Green rectangular M.2 2280 SSD with exposed black controller and NAND chips

Patriot Memory

Patriot Memory P300P512GM28 512GB M.2 2280 PCIe Gen3 x4 NVMe 1.3 internal SSD

SKU CH-EXJJ-2QRKM MPN P300P512GM28

A 512 GB M.2 2280 NVMe 1.3 SSD delivering 1700 MBps read and 1200 MBps write speeds with end-to-end data protection

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity512GB
  • InterfacePCIe Gen3 x4, NVMe 1.3
  • CacheNo DRAM (HMB)

Options 512GB

  • Up to 1700 MBps sequential read for fast boot and load times
  • Up to 1200 MBps sequential write to finish large file tasks quickly
  • 290000 IOPS random read and 260000 IOPS random write keep multitasking responsive
  • Host Memory Buffer uses system RAM instead of DRAM cache to lower power draw to .37W idle
  • End-to-end data path protection and NANDXtend ECC guard data integrity across 160TB written

Compact M.2 2280 NVMe drive for laptops and desktops

The Patriot P300 512GB SSD uses a PCIe Gen3 x4 interface with NVMe 1.3 to deliver up to 1700 MBps sequential read and 1200 MBps sequential write. Random performance reaches 290,000 IOPS read and 260,000 IOPS write. The DRAM-less design relies on Host Memory Buffer technology and NANDXtend ECC for data integrity.

Sustained workload behaviour without a heatsink

Operating between 0 °C and 70 °C, the drive draws 0.37 W idle and 2.07 W active. End-to-end datapath protection and wear-leveling firmware maintain consistent throughput during extended writes. The 160 TBW rating reflects the endurance available for typical consumer workloads over the drive’s service life.

Upgrade from PCIe 3.0 x2 or SATA M.2 drives

The x4 controller provides roughly 25 percent higher transfer speeds and IOPS than standard PCIe 3.0 x2 solutions. The jump is worthwhile when moving from a SATA M.2 SSD or an older x2 NVMe drive in a system limited to PCIe Gen3. Windows 7, 8, 8.1 and 10 are supported, with a possible driver requirement for Windows 7.

Highlights

  • Up to 1700 MBps sequential read for fast boot and load times
  • Up to 1200 MBps sequential write to finish large file tasks quickly
  • 290000 IOPS random read and 260000 IOPS random write keep multitasking responsive
  • Host Memory Buffer uses system RAM instead of DRAM cache to lower power draw to .37W idle
  • End-to-end data path protection and NANDXtend ECC guard data integrity across 160TB written

Specifications

BrandPatriot
SeriesP300
ModelP300P512GM28
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity512GB
InterfacePCIe Gen3 x4, NVMe 1.3
CacheNo DRAM (HMB)
EncryptionEnd-to-End Datapath Protection
Max Sequential ReadUp to 1700 MBps
Max Sequential WriteUp to 1200 MBps
4KB Random ReadUp to 290,000 IOPS
4KB Random WriteUp to 260,000 IOPS
HeatSinkwithout HeatSink
FeaturesThe P300 is Patriot's next generation of mid-tier PCIe gen 3 x4 NVMe SSD to hit the market, offering 25% higher transfer speeds and IOPs than standard PCIe 3 x2 solutions. The compact m.2 form factor is designed for easy installation and will fit into any PC or laptop, while its low power consumption helps extend laptop battery life. The P300 is guaranteed to improve start-up, loading, and transfer times over traditional hard disk drives.
The P300's advanced firmware offers ECC technology and end-to-end data path protection to ensure data integrity throughout the life to the drive. A
Power Consumption (Idle)0.37W
Power Consumption (Active)2.07W
Operating Temperature0°C ~ +70°C
Height3.80mm
Width22.00mm
Depth80.00mm
Weight9.00g
Shipping weight0.02 kg
Package size131 × 102 × 7 mm

Other versions of this model

3 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How much heat and power will the P300 512GB drive produce during all-day use?

Active power draw is 2.07W with idle at 0.37W, and the drive is rated for 0°C to 70°C operating temperature without a heatsink.

What must my motherboard provide for this M.2 2280 NVMe SSD to work?

An M.2 2280 slot wired for PCIe 3.0 x4 and NVMe 1.3 support; the drive has no DRAM cache and relies on host memory buffer.

Will the P300 512GB drive work in a system limited to PCIe 3.0 x2 lanes?

It will function but at reduced throughput; the drive is built for PCIe 3.0 x4 and delivers 25% higher transfer speeds than x2 solutions.
