Green circuit board with black chips, M.2 2280 stick, no heatsink

KingSpec

KingSpec NX-FB 2TB M.2 2280 PCIe 3.0 x4 NVMe 1.3 internal SSD

SKU CH-1YWJ-KW78F

2TB M.2 2280 PCIe 3.0 x4 NVMe 1.3 SSD with 3D NAND delivering up to 3500 MB/s sequential read and 3200 MB/s sequential write

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity2TB
  • Memory Components3D NAND
  • InterfacePCI-Express 3.0 x4

Options NX-2TB-Soccer 2280

  • Faster boot and app loading with up to 3500 MB/s sequential read
  • Smooth multitasking and game level loads from up to 3200 MB/s sequential write
  • Responsive system feel backed by up to 380000 random read IOPS
  • Long-term storage confidence with 960 TBW endurance rating
  • Efficient laptop operation at just 0.71 W idle power draw

Capacity and audience

The KingSpec NX-FB 2TB M.2 2280 drive uses 3D NAND and a PCIe 3.0 x4 interface with NVMe 1.3 to deliver up to 3500 MBps sequential read and 3200 MBps sequential write. It targets desktop and laptop users who need a large, fast internal volume for operating systems, applications and data libraries.

Build integration

The M.2 2280 form factor slots directly into a compatible motherboard or laptop M-key socket without cables, freeing 2.5-inch bays and SATA ports for other storage. Active power draw is 4.66W and idle draw is .71W, so a standard M.2 slot supplies sufficient power without extra connectors.

Bundled value

No heatsink, mounting hardware or software utilities are included in the package. The drive relies on the host system's airflow and any motherboard-integrated thermal solution, while the 960 TBW endurance rating and 1,000,000-hour MTBF provide the longevity assurance for heavy write workloads.

Highlights

  • Faster boot and app loading with up to 3500 MB/s sequential read
  • Smooth multitasking and game level loads from up to 3200 MB/s sequential write
  • Responsive system feel backed by up to 380000 random read IOPS
  • Long-term storage confidence with 960 TBW endurance rating
  • Efficient laptop operation at just 0.71 W idle power draw

Specifications

BrandKingSpec
SeriesNX-FB Series
ModelNX-512 2280
Part NumberNX-2TB-FB 2280
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity2TB
Memory Components3D NAND
InterfacePCI-Express 3.0 x4
ProtocolNVMe 1.3
Max Sequential ReadUp to 3500 MBps
Max Sequential WriteUp to 3200 MBps
4KB Random ReadUp to 380,000 IOPS
4KB Random WriteUp to 320,000 IOPS
Terabytes Written (TBW)960TB
MTBF1,000,000 hours
HeatSinkwithout HeatSink
Power Consumption (Idle)0.71W
Power Consumption (Active)4.66W
Operating Temperature0°C ~ +70°C
Storage Temperature-20°C ~ +75°C
Operating Humidity5-95%
Height2.10mm
Width22.00mm
Depth80.00mm
Weight50g

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Will this 2 TB M.2 2280 drive fit a laptop that only has an M.2 slot with PCIe 3.0 x4 support?

Yes, the drive uses the M.2 2280 form factor and a PCIe 3.0 x4 interface with NVMe 1.3, so it will install and operate in any slot that provides those connections.

Does the 960 TBW endurance rating cover typical heavy workloads such as video editing or large game libraries?

A 960 TBW rating means you can write nearly a petabyte of data over the drive's life, which is ample for daily creative work, large game installs and frequent system imaging.

What power draw should I expect when the SSD is under sustained load?

Active power consumption is 4.66 W, while idle drops to 0.71 W, so a standard laptop or desktop M.2 power rail can supply the drive without extra cooling or power adapters.
