000 IOPS write.

Highlights

  • Up to 3200 MB/s read speeds with PCIe 3.0 x4 NVMe 1.3
  • 1600 MB/s sequential write for fast file saves using 3D NAND
  • 380,000 random read IOPS and 320,000 write IOPS for responsive multitasking
  • 120 TBW endurance and 1,000,000-hour MTBF for long-term reliability
  • Low 0.71 W idle and 4.66 W active power draw extends laptop battery life

Specifications

BrandKingSpec
SeriesNX 2280 Series
ModelNX-256 2280
Part NumberNX-256 2280
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity256GB
Memory Components3D NAND
InterfacePCI-Express 3.0 x4
ProtocolNVMe 1.3
Max Sequential ReadUp to 3200 MBps
Max Sequential WriteUp to 1600 MBps
4KB Random ReadUp to 380,000 IOPS
4KB Random WriteUp to 320,000 IOPS
Terabytes Written (TBW)120TB
MTBF1,000,000 hours
HeatSinkwithout HeatSink
Power Consumption (Idle)0.71W
Power Consumption (Active)4.66W
Operating Temperature0°C ~ +70°C
Storage Temperature-20°C ~ +75°C
Operating Humidity5-95%
Height2.10mm
Width22.00mm
Depth80.00mm
Weight50g

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How many terabytes can be written to the NX-256 2280 before the drive reaches its rated endurance limit?

The drive is rated for 120 TBW, so you can write up to 120 terabytes over its lifetime before the endurance limit is reached.

Which performance limit appears first during long sequential writes on this PCIe 3.0 x4 SSD?

Sequential write speed caps at 1600 MBps, so sustained large-file transfers will hit that throughput ceiling before other limits.

What is the active power draw of the NX-256 2280 when it runs continuously under load?

Active power consumption is 4.66 W, so the drive draws that amount from the system during sustained operation.
