Green circuit board M.2 2242 NVMe SSD with black controller and gold edge connector

KingSpec

KingSpec NXM-512 512GB M.2 2242 NVMe internal SSD

SKU CH-TZ71-DDCQB

A 512 GB M.2 2242 NVMe drive with 3D NAND, PCIe 3.0 x4 interface and speeds up to 3500 MB/s read, 2700 MB/s write

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2242
  • Capacity512GB
  • Memory Components3D NAND
  • InterfacePCI-Express 3.0 x4

Options NXM-512 2242

  • Up to 3500 MB/s sequential read for fast boot and load times
  • Up to 2700 MB/s sequential write speeds up file saves and transfers
  • 330,000 random read IOPS delivers responsive multitasking
  • M.2 2242 form factor fits ultrabooks, laptops and desktops
  • 3D NAND with LDPC error correction protects data integrity

NXM-512 512GB M.2 2242 NVMe SSD

The KingSpec NXM-512 is a 512GB internal solid-state drive built on 3D NAND flash. It uses the M.2 2242 form factor and a PCIe 3.0 x4 interface with NVMe 1.3 compliance. The drive targets users upgrading ultrabooks, laptops, desktops or all-in-one PCs where a short M.2 slot is the only storage option.

Build integration and system impact

The 42.0mm length fits tight M.2 2242 slots in thin devices and leaves larger bays free for secondary drives. A PCIe 3.0 x4 motherboard key and NVMe 1.3 support are required. The drive draws 3.6W at idle from a 3.3V rail and supports S.M.A.R.T., TRIM and hardware LDPC error correction across Windows 7-10, Linux and CentOS.

Sustained workload behaviour

Sequential throughput reaches up to 3500 MBps read and 2700 MBps write with 4KB random performance up to 330,000 read IOPS and 250,000 write IOPS. The on-board heat spreader helps manage temperatures during extended transfers within the 0°C to 70°C operating range. MTBF is rated at 1,000,000 hours.

Highlights

  • Up to 3500 MB/s sequential read for fast boot and load times
  • Up to 2700 MB/s sequential write speeds up file saves and transfers
  • 330,000 random read IOPS delivers responsive multitasking
  • M.2 2242 form factor fits ultrabooks, laptops and desktops
  • 3D NAND with LDPC error correction protects data integrity

Specifications

BrandKingSpec
SeriesNXM Series
ModelNXM-512
Part NumberNXM-512
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2242
Capacity512GB
Memory Components3D NAND
InterfacePCI-Express 3.0 x4
Max Sequential ReadUp to 3500 MBps
Max Sequential WriteUp to 2700 MBps
4KB Random ReadUp to 330,000 IOPS
4KB Random WriteUp to 250,000 IOPS
MTBF1,000,000 hours
Power Consumption (Idle)3.6W
Operating Temperature0°C ~ +70°C
Storage Temperature-20°C ~ +75°C
Operating Humidity5% to 95% RH non-condensing
Height42.00mm
Width22.00mm
Depth3.50mm
Weight45g

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Will this 42 mm M.2 2242 drive fit my ultrabook or small-form-factor desktop?

The drive measures 42.0 mm long by 22.0 mm wide by 3.5 mm high, matching the M.2 2242 form factor used in many ultrabooks, laptops, desktops and all-in-ones.

What speeds can I expect for everyday tasks like booting and loading games?

Sequential read reaches up to 3500 MBps and write up to 2700 MBps, with 4 KB random read up to 330,000 IOPS and random write up to 250,000 IOPS.

Does it work with my current operating system without extra drivers?

It supports Windows 7 through 10, Linux and Cent OS using the standard NVMe 1.3 protocol over PCIe 3.0 x4.
