Green rectangular circuit board with gold edge connector and black controller chip, no heatsink

Patriot Memory

Patriot Memory P300P256GM28 256GB M.2 2280 PCIe Gen3 x4 NVMe 1.3 internal SSD

SKU CH-C5N0-1MT24 MPN P300P256GM28

256 GB M.2 2280 NVMe 1.3 SSD with PCIe Gen3 x4 reaching 1700 MB/s read and 1100 MB/s write, HMB cache, end-to-end data protection and 80 TBW

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity256GB
  • InterfacePCIe Gen3 x4, NVMe 1.3
  • CacheNo DRAM (HMB)

Options 256GB

  • Fast boots and launches with up to 1700 MBps read
  • Responsive multitasking via up to 1100 MBps write
  • Snappy small-file access at 290,000 random read IOPS
  • Longer laptop runtime from 0.37 W idle power
  • Data integrity protected by end-to-end datapath protection

256 GB PCIe Gen3 x4 NVMe SSD

The Patriot P300 is a 256 GB internal SSD in the M.2 2280 form factor. It uses a PCIe 3.0 x4 interface with NVMe 1.3 for desktops and laptops. The drive has no DRAM cache and relies on HMB technology. End-to-end data path protection guards data integrity.

Sustained workload behaviour

Sequential reads reach up to 1700 MBps and writes up to 1100 MBps. Random performance hits 290,000 IOPS read and 260,000 IOPS write. Active power draw is 2.07 W and idle drops to 0.37 W. The controller operates from 0 °C to 70 °C with thermal management and wear levelling to prevent sharp speed drops over time. Rated endurance is 80 TB written.

Upgrade path from PCIe 3 x2 or SATA

This drive replaces slower PCIe 3 x2 NVMe SSDs or SATA SSDs with a 25 percent gain in transfer speeds and IOPS. The jump is worthwhile when boot times, application launches and file copies feel sluggish on the older interface. Windows 7, 8, 8.1 and 10 are supported, though Windows 7 may need a driver.

Highlights

  • Fast boots and launches with up to 1700 MBps read
  • Responsive multitasking via up to 1100 MBps write
  • Snappy small-file access at 290,000 random read IOPS
  • Longer laptop runtime from 0.37 W idle power
  • Data integrity protected by end-to-end datapath protection

Specifications

BrandPatriot
SeriesP300
ModelP300P256GM28
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity256GB
InterfacePCIe Gen3 x4, NVMe 1.3
CacheNo DRAM (HMB)
EncryptionEnd-to-End Datapath Protection
Max Sequential ReadUp to 1700 MBps
Max Sequential WriteUp to 1100 MBps
4KB Random ReadUp to 290,000 IOPS
4KB Random WriteUp to 260,000 IOPS
HeatSinkwithout HeatSink
FeaturesThe P300 is Patriot's next generation of mid-tier PCIe gen 3x4 NVMe SSD to hit the market, offering 25% higher transfer speeds and IOPs than standard PCIe 3x2 solutions. The compact m.2 form factor is designed for easy installation and will fit into any PC or laptop, while its low power consumption helps extend laptop battery life. The P300 is guaranteed to improve start-up, loading, and transfer times over traditional hard disk drives.
The P300's advanced firmware offers ECC technology and end-to-end data path protection to ensure data integrity throughout the life to the drive. Adv
Power Consumption (Idle)0.37W
Power Consumption (Active)2.07W
Operating Temperature0°C ~ +70°C
Height3.80mm
Width22.00mm
Depth80.00mm
Weight9.00g
Shipping weight0.02 kg
Package size131 × 102 × 7 mm

Other versions of this model

3 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How warm does the P300 256GB get and how much power does it draw when running all day?

The drive is rated for 0°C to 70°C operating temperature, draws 2.07W active and 0.37W idle, and ships without a heatsink.

What slot and protocol must my motherboard or laptop provide for this M.2 2280 NVMe drive to work?

An M.2 2280 key-M slot wired for PCIe Gen3 x4 with NVMe 1.3 support is required; no DRAM cache is on-board, so host memory buffer is used.

Will the P300 256GB work in an older system that only has PCIe Gen3 x2 lanes?

The drive needs a full x4 link for its 1700 MBps read and 1100 MBps write; on x2 it will fall back to lower speeds but remains functional.
