Black M.2 2280 stick with red label, 2TB capacity

SAMSUNG

SAMSUNG 970 EVO M.2 2280 2TB internal SSD MZ-V7E2T0BW

SKU CH-R9FV-3F59H MPN MZ-V7E2T0BW

A 2TB M.2 2280 internal SSD delivering up to 3500 MBps sequential read and 2500 MBps sequential write with 2GB LPDDR4 DRAM cache

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity2TB
  • Memory Components64L V-NAND MLC
  • InterfacePCIe Gen3. X4, NVMe 1.3

Options 2TB

  • Fast boot and load times with up to 3500 MB/s sequential read
  • Responsive multitasking backed by up to 500,000 IOPS random read
  • Sustained write performance from up to 2500 MB/s sequential write
  • Reliable long-term storage with 1,500,000-hour MTBF
  • Cool, efficient operation at 30 mW idle power

Samsung 970 EVO 2TB NVMe SSD

The Samsung 970 EVO MZ-V7E2T0BW is a 2TB internal solid state drive built for consumer workloads. It uses the M.2 2280 form factor and connects through a PCIe Gen3 x4 interface with NVMe 1.3 protocol. The drive suits desktops and laptops that need fast storage for operating systems, applications and large media files.

Phoenix controller with 2GB LPDDR4 cache

The Samsung Phoenix controller manages the 64-layer V-NAND MLC flash and a 2GB LPDDR4 DRAM cache. This combination delivers sequential reads up to 3500 MBps and sequential writes up to 2500 MBps. Random read performance reaches 500,000 IOPS at QD32 and 15,000 IOPS at QD1, while random write hits 480,000 IOPS at QD32. Samsung Magician software enables cloning, firmware updates and performance optimisation.

2TB capacity with 1,500,000 hour MTBF

The 2TB capacity provides ample room for games, creative projects and system images. Endurance is rated for heavy daily writes over the warranty period. Active power draw averages 6W with a 10W burst ceiling, while idle consumption stays at 30 mW. The drive operates between 0°C and 70°C and withstands 1,500G shock, ensuring reliability in portable and desktop systems.

Highlights

  • Fast boot and load times with up to 3500 MB/s sequential read
  • Responsive multitasking backed by up to 500,000 IOPS random read
  • Sustained write performance from up to 2500 MB/s sequential write
  • Reliable long-term storage with 1,500,000-hour MTBF
  • Cool, efficient operation at 30 mW idle power

Specifications

BrandSAMSUNG
Series970 EVO
ModelMZ-V7E2T0BW
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity2TB
Memory Components64L V-NAND MLC
InterfacePCIe Gen3. X4, NVMe 1.3
ControllerSamsung Phoenix Controller
Cache2GB LPDDR4 DRAM
Max Sequential ReadUp to 3500 MBps
Max Sequential WriteUp to 2500 MBps
4KB Random ReadQD32: Up to 500,000 IOPS
QD1: Up to 15,000 IOPS
4KB Random WriteQD32: Up to 480,000 IOPS
MTBF1,500,000 hours
Power Consumption (Idle)Max. 30 mW
Power Consumption (Active)Average: 6W
Maximum: 10W (Burst mode)
Operating Temperature0°C ~ +70°C
Max Shock Resistance1,500G & 0.5 ms (Half sine)
Height2.30mm
Width22.10mm
Depth80.26mm
Weight7.94g
Shipping weight0.08 kg
Package size141 × 98 × 24 mm

Other versions of this model

3 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How long is the rated endurance for the 2TB 970 EVO before the V-NAND MLC cells may need replacement?

The drive is rated for up to 1,200 TBW total bytes written, which represents the endurance limit of the 64-layer V-NAND MLC memory.

Which thermal limit is reached first during sustained heavy writes on the 970 EVO 2TB?

The operating temperature ceiling is 70 °C; Samsung's Dynamic Thermal Guard throttles performance once this threshold is approached to protect the controller and NAND.

What are the typical power draw and heat output when the 970 EVO 2TB runs all day under load?

Active power averages 6 W with bursts up to 10 W; idle power is a maximum of 30 mW, so heat output scales directly with those wattage levels.
