Green printed circuit board M.2 2280 stick with black controller and silver Samsung label

SAMSUNG

SAMSUNG 970 EVO MZ-V7E1T0BW 1TB internal SSD

SKU CH-ZVA0-QB3YP MPN MZ-V7E1T0BW

M.2 2280 drive with 1TB capacity delivers sequential read speeds up to 3400 MBps and write speeds up to 2500 MBps using 64L V-NAND MLC and a 1GB LPDDR4 DRAM cache

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity1TB
  • Memory Components64L V-NAND MLC
  • InterfacePCIe Gen 3.0 x4, NVMe 1.3

Options 1TB

  • Up to 3400 MB/s sequential read for fast boot and load times
  • Up to 2500 MB/s sequential write speeds up large file transfers
  • 64-layer V-NAND MLC with 1GB LPDDR4 cache delivers sustained performance
  • AES 256-bit encryption and TCG Opal 2.0 keep data secure
  • 600 TBW endurance rating supports heavy daily workloads

Samsung 970 EVO 1TB NVMe Drive

The Samsung 970 EVO MZ-V7E1T0BW is a 1TB internal solid state drive built for consumer workloads. It uses a PCIe Gen 3.0 x4 interface with NVMe 1.3 protocol and a Samsung Phoenix controller. The drive suits tech enthusiasts, high end gamers, and 4K and 3D content designers who need low latency and power efficiency.

PCIe Gen 3.0 x4 Interface Limits

The PCIe Gen 3.0 x4 link caps maximum sequential read at 3400 MBps and sequential write at 2500 MBps. Random read reaches 500,000 IOPS at QD32 and 15,000 IOPS at QD1. Random write reaches 450,000 IOPS at QD32 and 50,000 IOPS at QD1. Active power averages 6W with a 10W burst maximum.

1TB Capacity and 600 TBW Endurance

The 1TB capacity uses 64L V-NAND MLC memory with a 1GB LPDDR4 DRAM cache. The drive is rated for 600 TBW and an MTBF of 1,500,000 hours. Dynamic Thermal Guard manages operating temperatures from 0°C to 70°C. AES 256-bit encryption and TCG Opal IEEE1667 protect data at rest.

Highlights

  • Up to 3400 MB/s sequential read for fast boot and load times
  • Up to 2500 MB/s sequential write speeds up large file transfers
  • 64-layer V-NAND MLC with 1GB LPDDR4 cache delivers sustained performance
  • AES 256-bit encryption and TCG Opal 2.0 keep data secure
  • 600 TBW endurance rating supports heavy daily workloads

Specifications

BrandSAMSUNG
Series970 EVO
ModelMZ-V7E1T0BW
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity1TB
Memory Components64L V-NAND MLC
InterfacePCIe Gen 3.0 x4, NVMe 1.3
ControllerSamsung Phoenix Controller
Cache1GB LPDDR4 DRAM
Max Sequential ReadUp to 3400 MBps
Max Sequential WriteUp to 2500 MBps
4KB Random ReadQD32: Up to 500,000 IOPS
QD1: Up to 15,000 IOPS
4KB Random WriteQD32: Up to 450,000 IOPS
QD1: Up to 50,000 IOPS
MTBF1,500,000 hours
FeaturesTrim Support
AES Encryption: AES 256-bit Encryption (Class 0) TCG / Opal IEEE1667 (Encrypted drive)
S.M.A.R.T. Support
GC (Garbage Collection): Auto Garbage Collection Algorithm
Device Sleep Mode Support
Temperature proof
NVMe
Gaming SSDs
Management SW: Magician Software for SSD management
Power Consumption (Idle)Max. 30 mW
Power Consumption (Active)Average: 6W
Maximum: 10W (Burst mode)
Operating Temperature0°C ~ +70°C
Max Shock Resistance1,500G & 0.5 ms (Half sine)
Height2.30mm
Width22.10mm
Depth80.26mm
Weight7.94g
Shipping weight0.08 kg
Package size145 × 99 × 23 mm

Other versions of this model

3 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Will this M.2 2280 drive fit in my laptop's PCIe Gen 3.0 x4 slot?

Yes, the drive uses the M.2 2280 form factor and a PCIe Gen 3.0 x4 interface with NVMe 1.3 protocol, matching that slot exactly.

Does the 1TB capacity provide enough endurance for heavy daily writes?

The drive is rated for 600 TBW and uses 64L V-NAND MLC with a 1GB LPDDR4 DRAM cache to sustain high write workloads.

Is hardware encryption supported without third-party software?

The controller includes AES 256-bit encryption compliant with TCG Opal and IEEE 1667 standards for hardware-based drive locking.
