Green printed circuit board M.2 2280 SSD with black controller and NAND chips, no heatsink

MSI

MSI SPATIUM M390 250GB PCIe Gen3 x4 NVMe internal SSD

SKU CH-6P6Q-SB75Y

M.2 2280 NVMe drive delivering up to 3300 MB/s read and 1200 MB/s write with 150 TBW endurance

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity250GB
  • Memory Components3D NAND
  • InterfacePCIe Gen3 x4, NVMe 1.4
  • Sequential read up to 3300 MB/s for fast boot and load times
  • Sequential write up to 1200 MB/s to move large files quickly
  • 4 KB random write up to 300,000 IOPS for snappy multitasking
  • 150 TBW endurance rating backed by 1.5 million hour MTBF
  • Low 30 mW idle power extends laptop battery life

SPATIUM M390 250GB NVMe SSD

The MSI SPATIUM M390 is a 250GB internal solid-state drive built for consumer desktops and laptops. It uses an M.2 2280 form factor with 3D NAND flash memory and a PHISON E15T controller. The drive targets everyday computing, gaming loads, and content workflows that need responsive NVMe storage.

PCIe Gen3 x4 interface limits

This drive connects through a PCIe Gen3 x4 link using the NVMe 1.4 protocol. The interface caps theoretical throughput, so sequential speeds cannot exceed the bus limit regardless of controller capability. Random read reaches 150,000 IOPS and random write reaches 300,000 IOPS within that constraint. Active power draw is 3.2W while idle consumption sits at 30 mW.

150TB endurance rating

The terabytes-written figure of 150TB defines how much data can be written before the warranty endurance threshold is met. That number determines whether the drive suits light desktop use or heavier write workloads such as video editing caches. MTBF is rated at 1,500,000 hours and the drive includes LDPC ECC, end-to-end data path protection, TRIM, and SMART monitoring.

Highlights

  • Sequential read up to 3300 MB/s for fast boot and load times
  • Sequential write up to 1200 MB/s to move large files quickly
  • 4 KB random write up to 300,000 IOPS for snappy multitasking
  • 150 TBW endurance rating backed by 1.5 million hour MTBF
  • Low 30 mW idle power extends laptop battery life

Specifications

BrandMSI
SeriesSPATIUM Series
ModelM390
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity250GB
Memory Components3D NAND
InterfacePCIe Gen3 x4, NVMe 1.4
ControllerPHISON E15T
Max Sequential ReadUp to 3300 MBps
Max Sequential WriteUp to 1200 MBps
4KB Random ReadUp to 150,000 IOPS
4KB Random WriteUp to 300,000 IOPS
Terabytes Written (TBW)150TB
MTBF1,500,000 hours
HeatSinkwithout HeatSink
FeaturesTRIM (Performance Optimization, OS Support required)
SMART (Self-Monitoring, Analysis and Reporting Technology)
LDPC (Low Density Parity Check) ECC Algorithm
End to End Data Path Protection
APST (Autonomous Power State Transition)
AES256/TCG Pyrite (Encryption, Data Security)
Power Consumption (Idle)30 mW
Power Consumption (Active)3.2W
Operating Temperature0°C ~ +70°C
Storage Temperature-40°C ~ +85°C
Height2.15mm
Width22.00mm
Depth80.00mm

Questions about this item

Is the 250 GB M390 the right capacity for a boot drive plus a few games?

The 250 GB model holds the OS, core apps and a handful of large titles while leaving headroom for updates; its 150 TBW rating covers typical daily writes for years.

How fast will the 3300 MB/s sequential read actually feel when Windows boots or a game level loads?

Large sequential transfers such as game assets or OS images move at up to 3300 MB/s, cutting load screens to a fraction of what a mechanical drive delivers.

What does PCIe Gen3 x4 NVMe 1.4 cap at for this drive?

The four-lane Gen3 link limits peak throughput to the stated 3300 MB/s read and 1200 MB/s write, so the controller cannot exceed those ceilings.
